galvanized welded wire mesh Introduction

We supply welded wire mesh PVC coated ,electro galvanized or hot dipped galvanized. In the forms of rolls or panels, for construction, fences and other industrial uses. It enjoys the feature of corrosion resistance compared with plain welded wire mesh. Mainly used as fencing panels or further fabricated into wire partitions, wire container panels, wire baskets, welded wire fences, poultry fences and other welded products.



galvanized welded wire mesh Details Description



 Material :



Low carbon steel Q195, stainless steel wire.



surface treatment:

balck (mild steel wire)

electro galvanized ,(galvanized before welding, galvanzied after welding)

hot dip galvanized,  ,(galvanized before welding, galvanzied after welding)

pvc coated wleded wire mesh, (black wire mesh then pvc coated,electro gal. then pvc coated , hot dip gal.the pvc coated)

stainless steel welded wire mesh(SS302, SS304, SS304L) .



Features : smooth and trim mesh surface, solid and uniform structure and superior

integral performance, it won't loosen even subject to local cutting or pressure, It has the

characteristics of corrosion-resisting and oxidation-resisting





 specification of welded wire mesh

Welded Wire Mesh
Opening		Wire Diameter<BWG>
In inch	In metric unit(mm)
1/4" x 1/4"	6.4mm x 6.4mm	22,23,24
3/8" x 3/8"	10.6mm x 10.6mm	19,20,21,22
1/2" x 1/2"	12.7mm x 12.7mm	16,17,18,19,20,21,22,23
5/8" x 5/8"	16mm x 16mm	18,19,20,21,
3/4" x 3/4"	19.1mm x 19.1mm	16,17,18,19,20,21
1" x 1/2"	25.4mm x 12.7mm	16,17,18,19,20,21
1-1/2" x 1-1/2"	38mm x 38mm	14,15,16,17,18,19
1" x 2"	25.4mm x 50.8mm	14,15,16
2" x 2"	50.8mm x 50.8mm	12,13,14,15,16
Technical Note: 1,Standard roll length: 30m;width: 0.5m to 1.8m 2,Special sizes available at request 3,Packing: in waterproof paper in rolls. Custom packing available at request.



Galvanized Fencing Mesh
Opening		Wire Diameter<BWG>
In inch	In metric unit(mm)
2" x 3"	50mm x 75mm	2.0mm,2.5mm,1.65mm
3" x 3"	75mm x 75mm	2.67mm,2.41mm,2.11mm,1.83mm,1.65mm
2" x 4"	50mm x 100mm	2.11mm,2.5mm
4" x 4"	100mm x 100mm	2.0mm,2.5mm
Technical Note: 1,Standard roll length: 30m;width: 0.5m to 1.8m 2,Special sizes available at request 3,Packing: in waterproof paper in rolls. Custom packing available at request.



PVC Coated Welded Mesh
Opening		Wire Diameter<BWG>
In inch	In metric unit(mm)
1/2" x 1/2"	12.7mm x 12.7mm	16,17,18,19,20,21
3/4" x 3/4"	19mm x 19mm	16,17,18,19,20,21
1" x 1"	25.4mm x 25.4mm	15,16,17,18,19,20
Technical Note: 1,Standard roll length: 30m;width: 0.5m to 1.8m 2,Special sizes available at request 3,Packing: in waterproof paper in rolls. Custom packing available at request.





Application:



widely used in the industry ,agriculture ,construction,transport and mining .

Such as machine protection cover ,ranch fender ,garden fender ,window protection fender ,

passage fender ,fowl cage ,egg basket and foodstuffs basket.



For construction:

Used for cages:

Used for fence panel:

Uesd  for gabion box:

galvanized welded wire mesh Payment Terms

1. TT

2. LC

3. 30% TT payment in advance,70%TT paid after you got the B/L COPY

galvanized welded wire mesh Delivery Time & Packing

Packaging Details:  welded wire mesh roll /packing: is packed with waterproof paper inside and wrapped with plastic film outside. Pallet and wooden box can be used as the customer's require.

Delivery Detail:   welded wire mesh within 15 days after receive the deposit



galvanized welded wire mesh Quality Test

1. We will do the specialized quality checking during production and before in warehour or loading.

2. Customer check in person or SGS and any other third parties checking is acceptable.

3. ISO 9001 4001 AND TUV Certicification CE.
