03/04 счетчик Telebahn 3 цифры 0-9999 4
- Категория: Counters >>>
- Поставщик: Zhuhai,Telehof,Electrics,Company,Limited
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-20-2025 | 19.89 $* | 19.79 $* |
| Jul-20-2025 | 15.43 $* | 15.15 $* |
| Jun-20-2025 | 19.84 $* | 19.92 $* |
| May-20-2025 | 19.95 $* | 19.83 $* |
| Apr-20-2025 | 15.21 $* | 15.91 $* |
| Mar-20-2025 | 18.38 $* | 18.88 $* |
| Feb-20-2025 | 18.3 $* | 18.31 $* |
| Jan-20-2025 | 18.13 $* | 18.97 $* |
Характеристики
Product description
Summary:
This product is used for counting the times of discharge by surge protective devices.
Features:
- 1.5 standard module width
- Inductive loop (feed through with the earthing cable of surge protective devices)
- Powered by replaceable 3V Lithium battery, 3 digits or 4 digits LCD display with set and reset function.
- 1m long inductive twisted pair
Installations:
- Attached to the battery is an insulated tie back, pull the tieback "Battery on PULL" before installation to ensure the power supply works normally.
- Open the attached inductive ring and hitch around the earthing wirethen fixed the SPD on the 35mm DIN rail.
- Fault Resolution: When the product indicate incomplete, still reset or even no indication, open the bottom enclosure, unplug the internal battery for about 5 minutes and then reinstall it back, pay attention to the battery and its holder's positive(+) and negative(-) accordingly. In this condition that the display screen will operate normally and do the reset testing setting.
- Testing direction:
1 ) Press the button"SET/RESET"not more than 2 seconds,the number indicate in LCD will add 1. when the number reaches the Max number(999 or 9999),it need to be zero clearing again for using.
2 ) Press the button"SET/RESET"and hold it for 5 seconds the number in LCD will be cleared to zero
3 ) Long press the button"BATTERYLCD will indicate the current level of the batteryThe battery is fully charaed willshow"HI"If the display screen show "LO" you should chanae the new batteries.
Technical Parameters:
Type | IC 03 / IC 04 |
Art.-No. | 810400 / 810404 |
Response behaviour of impulse current | > 1kA, rise time:8-10µs |
Sequence of impulse | > 1s |
LCD indicator | o - 999 /0 - 9999 |
Inductive line | 1m long twisted-pair |
Power supply | 3V battery; Type: CR123A, exchangeable |
Service of battery | > 2.5 year |
Operating temperature range | -100C...+500C |
Mounting on | 35mm DIN rail |
Enclosure material | Purple thermoplastic, UL94-V0 |
Dimension | 1.5 mods |
Certification | CE(LVD,EMC) |
