52 мм синий датчик уровня воды жидкостный контроллер Вертикальный магнитный
- Категория: Limit Switches >>>
- Поставщик: Dongguan,Fuen,Electronics,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 0.51 $* | 0.54 $* |
| Aug-15-2025 | 0.19 $* | 0.49 $* |
| Jul-15-2025 | 0.37 $* | 0.29 $* |
| Jun-15-2025 | 0.59 $* | 0.16 $* |
| May-15-2025 | 0.47 $* | 0.72 $* |
| Apr-15-2025 | 0.6 $* | 0.74 $* |
| Mar-15-2025 | 0.68 $* | 0.84 $* |
| Feb-15-2025 | 0.29 $* | 0.70 $* |
| Jan-15-2025 | 0.63 $* | 0.60 $* |
Характеристики
Product Description
Product Operation
The working principle of the float level switch is direct and simple, usually set a point or a few points of Reed Switch in a sealed non-magnetic metal or engineering plastic tube.And then fix the float ball with magnetic system builtin in the position of reed switch which in the tube body, letting the float fluctuate within a certain range. Using of the magnetic system of the float ball,
activate the reed switch to open or close through the tubebody. In the result of producing switching action and control the level.
Product Application
activate the reed switch to open or close through the tubebody. In the result of producing switching action and control the level.
Product Application
Float level switches are widely used in electronic, electrical, chemical, water treatment, drainage and other industry of level control and alarm. Such as Pipeline Water Dispenser, Automatic Coffee Machine, Portable Aire Cooler, Hot Water Mattress, Humidifier or Dehumidifier, instant water heater etc..
Pipeline Water Dispenser
Empty/full level alarm
Anti buring
Automatic Coffee Machine
Empty/full level alarm
Stainless steel material can be used for high temperature application
Portable Air Cooler
Empty/full level alarm
Easy installation
SPECIFICATIONS FOR PP FLOAT LEVEL SWITCH | ||||||
Reed Switch Contact Form | Normally Open | Normally Close | Change Over | |||
Float Switch Body Material | PP/POM | |||||
Max Contact Rating | 10W/50W | 10W | 10W | |||
Max Switching Voltage | 100VDC/220VDC | 100VDC | 100VDC | |||
Max Switching Current | 0.5A/1.5A | 0.5A | 0.5A | |||
Min Breakdown Voltage | 220VDC/350VDC | 220VDC | 220VDC | |||
Max Current Current | 1.0A/3.0A | 1.0A | 1.0A | |||
Working Temperature | -20℃~+80℃ | |||||
Working Life | 108 times | |||||
Main Features
1) Simple structure, easy in installation and maintation.
2) Adopting advanced world famous brand components in electric parts and operation parts.
3) High stability, high reliability, high consistency.
4) 100% QC inspection Before Shippment
5) ISO,CE,SGS working standard, experenced working skills.
CO-Brands
Our Service
Pre-Sales Service
* Inquiry and consulting support.
* Customed Samples, some models free charge, just need you pay for the shipping.
*Sample testing support.
After-Sales Service
*Show how to install the sensors/switches..
* Broken parts make-up
* .Technical support to work out the best solution.
Related Products
91.8% Response Rate
91.8% Response Rate
91.8% Response Rate
Our Company
Dongguan FuEn Electronics Co. Ltd.
Dongguan Fuen Electronics Co., Ltd. was founded in 2007. We are specialize in researching and developing, producing reed switch, float level switch, multi-point float level switch, continuous float level transmitter, fuel level sensor, proximity switch, flow meter, high pressure dry reed relay and other electronic components.
We have rich experiences in products and professional knowledge in technology, which not only ensure provide high quality products, but also can customize special products for our clients.
We have long-term cooperation with some famouse brands, like GREE and Midea. High quality, low complaints, short lead time have been a character and advantage of our company. If you choose us, we have strong confidence, this will be a good and long term cooperation with your company.
Office
Work Shop
Equipments
FAQ
How to make an order?
1.Sample approval
2.A. Big order: Client make 30% deposit after receiving our PI .
B. Sample & Small order: Client make 100% payment via PayPayl or Ali Trade Assurance
3.Client approve our sample, and get the testing report if any necessary
4.Production
5.Client approve our shipping sample
6.Arrange shipment
7.Supplier arrange necessary documents and send copy of these documents
8.Client finish the balance payments
9.Supplier send original documents or telex release the goods
Customer Service
1. How to contact with us?
Answer(1): send us an e-mail: lily (a) fuen0769.com
Answer(2): add my skype: fuenchina1
Answer(3): trade manger online chat: fuenchina
Answer(4): wechat/cellphone: 86-13392739485
2. Can you seed a sample for reference?
We are glad to send samples for your inspection. Samples are free, but you may need to pay the express fees.
3. How to confirm the quality with us before start to produce?
(1) You can get a free sample and choose from it, and then we make the quality according to that.
(2) Send us your samples, and we make the switch/sensor according to your quality.
4. How to solve the quality problems after sales?
(1) Take photos of the problems and send to us
(2) Take videos of the problems and send to us
(3) Send back the physical problem switch/sensor by express to us
After we comfirm the problems, such as caused by machine, etc, Within three days, we will draw up the satisfied program for you.
