Автоматическая машина для набивки меда соуса

Категория: Pharmaceutical Filling Machine >>>
Поставщик: Brightwin,packaging,machinery,Co.,Ltd

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-17-2025	0.53 $*	0.93 $*
Aug-17-2025	0.95 $*	0.64 $*
Jul-17-2025	0.41 $*	0.68 $*
Jun-17-2025	0.84 $*	0.67 $*
May-17-2025	0.22 $*	0.39 $*
Apr-17-2025	0.31 $*	0.97 $*
Mar-17-2025	0.99 $*	0.45 $*
Feb-17-2025	0.97 $*	0.59 $*
Jan-17-2025	0.74 $*	0.33 $*

Характеристики

automatic honey jar sauce peanut filling capping labeling machine

DETAILS

manufacturer sale honey jar filling capping labeling machine with VIDEO

program	automatic honey jar sauce peanut filling capping labeling machine
Filling head	2, 4, 6, 8, 10, 12, 16 etc(optional according to speed)
Filling volume	1-5000ml etc(customized)
Filling speed	200-6000bph(customized)
Filling precision	≤±1%
Power supply	110V/220V/380V/440V etc(customized) 50/60HZ
Power supply	≤1.5kw
Air pressure	0.6-0.8MPa
Net weight	400kg

manufacturer sale honey jar filling capping labeling machine with VIDEO

Specially designed thick sealing ring(Food grade Teflon material fromDupont USA), which is no need to replace within 3 years. As following picture:

2. Equipped with SUS316L long sepcial designed no–drip filing nozzles, which can protect the cylinder on the top being damaged by material. As following pictures:

3. 304 frame, 5mm thick SUS316L piston pump, manufactured by Taiwan producer

SUS 316L (6)

4. With sensor in each SUS316L rotary valve and filling nozzle, if there is any problem in any nozzle, it shows in touch screen, its easy to be found.

5. Japan Fuji Servo motor control, easy to adjust the volume, just need input the volume needed in touch screen.

Elements brands list

Item	Brands and material
sensor	transparent bottle sensor from Leuze Germany
PLC	SIEMENS
Touch screen	SIEMENS
Piston cylinder	5MM thick SUS316L
Rotary valve	SUS316L
Rotary valve connection	quick coupler designed from Germany
Filling nozzles	SUS316L stainless steel anti-drip quick-coupler design
Cylinder	Airtac Taiwan
Connecting pipe	fast loading pipe from Italy
Sealing ring	Edible PTFE from Dupont USA(no need replaced for three years)
electrical parts	Schneider
Rack	SUS304
bearings	Japan NSK, original imported
Level control in hopper	with
