China leading manufacturer lab test flotation device with 0.75L/1.5L/3L/8L
- Категория: Минеральный сепаратор >>>
- Поставщик: Ganzhou,Gelin,Mining,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 1547.48 $* | 1624.10 $* |
| Aug-16-2025 | 1534.10 $* | 1611.12 $* |
| Jul-16-2025 | 1287.36 $* | 1351.71 $* |
| Jun-16-2025 | 1508.92 $* | 1583.26 $* |
| May-16-2025 | 1313.65 $* | 1379.98 $* |
| Apr-16-2025 | 1482.32 $* | 1556.40 $* |
| Mar-16-2025 | 1469.15 $* | 1542.12 $* |
| Feb-16-2025 | 1456.27 $* | 1529.12 $* |
| Jan-16-2025 | 1443.36 $* | 1515.66 $* |
Характеристики
China leading manufacturer lab test flotation device with 0.75L/1.5L/3L/8L volume
The Laboratory Flotation Machine is used for continuous laboratory test work and small pilot plants. It is similar to the standard commercial machines as far as basic design is concerned; however, it is built in single cell units to allow greater flexibility in testing.The equipment is applicable to the laboratory flotation of a small sample ore in such areas as geology, metallurgy, building material and chemical industry.
Gelin supply different types of lab flotation machines for meeting customers' requirements.
Products Description
1. XFD-12 Laboratory Multiple Cell Flotation Machine
XFD-12 laboratory multiple cell flotation machines applicable to used in flotation of non-ferrous metals, ferrous metals, non- metallic and coal that 35 nesh or less size fraction . It also can be used in float test on 125-3000g flotation sample.
Advantage:
Frequency conversion technology;
Frequency conversion technology;
Speed Indicator
Stainless steel Impeller
Specification | XFD-12 |
Groove capacity(L) | 0.5, 0.75, 1, 2, 4, 8 |
Rotary speed of impeller (rpm) | 700-2000 |
Feeding granularity(mm) | 2 |
Motor | 250W |
Diameter of impeller (mm) | 54, 73, 95 |
Boundary dimension(mm) | 560*460*860 |
Weight(kg) | 58 |
The ordinary simple type, the impeller rotary speed can not be adjustable, and without LED display screen, without heater device, can not control temperature of the minerals.
1. Machine base 8.Motor
2.Supporting board 9. Flow Meter
3. Cell 10.Switch
4. Mix impeller 11.switch of scraper
5. Scraper 12.Frequency transformer
6. Main shaft 13.Adjusting knob
7. Cover;
All parts are fastened to the body, the spindle rotates in the clockwise direction , the movement through a belt to the spindle pulley belt and the spindle pulley have three different speeds. Rotation of the blade driven by the blade driven pulley the motor can have two different speed. The blade height can be adjusted by the position of the butterfly nut
Flotation machine driven by V-belt drive motor rotating impeller to form centrifugal vacuum, on the one hand inhalation pulp mixed with sufficient air , on the other hand stirring the pulp to mixed with drugs, while refined foam, mineral adhesive foam on top , float to the surface and then form a slurry bubble mineralization. Adjust shutter’s height and control surface to scrape the useful foam.
3. Cell 10.Switch
4. Mix impeller 11.switch of scraper
5. Scraper 12.Frequency transformer
6. Main shaft 13.Adjusting knob
7. Cover;
All parts are fastened to the body, the spindle rotates in the clockwise direction , the movement through a belt to the spindle pulley belt and the spindle pulley have three different speeds. Rotation of the blade driven by the blade driven pulley the motor can have two different speed. The blade height can be adjusted by the position of the butterfly nut
Flotation machine driven by V-belt drive motor rotating impeller to form centrifugal vacuum, on the one hand inhalation pulp mixed with sufficient air , on the other hand stirring the pulp to mixed with drugs, while refined foam, mineral adhesive foam on top , float to the surface and then form a slurry bubble mineralization. Adjust shutter’s height and control surface to scrape the useful foam.
XFD I Series Technical Parameters | Model | |||||||||||
Model | XFD I-0.5 | XFD I-0.75 | XFD I-1 | XFD I-1.5 | XFD I-3 | XFD I-8 | ||||||
Cell capacity | 0.5 | 0.75 | 1.0 | 1.5 | 3.0 | 8.0 | ||||||
Rotary speed of impeller(r/min) | 2590, 2340 | 2100, 1900 | 1910, 1750 | 1890, 1708 | 1400 | |||||||
Impeller diameter(mm) | 45 | 55 | 60 | 70 | 100 | |||||||
Rotary speed of scraper(r/min) | 15 30 | 7.9, 19.1 | ||||||||||
Feeding size(mm) | <0.2 | |||||||||||
Spindle motor(w) | 51k90A-EF 2800r/min 90W | JW63241410r/min 250w | ||||||||||
Dimension (mm) | 502*263*628 | 502*263*628 | 502*263*628 | 560*310*590 | 700*360*760 | |||||||
Weight(kg) | 29 | 28 | 30 | 32 | 50 | 72 | ||||||
it is the updated version of XFD I, the impeller rotary speed can be adjustable as your needs, but with LED display screen, without heater device, can not control temperature of the minerals.
Frequency conversion technology;
Stepless speed regulation of vane wheel;
LCD display;
Accurate direction adjustment;
Reliable operation;
Allowing installation of temperature controller;
Instant display of temperature of pulp in the cell;
Inflatable single cell flotator of FDC is designed with liquid level regulation, inflating volume regulation, digital display of
rotary speed and water supplement functions.
XFD II Series Technical Parameters | Model | |||||||||||
Model | XFD II-0.5 | XFD II-0.75 | XFD II-1 | XFD II-1.5 | XFD II-3 | XFD II-8 | ||||||
Cell capacity | 0.5 | 0.75 | 1.0 | 1.5 | 3.0 | 8.0 | ||||||
Rotary speed of impeller(r/min) | 0-2800 | 0-1400 | ||||||||||
Impeller diameter(mm) | 45 | 55 | 60 | 70 | 100 | |||||||
Rotary speed of scraper(r/min) | 0-30 | |||||||||||
Spindle motor(w) | 120W | 250w | ||||||||||
Feeding size (mm) | 0.04-0.25 | |||||||||||
Dimensions(mm) | 520*338*770 | 520*338*770 | 520*338*770 | 560*338*770 | 570*338*820 | 580*505*970 | ||||||
Weight(kg) | 26 | 28 | 35 | 40 | 50 | 80 | ||||||
It is the highest grade type. It uses inverter technology, variable speed impeller, digital display, and also change from the outside air to intake inflated with precise adjusted, clear and stable display.
According to user needs, it can be equipped with a heater, temperature control device to control, display tank mine fluid temperature at any time.
The machine can be equipped with additional water level automatically adjusts automatically administration and other devices, can achieve a higher level of automation.
The machine can be equipped with additional water level automatically adjusts automatically administration and other devices, can achieve a higher level of automation.
It uses inverter technology, variable speed impeller, digital display, and also change from the outside air to intake inflated with precise adjusted, clear and stable display. According to user needs, it can be equipped with a heater, temperature control device to control, display tank mine fluid temperature at any time. The machine can be equipped with additional water level automatically adjusts automatically administration and other devices, can achieve a higher level of automation.
The flotation machine has a frame member, spindle transmission parts, locking parts, wiper parts, flotation tank, outside the inflatable devices and electrical control components. Gas of pump tank supply to the rotor agitation, and mix with ore fluid, the stator is cut to produce tiny bubbles mineralization. Rotor speed is stepless and can be adjusted by inverter. Fixed flotation tank fasten by hand wheel drive screw clamp. Shaving foam body, its trajectory is a circular motion.
Advantages:The flotation machine has a frame member, spindle transmission parts, locking parts, wiper parts, flotation tank, outside the inflatable devices and electrical control components. Gas of pump tank supply to the rotor agitation, and mix with ore fluid, the stator is cut to produce tiny bubbles mineralization. Rotor speed is stepless and can be adjusted by inverter. Fixed flotation tank fasten by hand wheel drive screw clamp. Shaving foam body, its trajectory is a circular motion.
Frequency conversion adjust speed;
Set heating temperature;
Add air;
XFD III Series Technical Parameters | Model | |||||||||||
Model | XFD III-0.5 | XFD III-0.75 | XFD III-1 | XFD III-1.5 | XFD III-3 | XFD III-8 | ||||||
Cell capacity (L) | 0.5 | 0.75 | 1.0 | 1.5 | 3.0 | 8.0 | ||||||
Rotary speed of impeller(r/min) | 0-2800 | 0-1400 | ||||||||||
Impeller diameter(mm) | 45 | 55 | 60 | 70 | 100 | |||||||
Rotary speed of scraper(r/min) | 15-30 | |||||||||||
Feeding size(mm) | <0.25 | |||||||||||
Heating power(w) | 200w | 200w more | ||||||||||
Motor power(w) | 120 | 250 | ||||||||||
Voltage(V) | 220 | |||||||||||
Temperature adjust range(℃) | 50-150 | |||||||||||
Dimensions(mm) | 440*320*730 | 520*338*770 | 520*338*770 | 560*338*770 | 470*330*870 | 580*505*970 | ||||||
Weight(kg) | 30 | 30 | 35 | 43 | 50 | 80 | ||||||
Employing frequency conversion technology,continuously viable of vane wheel ;
Digital display and accurate adjustment ;
The hanging flotator of XFG series is applicable for stirring,scrubbing,separation and selection of small amounts of sample ore in labs of research institutes and mining bodies involving geology,metallurgy,building materials and chemical industry.
XFG Series Technical Parameters | ||||
Model | XFG5-35 | XFG50-100 | ||
Cell capacity (g) | 5/15/25/35 | 50/100 | ||
Cell capacity(mm) | 20/60/100/140 | 200/400 | ||
Rotary speed of impeller(r/min) | 0-2800 | |||
Impeller diameter(mm) | 20/26/30 | 36/48 | ||
Rotary speed of scraper(r/min) | 1000-1850 | |||
Feeding size(mm) | 0.05-0.2 | |||
Motor power(w) | 180 | |||
Dimensions(mm) | 450*300*700 | 450*300*700 | ||
Packing & Delivery
Packing
Normally the machines are taken apart before delivery and are packed by suitable packing ways, the packing ways are as below:
1. Nude packing.
2. Bundle packing.
3. Grass rope packing.
4. Water proof packing.
5. Wooden pallets packing.
6.Wooden box or carton box packing.
Delivery
Usually the equipments are delivered aboard by tracks,trains,or container(sea transportation). and some spare parts or very small goods also support to send by express, our company have built good relationships with large cargo agent and shipping companies which guarantee our products delivered safely and promptly.Sea transportation includes three delivery ways as below:
1.40HQ container: used for goods without overlength, overheight and overweight;
2.FR(Flat Rack) container:suitable for large equipments with overlength,overheight like ball mill,excavator,etc.
3.Bulk cargo shipment (LCL): used for some goods without loading in full container,normally it requires good packing with marks for safety and easy to be trackable.
Normally the machines are taken apart before delivery and are packed by suitable packing ways, the packing ways are as below:
1. Nude packing.
2. Bundle packing.
3. Grass rope packing.
4. Water proof packing.
5. Wooden pallets packing.
6.Wooden box or carton box packing.
Delivery
Usually the equipments are delivered aboard by tracks,trains,or container(sea transportation). and some spare parts or very small goods also support to send by express, our company have built good relationships with large cargo agent and shipping companies which guarantee our products delivered safely and promptly.Sea transportation includes three delivery ways as below:
1.40HQ container: used for goods without overlength, overheight and overweight;
2.FR(Flat Rack) container:suitable for large equipments with overlength,overheight like ball mill,excavator,etc.
3.Bulk cargo shipment (LCL): used for some goods without loading in full container,normally it requires good packing with marks for safety and easy to be trackable.
About Company
Ganzhou Gelin Mining Machinery Co., Ltd is an over 30 years professional manufacturer and exporter of mining machinery for crushing, screening, grinding, flotation, separation etc. in China. Gelin have a complete service system which can provide customer full service in mining field and after sales service.By now, Gelin’s equipments and services are exported to over 60 countries,include America, Russia, India, Africa, Brazil, Chile,South Africa,Zambia etc.
Sincerely welcome customers to visit our factory.
Our Services
One Stop solution for beneficiation plant service:
1.Engineering consulting available,it makes clients have a comprehensive understanding of beneficiation plant,including mine value,useful elements,mineral processing technology,plant scale,essential equipments,etc.
3.After reaching agreement with client,we start to engineering design,including planning,investigation,data collection, project evaluation etc. and then comes up with design scheme of beneficiation plant construction and working drawings.
1.Engineering consulting available,it makes clients have a comprehensive understanding of beneficiation plant,including mine value,useful elements,mineral processing technology,plant scale,essential equipments,etc.
2.Arrange mineral beneficiation experiment after received the material sample and beneficiation test report will be done after test.
3.After reaching agreement with client,we start to engineering design,including planning,investigation,data collection, project evaluation etc. and then comes up with design scheme of beneficiation plant construction and working drawings.
4.Manufacturing the necessary equipments and arrange the shipment.
5.Complete services for Installation and commissioning and technical training(operating training,common problem solving training).
After-sale Service
Regularly visit customers to provide after- sale technical supports and to solve problems of beneficiation plant. For equipments supplied,we could provide one-year warranty and provide spare parts with preferential price in the long term and be responsible for any problems with the them.
FAQ
Q: Are you a trading company or a factory?
A: We are a factory at Shicheng county with 110 workers,6 workshops covered 17,000㎡ and office covered 2,500㎡. Welcome to visit our factory at anytime.\t
A: We are a factory at Shicheng county with 110 workers,6 workshops covered 17,000㎡ and office covered 2,500㎡. Welcome to visit our factory at anytime.\t
Q: What is your payment terms?
A: By TT(Telegraphic Transfer), 100% or 40% Deposit before production and 60% balance payment will be paid off after sending product pictures and before loading from factory.
A: By TT(Telegraphic Transfer), 100% or 40% Deposit before production and 60% balance payment will be paid off after sending product pictures and before loading from factory.
Q: How long is the guarantee period of your products?
A: The guarantee period is 1-2 years, pls ask staff for more details. And we will supply lifelong technical support service and the spare parts at lowest cost.
Q: Is it possible to produce customized products ?
A: Yes, most of our products are produced as required.
A: Yes, most of our products are produced as required.
Q: Is it possible to provide sample for your factory to do ore-dressing experiment?
A: Yes, engineering consulting is available and we’d like to arrange mineral beneficiation experiment after received your sample and provide the test report.
A: Yes, engineering consulting is available and we’d like to arrange mineral beneficiation experiment after received your sample and provide the test report.
For more details, please refer to our website: www.gelinmachinery.com
