Фабрика Intel core 12th i3 i5 i7 DDR5 Type-C HD WIFI доска для встреч мини-ПК
- Категория: Motherboards >>>
- Поставщик: Shenzhen,Piesia,Electronic,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-17-2025 | 146.31 $* | 149.56 $* |
| Jul-17-2025 | 118.46 $* | 120.82 $* |
| Jun-17-2025 | 144.16 $* | 147.54 $* |
| May-17-2025 | 143.55 $* | 146.42 $* |
| Apr-17-2025 | 114.21 $* | 116.52 $* |
| Mar-17-2025 | 140.83 $* | 143.20 $* |
| Feb-17-2025 | 139.61 $* | 142.5 $* |
| Jan-17-2025 | 138.98 $* | 141.86 $* |
Характеристики
Products Description
* Onboard Intel Core 12thAlder Lake-U/-P/13th Raptor lake Series processor
* 1*DDR5 SO-DIMM，Onboard Ram optional，max support 48GB
* 0optional
* Display Output：HDMI0/MiniDP/Type-C
* 2*2，2*USB2.0
* DC 12-19V； Size：180x119x30mm.
* 1*DDR5 SO-DIMM，Onboard Ram optional，max support 48GB
* 0optional
* Display Output：HDMI0/MiniDP/Type-C
* 2*2，2*USB2.0
* DC 12-19V； Size：180x119x30mm.
Processor | Onboard Intel 12th Alder Lake-U/-P/13th Raptor lake Series processor |
EFI BIOS | |
TPM2.0 | CPU built-in, optional external TPM2.0 |
Ram | 1*DDR5 SO-DIMM，Onboard Ram optional，max support 48GB |
Storage | 1*M.2 M-Key 2280，NVMe PCIe 4.0 x4 protocol，SATA3.0 protocol optional |
1*2.5inch HDD port (with SATA3.0 choose one of two) | |
1* SATA3.0 interface, 2Pin 5V (alternative to 2.5-inch HDD) | |
Display | 1*HDMI2.0 interface supporting 4096x2160@60Hz. |
1*Mini DP, supporting 4096x2160@60Hz. | |
1*Type-C, supporting double-sided USB3.1 and DP 4K and 5V 3A outputs. | |
Support synchronous or asynchronous display | |
I/O interface | 1*Mini DP, 1 HDMI2.0, 2 USB3.0, 2 USB2.0. |
1*LAN(RTL8111 network, optional Intel i219) | |
1*power indicator, 1 hard disk indicator, 1 switch button, 1 reset button. | |
1*Type-C | |
1*Mic-in, 1 Line-out | |
1*DC JACK power interface | |
Extended interface/function | 1*M.2 E-Key(PCIe 3.0+USB2.0 protocol, supporting WIFI/BT module) |
1*M.2 B-Key(USB2.0+USB3.0 protocol, supporting 4G/5G modules) | |
1*set of 8-bit GPIO pins, 2x5Pin, with a spacing of 2.0mm | |
1*set of RS232 stitches, 2x5Pin, with a spacing of 2.0mm | |
1*4Pin SYS FAN, 1 4Pin CPU FAN | |
OS system | Windows10，Windows11，Linux |
Colour | Black |
Size | 180x119x30mm |
Wight | The net weight is about 750g, and the packaged gross weight is about 800g |
Details Images
company information
Certifications
Our Services
1.Quality: we check every product carefully before the delivery, and provide 2 years warranty time, if you find problems please contact us in time.
2.Design: we could do design as customer requirement.
3.Packages: the carton with your own logo are available.
4.Other Support: about the product performance and safety knowledge, you also can consult our engineer
2.Design: we could do design as customer requirement.
3.Packages: the carton with your own logo are available.
4.Other Support: about the product performance and safety knowledge, you also can consult our engineer
Packing & Delivery
Exhibition
FAQ
Q1: What is the Warranty for your pc?
A1: For the pc, we have 2 years warranty.
Q2: How to do if any quality problems on your side in the warranty time?
A2: First, take pictures or videos as proof and send to us. We will replace new ones for free or Returned to our factory for free maintenance.
A1: For the pc, we have 2 years warranty.
Q2: How to do if any quality problems on your side in the warranty time?
A2: First, take pictures or videos as proof and send to us. We will replace new ones for free or Returned to our factory for free maintenance.
Q3: Are you a manufacturer?
A3: Yes, we are ODM and OEM and we have our own factory and professional engineers to meet your any requirements. Welcome to visitour factory.
Q4: What kind of payment do you support?
A4: T/T West union paypal
Q5: Can we get support if we have our own market position?
A5: Please inform us your detailed market demand,we will discuss and propose helpful suggestion for you,to find the best solution for you.
Q6: Is there any cheap shipping cost to import to our country?
A6:Cheaper Express: Postal parcel for small samples Faster
Express: DHL TNT UPS by air for samples and middle order
Reasonable Express: delivery by sea for large order
Q7: How many days will samples be finished? And how about the mass production?
A7: Generally 3-5Working days after payment for samples. The leading time of mass production will depend on the quantity.
A3: Yes, we are ODM and OEM and we have our own factory and professional engineers to meet your any requirements. Welcome to visitour factory.
Q4: What kind of payment do you support?
A4: T/T West union paypal
Q5: Can we get support if we have our own market position?
A5: Please inform us your detailed market demand,we will discuss and propose helpful suggestion for you,to find the best solution for you.
Q6: Is there any cheap shipping cost to import to our country?
A6:Cheaper Express: Postal parcel for small samples Faster
Express: DHL TNT UPS by air for samples and middle order
Reasonable Express: delivery by sea for large order
Q7: How many days will samples be finished? And how about the mass production?
A7: Generally 3-5Working days after payment for samples. The leading time of mass production will depend on the quantity.
