HS-50W 12V переключатель режима питания с одним выходом от переменного тока до постоянного инвертора сертификацией SGS CE ROHS TUV KC

HS-50W 12V переключатель режима питания с одним выходом от переменного тока до постоянного инвертора сертификацией SGS CE ROHS TUV KC

Категория: Инверторы и Преобразователи >>>
Поставщик: Zhejiang,Hengwei,Technology,Co.,Ltd.

Цена:5,33 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Aug-18-2025	6.23 $*	6.65 $*
Jul-18-2025	5.25 $*	5.17 $*
Jun-18-2025	6.6 $*	6.80 $*
May-18-2025	6.70 $*	6.71 $*
Apr-18-2025	5.93 $*	5.28 $*
Mar-18-2025	6.47 $*	6.52 $*
Feb-18-2025	6.17 $*	6.67 $*
Jan-18-2025	6.45 $*	6.14 $*

Характеристики

HS-50W 12V Switch Mode Power Supply Single Output Ac to Dc Inverter With SGS,CE,ROHS,TUV,KC,CCC Certification

Product Description

HS-50W series compact single switching power supply

Features:

·AC input voltage range selected by switch

·Small volume,low weight,high efficiency

·Protections:short circuit/over load

·cooling by free air convection

·LED indicator for power on

·100% full load burn-in test

·2 Years warranty

Model		HS-50-5	HS-50-12	HS-50-15	HS-50-24
output	DC voltage	5V	12V	15V	24V
	Voltage tolerance	±2%	±1%	±1%	±1%
	Rated current	7A	4.2A	3.4A	2.1A
	Current range	0~7A	0~4.2A	0~3.4A	0~2.1A
	Rated power	35W	50.4W	51W	50.4W
	Ripple&noise	80mvp-p	120mvp-p	120mvp-p	120mvp-p
	DCvoltage ADJ.range	-9%~+10%	±10%	±10%	±10%
input	Voltage range	90~132VAC/170~264VAC(selected by switch),235~373VDC
	frequency	47~63HZ
	AC current	1.3A/115VAC,0.65A/230VAC
	efficiency	80%	82%	82%	84%
	Inrush current	Cold start current 18A/115VAC,36A/230VAC
	Leakage current	< 1mA/240VAC
protection	overload	Rated output power115%~150% start over load protection
		protection type:hiccup mode,auto-recovery after fault condition is removed
	-----	-----
		-----
environment	Working temp,humidity	-10℃~+60℃,20%~90%RH
	Storage temp,humidity	-20℃~+85℃,10%~95%RH non-condensing
	Withstand vibration	10~500HZ,2G 10min/1cycle,period for 60 minutes,each axes
safety	Withstand voltage	I/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC
	Isolation resistance	I/P-O/P,I/P-FG,O/P-FG:100M ohms/500VDC
Fit standard	Safety standard	Compliance toUL1012
	EMC standard	Compliance toEN55022,CLASSA
others	Dimension	*1117836mm (LWH)*
	Weight/packing	0.26kg/50pcs/ 14kg/0.027 m³/0.96CUFT
note	1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. 3. Tolerance : includes set up tolerance, line regulation and load regulation.
