325 -3000mesh bentonite clay grinding mill in india:

—— five models: HGM80, HGM90, HGM100, HGM100A, and HGM125

——finished production fineness: 300meshes~3000meshes, 5-47 micron

——the capacity (ton/hour) ranges from 0.4T/H to 12T/H



 Application of 325 -3000mesh bentonite clay grinding mill in india:

HGM Series 325 -3000mesh bentonite clay grinding mill in india is the equipment specializing in producing fine and superfine powder of non-inflammable, non-explosive and brittle materials with Moh's hardness under six, such as calcite, chalk, limestone, dolomite, kaolin, bentonite, talc, mica, magnesite, illite, pyrophyllite and vermiculite, sepiolite, attapulgite, rectorite, diatomite, barite, gypsum, alunite, graphite, fluorite, rock phosphate, Kalium ore, pumice, etc., totally more than 100 kinds of materials.





Work Principle of 325 -3000mesh bentonite clay grinding mill in india:

HGM series 325 -3000mesh bentonite clay grinding mill in indiamainly consist of main unit, classifier, powder collector, dust cleaner, blower, muffler, sound-proof room, crusher, bucket elevator, storage hopper, and vibrating feeder.





Features of 325 -3000mesh bentonite clay grinding mill in india:

1.High Efficiency

Under the same finished final size and the same motor power, the capacity of 325 -3000mesh bentonite clay grinding mill in india is twice as much as jet mill, mixing grinder and ball mill, and energy consumption decreased 30%.

2.Long lifecycle of spare parts

The ring and roller are forged by special material with high utilization,the lifetime can reach 2-5 years for grinding calcite carbonate.

3.High safety and reliability

As no rolling bearings or screws in grinding cavity, there are no problems caused by bolts shedding or rapid wear of bearings and seal components.

4.High fineness, flexible adjustment

The final fineness of the grinding materials can be adjusted between 325 meshes and 2500 mesh (47-5 micron), and the product fineness can reach D97≤5μm.

5.Environment-friendly

The application of pulse bag filter and muffler greatly alleviates dust pollution and noise.

6.Advanced intelligent speed control device

Convenient adjusting, more uniform particle size.

Main specification of 325 -3000mesh bentonite clay grinding mill in india:

Model	HGM80	HGM90	HGM100	HGM100A	HGM125
Ring Diameter(mm)	800	930	1035	1035	1300
Ring Number (PCS)	3	3-4	3	4	4
Roller Number(PCS)	21	24-32	27	34-36	40-44
Main Shaft Speed (r. p. min)	230-240	200-220	180-200	180-200	135-155
Input Size (mm)	≤20
Finished Size (um)	5-47(325-2500)
Capacity (t/h)	0.5-4.5	0.6-6.5	0.7-7	1-8.5	1.5-12
Outlet Size L*W*H (m)	13.9*4*6.2	14.7*4.8*7.2	18*4.6*8.6	18*4.6*8.6	14*9*10.25
Motor powder (KW)	145-165	185-204	263	263-290	380-430

Note: This specification is just referencing, any changes are subject to the products.
