Scientz-10N сушильная машина для
- Категория: Freeze Drying Equipment >>>
- Поставщик: Ningbo,Scientz,Biotechnology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.79 $* | 0.52 $* |
| Aug-16-2025 | 0.86 $* | 0.73 $* |
| Jul-16-2025 | 0.61 $* | 0.74 $* |
| Jun-16-2025 | 0.72 $* | 0.51 $* |
| May-16-2025 | 0.22 $* | 0.89 $* |
| Apr-16-2025 | 0.64 $* | 0.98 $* |
| Mar-16-2025 | 0.5 $* | 0.61 $* |
| Feb-16-2025 | 0.58 $* | 0.22 $* |
| Jan-16-2025 | 0.91 $* | 0.37 $* |
Характеристики
Product Description
Product Video
Specification
Model | Scientz-10N | ||||||
Type | Ordinary | Top press | Ordinary multipipline | Top press multipipline | |||
Dryer area(㎡） | 0.125 | 0.08 | 0.125 | 0.08 | |||
Ability to capture water (kg/batch) | 3 | 3 | 3 | 3 | |||
Schering bottle quantity | 920 | 560 | 920 | 560 | |||
480 | 285 | 480 | 285 | ||||
260 | 165 | 260 | 165 | ||||
Eggplant shape bottle | / | / | 8 | 8 | |||
Plate load capacity (L) | 1.5 | 1 | 1.5 | 1 | |||
Plate size (mm) | Φ200 | Φ180 | Φ200 | Φ180 | |||
Plate distance(mm) | 70 | ||||||
Plate size (pc) | 4 | 3 | 4 | 3 | |||
Cold chmaber size (mm) | Φ250*150 | ||||||
Cold trap the lowest temperature （℃） | ≤-56(No load) | ||||||
Ultimate vacuum (Pa) | ≤-5(No load) | ||||||
Power (220V/50Hz) | 950 | ||||||
Ambient temperature (℃） | ≤25 | ||||||
Overall dimensions | 590（L)*460(W)*400(H)+400 | ||||||
Weight (KG) | 55 | 61 | 57 | 63 | |||
Special note | The device size and weight not included in the external vacuum pump.Top press model height not included in manual gland handle(The handle height 70mm) | ||||||
Feature
1. This machine adopts secop (former danfoss) compressor for refrigeration, refrigeration is rapid, cold well temperature is low
2. 7-inch true color touch LCD control system, easy to operate and powerful.
3. The control system automatically saves the freeze-drying data and can observe the whole process of freeze-drying in the form of real-time curve and historical curve.
4. Our unique spot heating calculation method, more stable heating, no overshoot, more accurate temperature control.
5. Equipped with inflatable valve, can be filled with dry inert gas.
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
FAQ
Our products provide one-year warranty service, within the warranty period, you can consult our customer service number if you have any questions.
