Месяц | Минимальная цена | Макс. стоимость |
---|---|---|
Aug-15-2025 | 1.71 $* | 1.76 $* |
Jul-15-2025 | 1.35 $* | 1.90 $* |
Jun-15-2025 | 1.32 $* | 1.31 $* |
May-15-2025 | 1.4 $* | 1.28 $* |
Apr-15-2025 | 1.53 $* | 1.11 $* |
Mar-15-2025 | 1.17 $* | 1.41 $* |
Feb-15-2025 | 1.8 $* | 1.56 $* |
Jan-15-2025 | 1.80 $* | 1.79 $* |
Delivery Time | Normal Delivery Time: | 24 hours ( fastest 12 hours quick-turn) | ||||
Small Production: | 72 hours( fastest 24 hours quick-turn) | |||||
Medium Production: | 5 working days | |||||
Capacity | SMT assembly | 500W point/day | ||||
THT assembly | 30W point/day | |||||
Components | A full set of substitute materials | Have a mature component procurement management system, and provide cost-effective services for OEM projects. | ||||
Only SMT | Do SMT and backhand welding according to components and PCB boards provided by customers. | |||||
Components purchasing | Customers provide core components, and we provide substituting services for other components |
PCB Capability | ||||
Attribute: see (*) below as applies | S/Sided | D/Sided | Multilayer | Advanced |
Minimum Line/Spacing, Internal Layer | N/A | N/A | .004”/.004” | .003”/.003” |
Minimum Line/Spacing, External Layer | .007”/.008” | .007”/.008” | .005”/.005” | .003”/.003” |
Aspect Ratio (Thickness to Drill) | 6:1 | 6:1 | 8:1 | 10:1 |
Minimum Drilled Hole Size | .010” | .008” | .008” | .008” |
Land Size Internal (Diameter Over Drill) | N/A | N/A | .015” | .012” |
Land size External (Diameter Over Drill) | .012” | .012” | .012” | .010” |
Plane Clearance (Diameter Over Drill) | .030” | .030” | .030” | .024” |
Plated Hole Tolerance | +/- .003” | +/- .003” | +/- .003” | +/- .002” |
Minimum Dielectric Thickness | N/A | N/A | .0025” | .002” |
Minimum Core Thickness | N/A | N/A | .004” | .003” |
Minimum PCB Thickness ** | .017” | .018” | .020” | .020” |
Maximum PCB Thickness | .125” | .125” | .250” | .250” |
Thickness Tolerance (%) | +/- 10 | +/- 10 | +/- 10 | +/- 5 |
Maximum Board Dimensions * | 16” x 52”* | 19” x 22”* | 17” x 23”* | 17” x 23”* |
Fabrication Tolerances (overall dimension) | +/- .010” | +/- .010” | +/- .010” | +/- .005” |
Bow and Twist (Through Hole) % | 1.5 | 1.5 | 1.5 | 1 |
Bow and Twist (SMT) % | .75 | .75 | .75 | .75 |
Minimum Conductor to Edge | .015” | .015” | .015” | .010” |
Layer to Layer Registration Tolerance | N/A | .004” | .004” | .003” |
Component Pitch | .025” | .025” | .025” | .015” |
Soldermask Clearance | .005” | .005” | .005” | .004” |
Soldermask Dams | .005” | .005” | .005” | .004” |
Impedance Tolerance (>50 Ohms) % | +/- 10 | +/- 10 | +/- 10 | +/- 8 |
Maximum Layers | 1 | 1 | 12 | 16 |
Minimum Copper Weight Inners (oz.) | N/A | N/A | 1/4 | |
Maximum Copper Weight Int. Ground (oz.) | N/A | N/A | 3 | 8 |
Maximum Copper Weight Int. Signal (oz.) | N/A | N/A | 2 | 6 |
Maximum Copper Weight Ext. Ground (oz.) | 4 | 4 | 2 | 10 |
Maximum Copper Weight Ext. Signal (oz.) | 4 | 4 | 3 | 10 |
PCBA Technical Capability | |
1. Assembly Type:: | FR4, FPC, Rigid-flex PCB, Metal base PCB. |
2. Assembly Specification: | Min size L50*W50mm; Max size: L510*460mm |
3. Assembly thickness: | Min thickness: 0.2mm; Max thickness: 3.0mm |
4. Components Specification | |
Components DIP: | 01005Chip/0.35 Pitch BGA |
Minimum device accurace: | +/-0.04mm |
Minimum footprint distance: | 0.3mm |
5. File format: | BOM list; PCB Gerber file: |
6. Test | |
IQC: | Incoming inspection |
IPQC: | Production inspection; first ICR test |
Visual QC: | Regularly quality inspection |
SPI test : | Automatic solder paste optical inspection |
AOI: | SMD component welding detection, components shortage & component polarity detection |
X-Ravd: | BGA test; QFN and other precision devices hidden PAD device inspection |
Function test: | Test function and performance according to customer's test procedures and steps |
7. Reworking: | BGA rework equipment |
8. Delivery Time | |
Normal delivery time: | 24 hours( fastest 12 hours quick-turn) |
Small production: | 72 hours( fastest 24 hours quick-turn) |
Medium production: | 5 working davs. |
9. Capacity: | SMT assembly 5 million point/day;plug-in & welding 300,000 point/day; 50-100 items/day |
10. Components Service | |
A full set of substitute materials: | Have a experience component procurement sourcing, management system, and provide cost-effective services for OEM projects |
Only SMT: | Do SMT and backhand welding according to components PCB boards provided by customers. |
Components purchasing: | Customers provide core components, and we provide components sourcing services. |
