PSE604GS 4 порта POE + 1 порт uplink SFP 65 Вт IEEE802.3at / af Стандартный гигабитный сетевой
- Категория: Network Switches >>>
- Поставщик: Shenzhen,Hongnaer,Electronic,Techonology,CO.,LTD
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 21.78 $* | 22.77 $* |
| Aug-17-2025 | 21.65 $* | 22.34 $* |
| Jul-17-2025 | 18.81 $* | 19.8 $* |
| Jun-17-2025 | 21.37 $* | 22.64 $* |
| May-17-2025 | 18.77 $* | 19.96 $* |
| Apr-17-2025 | 21.26 $* | 22.69 $* |
| Mar-17-2025 | 20.59 $* | 21.77 $* |
| Feb-17-2025 | 20.57 $* | 21.50 $* |
| Jan-17-2025 | 20.48 $* | 21.63 $* |
Характеристики
Products Description
PSE604GS 4 port POE + 1 port uplink + 1 port SFP 65W IEEE802.3at / af standard all gigabit POE network switch
Specification
The PSE604GS offers 5 10/100/1000Mbps RJ45 ports and 1 Gigabit SFP ports. The Gigabit SFP ports can be for 1000Base-SX/LX through
SFP (Small Factor Pluggable) interface. PSE604GS boasts a high performance switch architecture that is capable of providing
non-blocking switch fabric and wire-speed throughput as high as 12Gbps. Its built-in GbE uplink ports also offer incredible
extensibility, flexibility and connectivity to the Core switch or Servers.
Specification
The PSE604GS offers 5 10/100/1000Mbps RJ45 ports and 1 Gigabit SFP ports. The Gigabit SFP ports can be for 1000Base-SX/LX through
SFP (Small Factor Pluggable) interface. PSE604GS boasts a high performance switch architecture that is capable of providing
non-blocking switch fabric and wire-speed throughput as high as 12Gbps. Its built-in GbE uplink ports also offer incredible
extensibility, flexibility and connectivity to the Core switch or Servers.
Product Parameter
Hardware Specification | ||
Copper Ports | 5 10/100/1000Base-T RJ-45 Auto-MDI/MDI-X ports with IEEE 802.3af/at PoE | |
SFP/mini-GBIC Slots | 1 1000Base-SX/LX/BX SFP interfaces | |
Switch Architecture | Store-and-Forward | |
Switch Fabric | 12Gbps / non-blocking | |
Switch Throughput | 8.928Mpps@64 bytes | |
Address Table | 8K entries | |
Share Data Buffer | 4Mbytes | |
Flow Control | Back pressure for Half-Duplex IEEE 802.3x Pause Frame for Full-Duplex | |
LED | System: Power ,PoE In-Use ( yellow) 10/100 LINK / ACT(Green), 1000 LINK ( yellow) | |
Dimension (W x D x H) | 185*124*44mm , 1U height | |
Weight | 1 kg | |
Power Requirement | 100~240V AC, 50-60 Hz | |
Power Consumption / Dissipation | 65 Watts maximum | |
Power over Ethernet | ||
PoE Standard | IEEE 802.3af/at Power over Ethernet / PSE | |
PoE Power Supply Type | End-Span | |
PoE Power Output | Per Port 52V DC, af:350mA. Max. 18.2 Watts at:600mA. Max.31.2 Watts | |
Power Pin Assignment | 1/2(+), 3/6(-) | |
PoE Power Budget | 65Watts | |
PoE Ability | Number of PD @15.4W watts:4 | |
