4-колесный мини-Холодильный фургон для


Поделиться:


Цена:5 000,00 $ - 5 300,00 $*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-15-2025 5950.22 $* 6248.65 $*
Aug-15-2025 5900.16 $* 6195.32 $*
Jul-15-2025 4950.99 $* 5198.42 $*
Jun-15-2025 5800.97 $* 6090.8 $*
May-15-2025 5050.89 $* 5303.90 $*
Apr-15-2025 5700.67 $* 5985.22 $*
Mar-15-2025 5650.16 $* 5933.89 $*
Feb-15-2025 5600.65 $* 5880.66 $*
Jan-15-2025 5550.31 $* 5828.99 $*

Характеристики



4 wheels FOTON mini refrigerated cold room van truck Refrigeration Food Truck price
Refrigerator truck (also called refrigerator wagon, refrigerated car, refrigerated boxcar, freezer vehicle, freezer wagon, termperature-controlled truck, refrigerator car, preservation vehicle) is used to carry perishable stuff at specific temperatures. The cooling device could be of famous brands such as Carrier, Thermoking, etc. There are two types of power driving ways, one is powered by a vehicle engine through PTO, and the other one is driven by an independent electric power unit.


Products Description


Cab
Single row cab, with power steering.
Electronic flameout
Driving Type
4*2 Left hand driving
Max Speed (km/h)
100Km/h
Overall dimension(mm)
5765*1950*2720
GVW( kg)
2580
Wheelbase(mm)
2860
F/R track base (mm)
1506/1466
F/R overhang (mm)
1120/1515
Approach/Departure Angel
20/16
Tire
185/65R15
Clutch
Single-plate dry diaphragm spring clutch
Steering
Hydraulic steering with power assistance
Gear box
5-speed
Engine
Model
YC4F90-30/ELECTRIC
Fuel Type
Diesel/Electric
Type
Straight line four cylinder turbocharging
Exhaust(ml)
2660mL
Max output power/rotate speed (hp /rpm )
112HP/3400RPM
Max torque/rotate speed(N.m/rpm)
210N·m/2200RPM
Braking system
Service Brake
Compressed air brake
Park Brake
Spring energy
Auxiliary brake
parking brake
Eletric system
24v


Color option
Customizable
Function
Transporting frozen food, dairy products, vegetables, fruit, and vaccine medicine, etc
Materials
Stainless steel, glass fiber reinforced plastics, aluminum alloy, or color steel plate, etc. with PU, etc. sandwiched.
Material of van box
In the middle of Polyurethenefoam, Inner and coating is glass fiber
Thickness of van box (mm)
80mm Polyurethene foam
Model of Refrigeration unit
Korean ND THERMO brand Type:DT-150
Cooling capacity (w)
1960
Van box dimension(mm)
3500*1750*1500mm
Length of van (m)
3~4
Capacity of van (m³)
9m³
Voltage & Total Current
DC12V(20A)
Power
240W
Compressor
SD-5L09(87cc)/SD-5H09(87cc)
Refrigerant
R404A 1.2Kg
Evaporator Dimensions(mm)
680×594×174
Condenser Dimensions(mm)
905×211×420
Mini temperature in van (ºC)
-18(suitable for transfer food )


For refrigerated van inner and outer wall plates can choose high-quality glass fiber reinforced plastic, stainless steel, or color steel plate, For middle insulation material choose an 8 cm thick imported level polyurethane XPS, compartment body aluminum alloy wrapped edge, bottom plate for non-slip pattern aluminum plate, rear door locking parts for stainless steel.


Product Overview




Technology: a sandwich process using vacuum negative pressure technology into one board.Material: The inside and outside of the van with FRP, and polyurethane insulation board in the middle.
Refrigerated car insulation, durability lies in the process of the structure. Refrigerated car with the van adhesive technology plate hard and stable curing between the van to eliminate the carriage leakage and air leakage.
Our factory adopts a 5-axis CNC board repair machine, complete to ensure the consistency of the box board and side board flatness, to eliminate the carriage leakage, air leakage.






Different colors you can choose as you like!
According to the classification of carriage type: bread type refrigerator truck, van type refrigerator truck, semi-trailer refrigerator truck.
According to the classification of chassis capacity: micro reefer 3.5 meters or less, small reefer 3.5-4.2 meters, medium-sized reefer 5.1-7.7 meters, large reefer 7.7 meters or more.


ADVANTAGE:
1. It is made of GRP and PU foam with an all-closed structure that the GRP (Glass Reinforced Plastic Fiber) outside and PU foam in the core.
2. Light in weight: 40% lighter than metal body.
3. Non-corrosion, non-pollution, anti-brine, acid, and soda-resisting.




ADVANTAGE:
4. The panel used for the truck body was constructed in a type of sandwich. The thermal insulation layer is 50-80mm thick, which offers a very good thermal insulation performance.
5. Length of Cargo body: 10-40 inches; Capacity of Cargo body: 5-70CBM. The material of the cargo body is optional according to which kinds of goods the truck transport, with perfect heat preservation, box open model: Rear double-open or Side-open.
6. Refrigeration unit Brand Optioanl: American CARRIER, THERMO KING. South Korea hanya. China Songhan, hanxue, etc. The Temperature range can be 0° C ~ -20° C. The refrigeration units that we select have a simple structure, convenient operation, reliable working, low energy consumption, large refrigerating capacity, small noise, easy installation and maintenance, and other advantages.


Refrigerated transport of different goods on the temperature requirements:
01: fruit, sparse class freshness zone: in 2 ~ 8 ºC refrigerated temperature zone can make vegetables, fruits, eggs, beer, drinks, and other refrigerated can preserve color and freshness, to maintain the original flavor. Suitable for transport in this temperature range of clams are grapes, apples, cherries, plums, melons, pears, citrus, peaches, pineapples, lemons, and bananas. Fresh fruits and vegetables: mushrooms, lobelia, carrots, cauliflower, green peas, flowering vegetables, cabbage, celery, cucumbers, eggplant, spinach, potatoes, onions, sweet potatoes, pumpkins, and tomatoes.
02: meat, fish preservation area: 0 to 2 ºC in 0 degrees insulation food in the 0 ºC state preservation, not frozen, nutrition is not popular, can be short-term storage 1-2 days consumption of fresh fish fresh meat, fresh not discounted. Suitable for this temperature section is generally fresh meat: raw bacon, raw pork, raw beef, raw chicken, raw lamb, raw ham, eggs, pork salami, smoked bacon, salted ham, etc.
03: temperature refrigerated area: in the variable temperature of -2 degrees ~ -14 ºC which includes.
1: water temperature refrigerated area (-2 ~ -3 ºC)
2: micro-freezing refrigeration (-3 ~ -5 ºC)
3: Soft freezing (-6~-8ºC)
4: light freezing (-10 ~ -14 ºC) four temperature zones, not only can keep the food well without losing nutrition, but also maintain the fresh taste.
04: Fast freezing zone, in the -18 ~ -21 ºC freezing temperature zone meat, fish, frozen food and other food can be stored for a longer period of time, freezing speed, freezing more durable. Foods suitable for this temperature are cold ice cream, frozen fruit, juice concentrate, frozen fish, frozen beef, frozen lamb, frozen pork, frozen chicken, and frozen ham.


Product packaging




The company is located in Henan Province . It has in-depth cooperation with foreign customers to develop vehicles and help foreign customers build CKD or SKD assembly workshops abroad.
We have many years of experience in vehicle exporting and have a professional foreign trade team in English, Arabic, and Russian; our products are exported to Tanzania, Ghana, Brazil, Zimbabwe, Central Africa, Thailand, Myanmar, Uzbekistan, and other countries. Our export products cover cargo trucks, sanitation trucks, used trucks and special trucks, providing foreign customers with high-quality and reliable trucks and services.
Packing: Nude packing after painting wax or according to your requirement.
Shipping: By bulk cargo carrier, RORO



Company Profile




In 2000, “Ideal machinery” started a small workshop in Changge city, assembling rebar cutting machines and bending machines.through 20 years of development and relied on word-of-mouth advertising, our product involved kinds of the light construction machine.In order to push our machines into the overseas market, the Brand “Ideal machinery” is established in 2015 and started export trading. until now, nearly 10,000 sets of our machines are servicing the overseas construction sites now.








FAQ


Q1: I want the front two tires to be bias tires and the rear 9 tires to be radial tires, is it ok?
A: We can make the tires as your requirement to suit your country's needs.

Q2: Can I have samples of this type of flatbed semi-trailer to test the quality?
A: Yes, you can buy any samples to test the quality, our MOQ is 1 unit.

Q3: What others we can do?
A: According to your order, we will provide the best price and quality trucks and trailers. And we are well capable of offering overseas after-sales service. Besides, we also provide rational packing and shipping program, letting shipment save money and security.

Q4: How to guarantee customers get the goods smoothly after they pay?
A: Don't worry, dear. We have been in this field for 20 years, we will send you production photos once in a while, and we will
help you to book the latest ship.

Q5: What's the delivery time?
A: The delivery time is within 15 working days after receiving your advance payment.

Q6: Can you supply some quick-wear truck or semi-trailer parts?
A: Yes, we can supply truck and semi-trailer parts as per your request, such as oil filter, fuel filter, air filter, traction,
traction pin, balance beam and semi-trailer plate spring, hanging accessories, turntable, all kinds of trailer brake pads, brake pan, bearings, etc.

Q7: What logistics ways we can work for shipment?
A: We can ship construction machinery with various transportation tools.
(1) For 80% of our shipment, we will go by sea, to all main continents such as South America,
Middle East, Africa, Oceania, etc. Either by container or RoRo/Bulk shipment.
(2) For neighborhood countries of China, such as Russia, Mongolia, Kazakhstan, Uzbekistan, Vietnam, Laos, etc., we can ship construction machinery by road or railway.
(3) For light spare parts in urgent demand, we can ship them by international courier service, such as DHL, TNT, UPS, or FedEx.

Q8: How do I choose my driving direction?
Our standard configuration is left-hand drive, right-hand drive please inform us in advance to customized for you.
