Linan Xinhui Cable Co.,Ltd specialized in coaxial cable,bare wire,such like :RG6,RG59,RG11,RG58,silver wire,OCC wire,Silver plated copper,Nickel wire,CCS(copper clad steel wire),CCA(Copper clad aluminum wire),Al-mg wire,Enameled wire ,aluminum wire



  rg6 coaxial cable connectors



Specification :



1.02mm CCS + 4.57mm FPE + AL/ pet Foil Bonded + 64*0.16mm Al Braiding 60% coverage + 6.91mm PVC







Electrical Characteristics :



1) Characteristics Impedance:                          75+/- 3 Ohms



2) Capacitance Conductor to Shield:                  53.1 pF/m



3) Velocity of Propagation :                                 82%



4) Delay:                                                           4.065 ns/m



5) Min.Structural Return Loss (5-3000MHz) :      20 dB



6) Max. Attenuation :

Application:



1. High frequency line;2. Textile line;3. Micro cable;4.Audio equipment5.CCTV cable



6. RG-6 coaxial cable is used in the networks of satellite and cable television 7.Ect



4.Materials:



Conductor: Copper clad steel (CCS),Dielectric: low density cellular polyethylene



Shield: aluminum foil and copper wire braid,Jacket material: PVC (polyvinylchloride)





5.Question and Answer:





Q1.What kind of cable do u produce?





A1.We specialize in producing coaxial cable,lan cable,telephone cable,speaker cable,alarm cable etc.











Q2.What's ur MOQ?





A2.The MOQ of coaxial cable is 20KM,lan cable is 100boxes.









Q3.What's ur delivery time?





A3.Our delivery time is about 20days after comfriming the deposite or L/C ,it is based on the quantity of the order.











Q4.What's ur payment terms?





A4.Normally,we accept T/T in advance,other payment term,we can negociate with clients









Q5.What's ur trade term ?





A5.We can accept FOB,CIF,CFR term.









Q6.what's ur manner of packing ?





A6.Inner packing, 100m in PE film,100m/plastic or wooden drum,305m/wooden drum,500m/wooden drum or paper,shrink wrap





      Outer packing,Carton box,pull put box,pallet available





      Other packing can according to clients' demand.









Q7.Can ur factory customize cables base on clients' samples or data sheet ?





A7.Yes,we can.
