100V 30A Battery Pack Life Cycle Tester Charge and Discharge System

Application and Function



100V 30A battery pack life cycle tester is mainly used for circle life testing and quality control of li-ion battery, lead-acid battery, Ni-Cd battery, NiMH battery and so on in production line or in lab.

Support battery circle life testing, capacity testing, charging characteristic testing, discharging characteristic testing, charge retention capability testing, charge and discharge efficiency testing, over charge or over discharge rate affordability testing.



Equipment configuration list





No.	Category	Product name	Product model	Quantity	Remarks
1	Test equipment	Charge and discharge test equipment	ACEY-HRCDS-100V30A	18CH
2	Cabinet	Charging and discharging equipment cabinet	/	1PCS	Default without power input line
3	Computer	Computer	Dell computer I5-10500 processor / 16G memory /256G solid state + 1T hard disk /3 network port	1PCS	Optional, including mouse, keyboard and 19 inch AOC displayer
4	Accessories	Charge discharge test line	/	18PCS	Each channel has a set of test lines with a length of 3.5meters.(including fixture)
5	Accessories	Switch	TP-LINK TL-SF1008VE	1PCS	Single cabinet without switch
6	Accessories	Communication accessories	Communication line / Crystal head, etc.	Several	For communication
7	Accessories	USB Flash Drive	16G	1PCS	Contains Test software etc.
8	Accessories	File	/	1PCS	Test report, packing list, etc.



Working Environment and Technical Parameters

1. Power supply of the whole cabinet: AC 380V±10%, frequency: 50HZ±5%.


2. Maximum input power of the whole cabinet: 60.0 kW (18CH)


3. Working temperature: 0℃~ 45℃.


4. Humidity: less than ≤ 85%R.H (non-condensing).


5. No severe shake, no corrosive gases, no flammable or explosive gases around.


6. Resolution: AD 16 bit.



No.	Item		ACEY-HRCDS-100V30A
1	Main channels		1CH/ module
2	Channel working mode		Completely independent
3	Main channel working mode		Charge: CC, CV, CCCV,  no voltage or current impact when CC transfer to CV
			Discharge: CD, CP, CR
			Still
	Main channel test cutoff condition		Time, total voltage, total current, capacity, -ΔV, Vcell, RSOC, etc.
4	Main channel Voltage	Single channel test range	0V-100V
		Min. discharge voltage	6V
		Accuracy	±0.05%FS+0.05%RD
		Resolution	1mV
	Main channel Current	Single channel test range	±30A
		Min. output current	60mA
		Accuracy	±0.05%FS+0.05%RD
		Resolution	1mA
		Current start response time	<10ms(10%FS~90%FS)
	Time	Resolution	1s
	Auxiliary voltage (Optional)	Range	DC:0-5V
		Accuracy	±0.05%FS
		Resolution	1mV
	Auxiliary temperature (Optional)	Range	-20℃~100℃
		Accuracy	±1℃(0℃~80℃)
		Resolution	0.1℃
	Power	Output power	Single channel continuous working power 3000W.
		Stability	±0.1%FS+0.1%RD
5	Communication		LAN
	Battery BMS communication		Support CAN 2.0A, CAN 2.0B; RS485 communication;
			Support DBC import, realize data reading with BMS CAN, and participate in process control
