Дорожный скользящий бетонный бордюр и водосточный
- Категория: Road Machinery >>>
- Поставщик: China,Vastness,Machinery,Co.,Ltd.China,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.91 $* | 0.80 $* |
| Aug-19-2025 | 0.70 $* | 0.88 $* |
| Jul-19-2025 | 0.44 $* | 0.31 $* |
| Jun-19-2025 | 0.34 $* | 0.14 $* |
| May-19-2025 | 0.43 $* | 0.9 $* |
| Apr-19-2025 | 0.44 $* | 0.86 $* |
| Mar-19-2025 | 0.88 $* | 0.24 $* |
| Feb-19-2025 | 0.89 $* | 0.45 $* |
| Jan-19-2025 | 0.47 $* | 0.50 $* |
Характеристики
Product Description
road slipforming concrete curb and gutter slipform kerbing paving machine
Specification
| Model | RW—50S | RW—300K | RW-5000M | RW—6000L | RW—1100MINI | RW—2000L | RW-2800L |
| Drive mode | Single motor rear drive - dual drive | Single motor mid-mounted four-wheel drive | Dual motor dual control dual drive | Dual motor dual control dual drive | Dual motor dual control dual drive | Dual motor dual control dual drive | Dual motor dual control dual drive |
| Weight | 2 tons | 5.8 tons | 6.8 tons | 9.8 tons | 11 tons | 15 tons | 20 tons |
| Forming method | Vibration | Vibration | Vibration | Vibration | Vibration | Vibration | Vibration |
| Vibrator Style | 1 drag 2 high-frequency vibrators + 2 sets of ordinary vibrators | Adjustable speed high-frequency vibrator (standard one for four) hybrid mechanical vibrator | Adjustable speed high-frequency vibrator (standard one for six) hybrid mechanical vibrator | Adjustable speed high frequency vibrator (standard one for six) hybrid mechanical vibrator | |||
| Awning | Detachable canopy + soft cloth roof | Detachable canopy + soft cloth roof | Detachable canopy + soft cloth roof | Detachable canopy + soft cloth roof | Detachable canopy + soft cloth roof | Detachable canopy + soft cloth roof | Detachable canopy + soft cloth roof |
| Speed of work | 1m/min-6m/min | 1m/min-6m/min | 1m/min-6m/min | 0.5 m/min- 6 m/min | 0.5 m/min- 3 m/min | 0.5m/min- 3m /min | 0.5 m/min- 3 m/min |
| Control method | Control box manual + remote control wireless remote control | Control box manual + remote control wireless remote control | Control box manual + remote control wireless remote control | Control box manual + remote control wireless remote control | Control box manual + remote control wireless remote control | Control box manual + remote control wireless remote control | Control box manual + remote control wireless remote control |
| Feeding method | Hydraulic screw feeder | Hydraulic screw feeder | Hydraulic screw feeder | Hydraulic screw feeder | Hydraulic screw feeder | Detachable hydraulic screw feeder | Detachable hydraulic screw feeder |
| Way of working | Double leveler automatic control | Double leveler automatic control | Double leveler automatic control | Double leveler automatic control | Dual leveling instrument control ; dual pitch angle control | Automatic control of double leveling instruments ; double pitch angle control | Automatic control of double leveling instruments ; double pitch angle control |
| Dynamo | 10KW Generator | 30KW | 50KW generator | 50KW generator | 50KW generator | 100KW Generator | 100KW Generator |
| Engine start method | Electric start Alternate manual start | electric start | electric start | electric start | electric start | PLC intelligent control panel | PLC intelligent control panel |
| Tank volume | 40L | 200L | 200L | 200L | 300L | 300L | 300L |
| Diesel tank volume | 25L | 160L | 240L | 240L | 240L | 60L | 60L |
| Tire / track style | rubber solid tire | rubber solid tire | Special track for rubber covered steel wire engineering | Special track for rubber covered steel wire engineering | Steel crawler chassis (excavator chassis) | Steel Track Chassis | Steel crawler chassis (excavator chassis) |
| Track chassis size | 2800mm*1800mm Bandwidth 320mm | 3500mm*2400mm Bandwidth 400mm | 3500mm*1800mm Bandwidth 400mm | 3500mm*2500mm width 400mm | 4500mm*3000mm Bandwidth 500mm | ||
| Drive motor power | 4KW | 5.5KW | 5.5KW*2 | 4KW *2 | 4KW*2 | 4KW *2 | 4KW*2 |
| Gearbox type | none | Front 3 rear 2+ high and low speed | none | none | Caterpillar directly connected planetary reducer | Caterpillar directly connected planetary reducer | Caterpillar directly connected planetary reducer |
| Dimensions (length*width*height without awning) | 2950 mm* 2080 mm*18 80 mm | 5 0 00mm* 2650mm *2600mm | 5 5 00mm* 2650mm *2800mm | 6300mm*2 550mm *2 4 00mm | 5 57 0mm*2 300 mm*2 50 0mm | 5 460mm * 3130mm * 2 5 00mm | 6500mm*2800mm*2800mm |
| Applicable material | concrete | concrete | concrete | concrete | concrete | concrete | concrete |
| Applicable molding size (specifically, the actual drawing calculation shall prevail) | Within 400mm*400mm | Within 800mm*800mm (excluding ditch) | Within 800mm*800mm (dimensions of the ditch) | Production 800mm*800mm (ditch inner diameter 600mm*600mm) | Ditch within an inner diameter of 800mm×800mm (curb stones, shoulders, etc. of any size) | Within 1500mm*1500mm | Within 1700mm*1700mm |
| Hopper volume | 0.2m²-0.5m² | 0.8m²-1.5m² | 1.5m³± | 1.5m³± | 1.2m³± | 1.2m³-1.5m³ | 1.2m³-1.5m³ |
| Speed mode | Inverter stepless speed regulation | Gearbox manual speed regulation combined with inverter stepless speed regulation | Inverter stepless speed regulation | Inverter stepless speed regulation | Inverter stepless speed regulation | Inverter stepless speed regulation | Inverter stepless speed regulation |
| Engine | 28 horsepower horizontal bar water-cooled engine | four cylinder engine | Turbocharged four-cylinder engine | Turbocharged four-cylinder engine | Turbocharged four-cylinder engine | 6105 turbocharged four-cylinder engine | 6105 turbocharged four-cylinder engine |
| Hydraulic drive | Engine direct drive oil pump controlled by hydraulic solenoid valve | Engine direct drive oil pump controlled by hydraulic solenoid valve | Oil pump motor direct drive oil pump controlled by hydraulic solenoid valve | Oil pump motor direct drive oil pump controlled by hydraulic solenoid valve | Oil pump motor direct drive oil pump controlled by hydraulic solenoid valve | Oil pump motor direct drive oil pump controlled by hydraulic solenoid valve | Oil pump motor direct drive oil pump controlled by hydraulic solenoid valve |
| Oil pump motor | 1 5 KW special motor for direct-connected oil pump | 1 5 KW special motor for direct-connected oil pump | 1 5 KW special motor for direct-connected oil pump | 15KW direct-connected oil pump special motor | 1 5 KW special motor for direct-connected oil pump | ||
| Machine cleaning | Equipped with high pressure cleaning water pump | Equipped with high pressure cleaning water pump | Equipped with high pressure cleaning water pump | Equipped with high pressure cleaning water pump | Equipped with high pressure cleaning water pump | Equipped with high pressure cleaning water pump | Equipped with high pressure cleaning water pump |
| Hydraulic oil tank volume | 70L | 80L | 150L | 140L | 140L | 80L | 140L |
| Diesel engine water tank | 20L | ||||||
| Tire /Track model | 18*7-8 | 28*9-15 | 320/90AH/68 | 400/90AH/82 | |||
| Generator supporting | Silent Generator Box | Silent Generator Box | |||||
| Excavator control | Hydraulic manual pilot valve (arm length 7M excavator) |
