AOHUA кабель решение DC адаптер папа 5 5*2 1/5 мм быстрое подключение 12 В dc разъем питания для
- Категория: Connectors & Terminals >>>
- Поставщик: Shenzhen,Aohua,Electric,Corporation,Limited
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 0.34 $* | 0.20 $* |
| Aug-18-2025 | 0.32 $* | 0.3 $* |
| Jul-18-2025 | 0.26 $* | 0.14 $* |
| Jun-18-2025 | 0.46 $* | 0.66 $* |
| May-18-2025 | 0.11 $* | 0.30 $* |
| Apr-18-2025 | 0.92 $* | 0.73 $* |
| Mar-18-2025 | 0.36 $* | 0.99 $* |
| Feb-18-2025 | 0.22 $* | 0.71 $* |
| Jan-18-2025 | 0.76 $* | 0.86 $* |
Характеристики
Product Description
AOHUA Y Type waterproof Connector
Description | Y Type PVC 01 | Y Type PVC 02 | Y Type PVC 03 | ||||||||
Pins | Part Number | Pins | Part Number | Pins | Part Number | ||||||
2 | AH-YP01-020X | 2 | AH-YP02-020X | 2 | AH-YP03-020X | ||||||
3 | AH-YP01-030X | 3 | AH-YP02-030X | 3 | AH-YP03-030X | ||||||
4 | AH-YP01-040X | 4 | AH-YP02-040X | 4 | AH-YP03-040X | ||||||
Main Cable Gauge | ≤0.5mm² | ≤1.0mm² | ≤1.5mm² | ||||||||
Branch Cable Gauge | ≤0.3mm² | ≤0.5mm² | ≤1.0mm² | ||||||||
Main Cable OD | Max 4.0mm | Max 6.8mm | Max 8.3mm | ||||||||
Branch Cable OD | Max 3.0mm | Max 5.0mm | Max 6.8mm | ||||||||
Operating Rating | -20℃~+80℃ | ||||||||||
Waterproof Level | IP65 | ||||||||||
The YP03 multiple branch Y type waterproof cable connector. In this cable solutions, Y splitter are usually connectors with male and female connectors. Such as, the main cable will be molded with the female connector, the branch cables will be molded with male connectors. The wire size is 2*24AWG, the cable length is customized.
There are 2pin, 3pin, and 4pin for this splitters, And its can customized for 2 branches, 3 branches, and 4 branches. main cable wire gauge is ≤1.5mm² (cable OD not exceed 8.3mm), the branch wire gauge is ≤ 1.0mm²(cable OD not exceed 6.8mm).
There are many waterproof connectors to molded for this Y type splitter, such as M10 M12, M14 and M16 connectors.
How to choose the right Y splitter, you just need to tell us the wire gauge, cable length, number of branches and cable connection, we will advise. We also welcome you offer the simple drawing you want, we will give you the professional solution and drawing.
There are 2pin, 3pin, and 4pin for this splitters, And its can customized for 2 branches, 3 branches, and 4 branches. main cable wire gauge is ≤1.5mm² (cable OD not exceed 8.3mm), the branch wire gauge is ≤ 1.0mm²(cable OD not exceed 6.8mm).
There are many waterproof connectors to molded for this Y type splitter, such as M10 M12, M14 and M16 connectors.
How to choose the right Y splitter, you just need to tell us the wire gauge, cable length, number of branches and cable connection, we will advise. We also welcome you offer the simple drawing you want, we will give you the professional solution and drawing.
Description | Y Type PVC 04 | Y Type PVC 05 | Y Type PVC 06 | Y Type PVC 07 | |||||
Pins | Part Number | Part Number | Part Number | Part Number | |||||
2 | AH-YP04-020X | AH-YP05-020X | AH-YP06-020X | AH-YP07-020X | |||||
3 | AH-YP04-030X | AH-YP05-030X | AH-YP06-030X | AH-YP07-030X | |||||
4 | AH-YP04-040X | AH-YP05-040X | AH-YP06-040X | AH-YP07-040X | |||||
Main Cable Gauge | ≤0.5mm² | ≤1.0mm² | ≤2.5mm² | ≤2.5mm² | |||||
Branch Cable Gauge | ≤0.3mm² | ≤0.5mm² | ≤1.5mm² | ≤1.5mm² | |||||
Main Cable OD | Max 5.0mm | Max 8.4mm | Max 9.5mm | Max 9.5mm | |||||
Branch Cable OD | Max 4.5mm | Max 5.0mm | Max 8.3mm | Max 8.3mm | |||||
Operating Rating | -20℃~+80℃ | ||||||||
Waterproof Level | IP65 | ||||||||
Y type splitter is a kind of multiple cables splitter, which is one cable input and multiple branch cables output. As usual, this splitter will be designed 1 input 2 3 4 5 outputs, the main cable with connectors and branch cable with connectors or the main cable and branch cables are without connectors but with bare cables.
The splitter size is length 58mm*wide 37mm*high 21mm, The main cable wire size is Less than or equal to 2.5mm², branch cable wire size is less than or equal to 1.5mm²; the main cable OD is not exceed 10mm, the branch cable is not exceed 8.3mm. This splitter is suitable for 2pin 3pin and 4pin.
In this example, the main cable designed without connector and branch cable designed with female connectors, the main cable and branch cable wire sizes are 2*0.75mm².
The splitter size is length 58mm*wide 37mm*high 21mm, The main cable wire size is Less than or equal to 2.5mm², branch cable wire size is less than or equal to 1.5mm²; the main cable OD is not exceed 10mm, the branch cable is not exceed 8.3mm. This splitter is suitable for 2pin 3pin and 4pin.
In this example, the main cable designed without connector and branch cable designed with female connectors, the main cable and branch cable wire sizes are 2*0.75mm².
Description | Y Type PVC 08 | Y Type PVC 09 | Y Type PVC 10 | Y Type PVC 11 | |||||
Part Number | Pins | Part Number | Part Number | Part Number | Part Number | ||||
2 | AH-YP08-020X | AH-YP09-020X | AH-YP10-020X | AH-YP11-020X | |||||
3 | AH-YP08-030X | AH-YP09-030X | AH-YP10-030X | AH-YP11-030X | |||||
4 | AH-YP08-040X | AH-YP09-040X | AH-YP10-040X | AH-YP11-040X | |||||
Main Cable Gauge | ≤1.5mm² | ≤2.5mm² | ≤2.5mm² | ≤1.5mm² | |||||
Branch Cable Gauge | ≤1.0mm² | ≤1.5mm² | ≤2.5mm² | ≤0.75mm² | |||||
Main Cable OD | Max 8.3mm | Max 9.5mm | Max 10.0mm | Max 7.8mm | |||||
Branch Cable OD | Max 8.0mm | Max 8.3mm | Max 10.0mm | Max 5.5mm | |||||
Operating Rating | -20℃~+80℃ | ||||||||
Waterproof Level | IP65 | ||||||||
YP 09 Y type splitter is the multiple cables designed solution, which is one cable input and multiple branch cables output. it will be designed in 2 to 6 output cables. its size is length 64mm*wide 50mm*high 15mm. The main cable wire size is Less than or equal to 2.5mm², branch cable wire size is Less than or equal to 1.5mm²; the main cable OD is not exceed 9.5mm, the branch cable is not exceed 8.3mm. This splitter is suitable for 2pin 3pin and 4pin.
Before quotation, please let me know the wire size, cable length, the number of branch cables and etc. For example, the main cable wire size is 2*1.5mm², length 500mm; branch cable wire size 2*1.0mm², length 300mm. There are 3 output cables. The main cable with male connector, the branch cable with female connector.
This Y type splitter is used to the power wire layout in plant grow lighting, led lighting, feeding system, and so on.
Before quotation, please let me know the wire size, cable length, the number of branch cables and etc. For example, the main cable wire size is 2*1.5mm², length 500mm; branch cable wire size 2*1.0mm², length 300mm. There are 3 output cables. The main cable with male connector, the branch cable with female connector.
This Y type splitter is used to the power wire layout in plant grow lighting, led lighting, feeding system, and so on.
1. Current rating, such as: 4A...
2. Pins, such as : 2pin, 3pin...
3. Wire size, such as: main cable 2*20AWG, branch cable 2*22AWG.
4. Length of each cable, such as: 300mm.
2. Pins, such as : 2pin, 3pin...
3. Wire size, such as: main cable 2*20AWG, branch cable 2*22AWG.
4. Length of each cable, such as: 300mm.
