USG6510F-D-AC USG6500F-D серии настольная модель нового поколения
- Категория: Firewall & VPN >>>
- Поставщик: Beijing,Tongruida,Information,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 1190.68 $* | 1250.96 $* |
| Aug-15-2025 | 1180.4 $* | 1239.74 $* |
| Jul-15-2025 | 990.45 $* | 1040.67 $* |
| Jun-15-2025 | 1160.19 $* | 1218.75 $* |
| May-15-2025 | 1010.4 $* | 1061.78 $* |
| Apr-15-2025 | 1140.16 $* | 1197.39 $* |
| Mar-15-2025 | 1130.52 $* | 1187.35 $* |
| Feb-15-2025 | 1120.54 $* | 1176.45 $* |
| Jan-15-2025 | 1110.0 $* | 1166.31 $* |
Характеристики
Product Description
With new hardware and software architectures,HiSecEngine USG6500F series, in either desktop or 1 U models, are next-generation AI firewalls that feature intelligent defense, outstanding performance, and simplified O&M, effectively addressing the preceding challenges. The USG6500F series uses intelligence technologies to enable border defense to accurately block known and unknown threats. Equipped with multiple built-in security dedicated acceleration engines, the USG6500F series firewalls support enhanced forwarding, content security detection, and IPsec service processing acceleration. The security O&M platform implements unified management and O&M of multiple types of security products, such as firewalls, IPS devices, and anti-DDoS devices, reducing security O&M OPEX. In addition, the USG6500F-DL series support the LTE function, which ,can be used to implement flexible, efficient, and fast network deployment in remote areas or mobile office scenarios.
Model | USG6510F-D | USG6530F-D | USG6510F-DL | USG6530F-DL | ||||
IPv4 Firewall Throughput1 (1518/512/64-byte, UDP) | 2.5/2.5/2.5 Gbps | 5/5/3.6 Gbps | 2.5/2.5/2.5 Gbps | 5/5/3.6 Gbps | ||||
IPv6 Firewall Throughput1 (1518/512/84-byte, UDP) | 2.5/2.5/2.5 Gbps | 5/5/3.6 Gbps | 2.5/2.5/2.5 Gbps | 5/5/3.6 Gbps | ||||
Firewall Throughput (Packets Per Second) | 3.75 Mpps | 5.4 Mpps | 3.75 Mpps | 5.4 Mpps | ||||
Firewall Latency (64-byte, UDP) | 18 us | 18 us | 18 us | 18 us | ||||
FW + SA* Throughput2 | 1.8 Gbps | 2.2 Gbps | 1.8 Gbps | 2.2 Gbps | ||||
NGFW Throughput (HTTP 100K)3 | 1.6 Gbps | 1.8 Gbps | 1.6 Gbps | 1.8 Gbps | ||||
NGFW Throughput (Enterprise Mix)4 | 800 Mbps | 900 Mbps | 800 Mbps | 900 Mbps | ||||
Threat Protection Throughput (HTTP 100K)7 | 1.3 Gbps | 1.5 Gbps | 1.3 Gbps | 1.5 Gbps | ||||
Threat Protection Throughput (Enterprise Mix)5 | 700 Mbps | 800 Mbps | 700 Mbps | 800 Mbps | ||||
Concurrent Sessions | 300,000 | 500,000 | 300,000 | 500,000 | ||||
IPv6 Concurrent Sessions1 | 200,000 | 500,000 | 200,000 | 500,000 | ||||
New Sessions/Second (HTTP1.1)1 | 20,000/s | 30,000 | 20,000 | 30,000 | ||||
IPv6 New Sessions/Second (HTTP1.1)1 | 8000/s | 30,000 | 8000 | 30,000 | ||||
IPsec VPN Throughput1 (AES-256 + SHA256, 1420-byte) | 2 Gbps | 3.7 Gbps | 2 Gbps | 3.7 Gbps | ||||
Maximum IPSec VPN Tunnels (GW to GW) | 1,000 | 2,000 | 1,000 | 2,000 | ||||
Maximum IPsec VPN Tunnels (Client to GW) | 1,000 | 2,000 | 1,000 | 2,000 | ||||
SSL VPN Throughput6 | 200 Mbps | 300 Mbps | 200 Mbps | 300 Mbps | ||||
Concurrent SSL VPN Users (Default/Maximum) | 100/100 | 100/500 | 100/100 | 100/500 | ||||
Security Policies (Maximum) | 3,000 | 3,000 | 3,000 | 3,000 | ||||
Virtual Firewalls | 10 | 20 | 10 | 20 | ||||
URL Filtering: Categories | More than 130 | |||||||
URL Filtering: URLs | A database of over 200 million URLs in the cloud | |||||||
Third-Party and Open-Source Ecosystem | Open API for integration with third-party products, providing NETCONF interfaces Other third-part management software based on SNMP, SSH, and Syslog | |||||||
VLANs (Maximum) | 4094 | |||||||
VLANIF Interfaces (Maximum) | 4094 | |||||||
Dimensions (W×D×H) mm | 250×210×43.6 | 320×220×43.6 | ||||||
Form Factor/Height | Desktop | |||||||
Fixed Interface | 10×GE RJ45 + 2×GE SFP | 10×GE RJ45 + 2×10GE SFP+ | 4×GE SFP + 8×GE RJ45 + LTE | 2×10GE SFP+ + 2×GE SFP + 8×GE RJ45 + LTE | ||||
USB Port | 1×USB 2.0 | |||||||
Weight | 1.55 kg | 2.34 kg | ||||||
External Storage | Optional, 64 GB microSD card available for purchase | |||||||
Power Supply | 100 V to 240 V, 50 Hz/60 Hz | |||||||
Maximum power consumption of the machine | 36 W | 46.5 W | ||||||
Power Supplies | Single power supply | |||||||
Operating Environment (Temperature/Humidity) | Temperature: 0°C to 45°C Humidity: 5% to 95%, non-condensing | |||||||
Non-operating Environment | Temperature: -40°C to +70°C Humidity: 5% to 95%, non-condensing | |||||||
1. Performance is tested under ideal conditions based on RFC2544, 3511. The actual result may vary with deployment environments. 2. SA performances are measured using 100 KB HTTP files. 3. NGFW throughput is measured with Firewall, SA, and IPS enabled; the performance is measured using 100 KB HTTP files. 4. NGFW throughput is measured with Firewall, SA, and IPS enabled; the performance is measured using the Enterprise Mix Traffic Model. 5. The threat protection throughput is measured with Firewall, SA, IPS, and AV enabled; the performance is measured using the Enterprise Mix Traffic Model. 6. SSL VPN throughput is measured using TLS v1.2 with AES128-SHA. 7. NGFW throughput is measured with Firewall, SA, IPS, and AV enabled, the performances are measured using 100 KB HTTP files. *SA: indicates service awareness. | ||||||||
Specification
Software Features | Description |
Integrated protection | Integrates firewall, VPN, intrusion prevention, antivirus, bandwidth management, Anti-DDoS, URL filtering; provides a global configuration view; manages policies in a unified manner. |
Application identification and control | Identifies over 6000 applications and supports the access control granularity down to application functions; combines application identification with intrusion detection, antivirus, and data filtering, improving detection performance and accuracy |
Intrusion prevention and web protection | Obtains the latest threat information in a timely manner for accurate detection and defense against vulnerability-based attacks. Supports coverage of tens of thousands of Common Vulnerabilities and Exposures (CVE). Detects malicious traffic, such as vulnerability attack traffic, web attack traffic (such as SQL injection and cross site scripting attacks), botnets, remote control, and Trojan horses, and supports brute-force attack detection. Supports 13,000+ IPS signatures, and supports user defined signatures. The default IPS blocking rate is up to 85%. Supports brute-force cracking detection based on user behaviors, and user-defined statistical periods. |
Anti-botnet | Supports detecting Botnet traffic by using the intrusion prevention function. |
Antivirus | Supports intelligent, heuristic antivirus engine that can detect hundreds of millions of virus variants. And supports the detection of files compressed in 100 layers. |
Anti-spyware | Supports detecting spyware by using the antivirus engine. |
Bandwidth management | Manages per-user and per-IP bandwidth based on service application identification, ensuring the network experience of key services and users. The management and control can be implemented by limiting the maximum bandwidth, guaranteeing the minimum bandwidth, and changing the application forwarding priority. |
URL filtering | Provides a URL category database with over 200 million URLs and accelerates access to specific categories of websites, improving access experience of high-priority websites. Supports DNS filtering, in which accessed web pages are filtered based on domain names. Supports the anti-phishing URL filter. Supports the SafeSearch function to filter resources of search engines, such as Google, to guarantee access to only healthy network resources. |
Intelligent uplink selection | Supports service-specific PBR and intelligent uplink selection based on multiple load balancing algorithms (for example, based on bandwidth ratio and link health status) in multi-egress scenarios. |
VPN encryption | Supports multiple highly available VPN features, such as IPsec VPN, SSL VPN and GRE. |
Anti-DDoS | Defends against more than 10 types of common DDoS attacks, including SYN flood and UDP flood attacks. (Note: Desktop models USG6500F-D and USG6500F-DL do not support the Anti DDoS functions.) |
Security virtualization | Supports virtualization of multiple types of security services, including firewall, intrusion prevention, antivirus, and VPN. Users can separately conduct personal management on the same physical device. |
Security policy management | Manages and controls traffic based on VLAN IDs, quintuples, security zones, regions, applications, URL categories, and time ranges, and implements integrated content security detection. Provides predefined common-scenario defense templates to facilitate security policy deployment. |
Routing | Supports multiple types of routing protocols and features, such as RIP, OSPF, BGP, IS-IS, RIPng, OSPFv3, BGP4+, and IPv6 IS-IS. |
Deployment and reliability | Supports transparent, routing, and hybrid working modes and high availability (HA), including the Active/Active and Active/Standby modes. |
Asset management | Provides asset-based threat visualization, which supports associating IPS and Antivirus threat logs with user assets and displaying asset risk assessment results. |
