GFUVE FU2200A трехфазный многофункциональный измеритель энергии

GFUVE FU2200A трехфазный многофункциональный измеритель энергии

Категория: Power Meters >>>
Поставщик: Beijing,GFUVE,Electronics,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-15-2025	0.67 $*	0.13 $*
Aug-15-2025	0.41 $*	0.96 $*
Jul-15-2025	0.17 $*	0.26 $*
Jun-15-2025	0.88 $*	0.87 $*
May-15-2025	0.62 $*	0.64 $*
Apr-15-2025	0.29 $*	0.27 $*
Mar-15-2025	0.94 $*	0.53 $*
Feb-15-2025	0.5 $*	0.2 $*
Jan-15-2025	0.92 $*	0.38 $*

Характеристики

GFUVE FU2200A three phase energy data logger

Product Description

Introduction

The FU2200A three phase ethernet energy data logger is a range of economical yet highly functional three-phase multifunction power and energy meters manufactured by GFUVE. These meters p three phase power recorder rovide excellent value for monitoring power and energy management systems. The 2200A ethernet energy data logger may be used as data gathering devices for intelligent power distribution or plant automation systems. All monitored data is available via a standard digital RS485 communication port running the Modbus RTU protocol. With a wide range of models to choose from, the 2200A three phase ethernet energy data logger offers unparalleled value and functionality.

Features

True-RMS measuring Parameters.
ANSI and IEC 0.5s Accuracy class.
Power Quality Analysis.
4 Quadrant Energy;
4MB onboard memory;
Data logging
High-speed RS485, Ethernet Port (optional);
Measure Individual Harmonics from 2nd to 63th (optional);
Module Design;
TOU, 4 Tariffs, 6 Seasons, 8 Schedules
Class leading Warranty.
With management software

Applications

Metering of distribution feeders, transformers, generators, capacitor banks and motors.
Medium and low voltage systems.
Commercial, industrial, utility.
Power quality analysis.

Specifications

Parameter		Accuracy	Resolution	Range
Voltage		0.2%	0.01V	0.5~500kV
Current		0.2%	0.01mA	5mA~50000A
Active Power		0.5%	0.2W	-9999MW~+9999MW
Reactive Power		2%	0.2var	-9999Mvar~+9999Mvar
Apparent Power		0.5%	0.2VA	0~9999MVA
Active Power Demand		0.5%	0.2W	-9999MW~+9999MW
Reactive Power Demand		2%	0.2var	-9999Mvar~+9999Mvar
Apparent Power Demand		0.5%	0.2VA	0~9999MVA
Power Factor		0.005	0.0001	-1.0000~0~1.0000
Frequency		0.01Hz	0.01Hz	45.000~65.000Hz
Energy	Primary	0.5%	0.1kWh	0~99999999.9kWh
Energy	Secondary	0.5%	0.001kWh	0~999999.999kWh
Reactive Energy	Primary	2%	0.1kvarh	0~99999999.9kvarh
Reactive Energy	Secondary	2%	0.001kvarh	0~999999.999kvarh
Apparent Energy	Primary	0.5%	0.1VAh	0~99999999.9kVAh
Apparent Energy	Secondary	0.5%	0.001VAh	0~999999.999kVAh
Phase Angle		0.1°	0.01°	0~359.99°
Unbalance Factor		2%	0.01%	0~300.00%
PT			1	1~10000
CT			1	1~10000
Addr			1	1~254
