Кабель HDMI 8K с поддержкой 8K/60 Гц 4K/120 и разрешением до 10K полоса пропускания 48 Гбит/с для HDR

Описание и отзывы

Трекер стоимости

Характеристики

Real 8K HDMI Cable support 4K@120fps 8K@100/120fps up to 10K High Speed 48Gbps 7680P Dolby Vision, HDCP 2.2, 4:4:4 HDR v2.1



 V2.1 8K HDMI Cable is Ready.

Latest V2.1 HDMI cable.
Support 8K/60Hz, 4K/120Hz & up to 10K resolution, Dynamic HDR, eARC, ALLM, QFT, QMS, VRR. 48Gbps bandwidth for latest features HDR, HDCP 2.2 & 2.3, DTS:X, Dolby Atmos, Dolby Vision, which means immersive viewing, smooth fast-action detail and perfect Audio fidelity.

Particular structure and process for 8K.
V2.1 HDMI employ certified category 3 HDMI connector with shell inside and 29AWG high purity copper conductor to reach real 8K resolution and 48Gbps speed. Triple shielding layer for maximum performance and ultra low SNR.

Super quality material, classic design and Ultra Durability.
99.99% oxigine free bare copper conductor, thinkened gold-plated connector, high precision automatic welding, environmental PVC jacket, Al-alloy shell with laser printing, all these features give you better audio and vedio experience and long-term usage.

Wide Application.
8K HDMI compatible with Apple TV, LG TV, Samsung QLED TV, Nintendo Switch, Fire TV, Roku, Playstation,Sony 8K UHD TV, Blu-Ray, Laptop, PC, DVD, PS3, PS4 Pro, Xbox 360 , Xbox one S and Wii U, Tivo, Vizio, Blu-ray player, Projector,etc.

24 Months +12 Months Warranty.
Most other suppliers can give maximum 2 years warranty and our 8K HDMI cable allows 3 years quarrantee for your long time enjoyment with this purchase without any worry, due to our high standard production and strict QC.





Many other designs, please contact Vincent for update.





SPECIFICATIONS
Conductors	High purity Oxygen Free Bare Copper
Insulation	Outer Jacket and color optional
Contacts	24K Gold Plated  (V2.1 class)
Connectors	Zn or Al alloy Metal shell type   (V2.1 class)
Available lengths	V2.1 to 3m
Available terminations	HDMI,19PIN,Male to Male
Available gauge	24/26/28AWG(optional)  OD:9.0/8.0/7.3mm
Certification	RoHS,UL,CE
Shielding	AL+ Mg+ Braiding+ Ferrite(for option)
AWG	24/26/28/30 AWG available for different length



ELECTRICAL
Quality Control	operation according to regulations & rules in ISO9001:2008
Voltage	DC300V 5M ohm/10ms
Insulation Resistance	10M min
Contact Resistance	5 ohm max
Working Temperature	-25C-80C
Data transfer rate	48 Gbps Max.
Differential Impedance	100±10Ω(TDR)



FEATURES

1, Center conductor: high quality digital signal delivered by oxygen-free copper 2, Insulation: Using foamed PE as the insulation, ensure image quality and transmit image signal with stability. 3, Inner shield:100% Aluminum/Mylar foil shield, prevent high frequency noises and interference 4, Outer shield:95% AL+MG braid shield, prevents most low frequency noises and interference. 5, function: suitable for HDTV, home theater, DVD player,projector,PS3,XBOX 360 and other HDMI devices. 6, High density triple shielding for maximum rejection of EMI and RFI 7, Transfer speed: 48 Gbps 8, connectors: 24K gold-plated to ensure superior signal transfer and lifetime of maximum performance 9, Color optional: Pearl golden, Matter black, Silver, Golden, Shiny black, white porcelain, black porcelain, chromel AND MORE



PACKING

A: Bubble blister is your first choice to make your prodcts attractive B: Premium Slide Blister is competitive in price but catch customer's eyes C: Gift box packing to make your products more environmental D: Poly bag with card header and barcode number is low cost but good looking E. Customer's designs are available by request



Applications

1.digital TV 2.Plasma display 3.LCD display 4.DVD player/repeater 5.Audio/video receiver 6.Home video system 7.Satellite system



Factory Photo

Cable Factory for high quality and short delivery time





HDMI assembly Factory for mass production and competitive price









Certificate

We welcome the friends and customers to visit our factory at your convenient time, and Vincent look forward to have long-term cooperation with your esteemed company.



One Corner of our showroom



 Factory building





For more choices of HDMI cable, please send me inquiry now!
