Винтовой компрессор 15 кВт 20 л.с. воздушный высокого давления

Винтовой компрессор 15 кВт 20 л.с. воздушный высокого давления

Категория: Air-Compressors >>>
Поставщик: Jiangxi,Fengshi,Compressor,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-17-2025	0.81 $*	0.83 $*
Aug-17-2025	0.53 $*	0.94 $*
Jul-17-2025	0.79 $*	0.19 $*
Jun-17-2025	0.20 $*	0.93 $*
May-17-2025	0.54 $*	0.7 $*
Apr-17-2025	0.41 $*	0.27 $*
Mar-17-2025	0.8 $*	0.13 $*
Feb-17-2025	0.26 $*	0.53 $*
Jan-17-2025	0.60 $*	0.15 $*

Характеристики

Screwcompressor 15kw 20hp screw air compressor 20hp 15kw aircompressor 15 kw 20 hp air compressor air compressor screw air price

Product Description

Name	Power Frequency Screw Air Compressor
Model	FS-20A
Power	15 KW / 20 HP
Pressure	0.8 Mpa / 8 bar / 115 psi
Flow	2.35 m³/min / 40 L/s / 80 CFM
Size	11007501000mm
Weight	350kg

All-in-one freeze dryer & filter & air tank

Parameters 7.5-400 KW Screw Compressor

Model Click On			Motor Power KW	Exhaust Volume Working Pressure (8 bar / 115 psi) Air Tank Capacity	Size (HLW) mm	Weight Kg
Power Frequency	Permanent Magnet Frequency Conversion		Motor Power KW		Size (HLW) mm	Weight Kg
FS 10	FY 7.5	7.5 KW	1.20 m³/min	920650900	240 Kg
FS 15	FY 11	11 KW	1.65 m³/min	11007501050	300 Kg
FS 20	FY 15	15 KW	2.35 m³/min	11007501050	340 Kg
FS 25	FY 18	18.5 KW	3.10 m³/min	13508701120	550 Kg
FS 30	FY 22	22 KW	3.62 m³/min	13508701120	550 Kg
FS 40	FY 30	30 KW	5.00 m³/min	13508701120	580 Kg
FS 50	FY 37	37 KW	6.50 m³/min	150010001300	700 Kg
FS 60	FY 45	45 KW	8.20 m³/min	150010001300	800 Kg
FS 75	FY 55	55 KW	9.80 m³/min	185013001550	1200 Kg
FS 100	FY 75	75 KW	13.5 m³/min	185013001550	1500 Kg
FS 120	FY 90	90 KW	15.5 m³/min	235016501800	1850 Kg
FS 150	FY 110	110 KW	19.7 m³/min	260016501800	1900 Kg
FS 175	FY 132	132 KW	23.2 m³/min	260016501800	2600 Kg
FS 160⁺	FY 160	160 KW	27.6 m³/min	290018002000	4100 Kg
FS 185⁺	FY 185	185 KW	30.0 m³/min	290018002000	4120 Kg
FS 200⁺	FY 200	200 KW	33.0 m³/min	290018002000	4180 Kg
FS 220⁺	FY 220	220 KW	40.0 m³/min	352022902030	6000 Kg
FS 250⁺	FY 250	250 KW	45.5 m³/min	352022902030	6000 Kg
FS 280⁺	FY 280	280 KW	51.5 m³/min	420023002300	7000 Kg
FS 315⁺	FY 315	315 KW	57.5 m³/min	420023002300	9000 Kg
FS 350⁺	FY 350	350 KW	63.0 m³/min	530023002300	9000 Kg
FS 400⁺	FY 400	400 KW	70.5 m³/min	530023002300	10000 Kg

Fengshi Air Compressor

WhatsApp: +86-181-6701-6615
WhatsApp: +86-198-1237-5292
WhatsApp: +86-135-6679-8008

Product Details Show

01 Screw Host

The screw air compressor host is from a famous brand of European which determined the excellent performance of the machine as a "strong heart'. According to the user's requirements, we can customize different specifications of "Screw Host" and assembly,For example:GHH, RC,Hanbell,BSC. Delivery time only needs 15-20 days

02 Screw Compressor Inlet Valve

Small power air compressor,Big power screw air compressor,Adopt different specifications to improve efficiency and reduce failure rate.None is easily damaged with an ON-OFF regulation and the adjusting range of tidal volume is 0 to 100%.It has small pressure loss and long operating life.At present,it is the most effective and reliable adjusting method of intake.

03 Main Motor

The screw air compressor motor adopts triphase high performance motor made by a famous brand with IP54 PROTECTION LEVEL,F insulation level and"SKF"heavy-duty bearing.The transmission efficiency up to 95%,whit good thermo-stability and long lifetime.

Customized Compressor

01 Customized In Japan & South Korea
