Shantui землеройный толкатель Sd16 бульдозер 160 л.с. с электронным управлением
- Категория: Bulldozers >>>
- Поставщик: Shandong,Hengjianhang,Construction,Machinery,Co.,Ltd.Shandong,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 6263153.66 $* | 6576311.93 $* |
| Aug-16-2025 | 6210522.71 $* | 6521048.73 $* |
| Jul-16-2025 | 5210522.23 $* | 5471048.30 $* |
| Jun-16-2025 | 6105259.71 $* | 6410522.95 $* |
| May-16-2025 | 5315786.4 $* | 5581575.4 $* |
| Apr-16-2025 | 5999996.93 $* | 6299996.75 $* |
| Mar-16-2025 | 5947364.87 $* | 6244732.44 $* |
| Feb-16-2025 | 5894732.51 $* | 6189469.52 $* |
| Jan-16-2025 | 5842101.16 $* | 6134206.14 $* |
Характеристики
Company Profile
About Company
As a large-scale new energy electric vehicle export dealer, we have a comprehensive brand and a wide range of models, which can provide you with the most favorable price.
I look forward to answering your questions about new or used cars.
Click "Query" to get in touch with us!
Click "Query" to get in touch with us!
Products Description
Planetary power shift, forced lubrication transmission, hydraulic power steering system makes the machine operation light, with high transmission power and efficient production efficiency.
● Closed system, so that the water tank pressure to maintain a specific value, can improve the evaporation temperature and heat dissipation efficiency of cooling water. Fan power comes from the engine, and the forced air supply adds more cooling effect.
● Mainstream 14MPa working hydraulic system, stable work, with overload protection function, can greatly reduce the failure rate of hydraulic components.
● Mainstream 14MPa working hydraulic system, stable work, with overload protection function, can greatly reduce the failure rate of hydraulic components.
● The use of vehicle waterproof connector, new relay and overall injection molding instrument panel can effectively avoid electrical system faults, instrument box set air conditioning, electrical appliances, instruments as one, more beautiful and high-grade.
● The main frame of full box structure adopts steel plate welding full box integral structure, which is integrated with the rear bridge box welding, with a high impact load and bending resistance ability, high quality weld to ensure that the main frame has a full life cycle.
● The main frame of full box structure adopts steel plate welding full box integral structure, which is integrated with the rear bridge box welding, with a high impact load and bending resistance ability, high quality weld to ensure that the main frame has a full life cycle.
● Eight-character beam swing type, balance beam suspension structure, connect the frame and walking system, can transfer the working load and impact load to the main frame, effectively improve in the complex Stability in miscellaneous working conditions
Exhibition
Product Paramenters
Type section | SD16 |
Long, X, width, X height (mm) (excluding soil) | 4990X 3440X 3110 |
Weight used (excluding loosening) (kg) | 16400 |
engine type | WD10G178E25 WP10G178E355 |
Power / rated turn quantity (kw/rpm） | 131/1850 |
Ground length and ground specific pressure (MPa) | 2430 |
0.067 | |
Climbing performance of (°) | 30 |
Number of track boards (on each side) | 37 |
Crawle plate width (mm) | 510 (560、610) |
Crawler center distance (mm) | 1880 |
Chain rail pitch (mm) | 203.2 |
Number of carriers (each side) | 2 |
Number of heavy wheel bearings (each side) | 6 |
Shovel knife type | Straight shovel |
Shovel length x high (mm) | 3440X 1135 |
Shovel blade capacity (m³) | 4.5 |
Shoade lift height (mm) | 1095 |
Shovel depth (mm) | 540 |
Relaxed soil type | Three teeth |
Depth (mm) | 570 |
Looiser lifting height (mm) | 600 |
Forward speed (km/h) | F1:0~3.29 |
F2:0~5.82 | |
F3:0~79.63 | |
Backgear speed (km/h) | R1:0~4.28 |
R2:0~7.59 | |
R3:0~12.53 |
