Мини-переключатель momro

Категория: Limit Switches >>>
Поставщик: Yueqing,Yongde,Electric,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-15-2025	0.70 $*	0.78 $*
Aug-15-2025	0.10 $*	0.23 $*
Jul-15-2025	0.13 $*	0.13 $*
Jun-15-2025	0.38 $*	0.71 $*
May-15-2025	0.83 $*	0.98 $*
Apr-15-2025	0.10 $*	0.25 $*
Mar-15-2025	0.4 $*	0.41 $*
Feb-15-2025	0.93 $*	0.55 $*
Jan-15-2025	0.88 $*	0.15 $*

Характеристики

omron micro switch

High switch on and off capacity

High accuracy

Wide range of operation speed

Terminal type

Rated
voltage
(V)

Noninductive load(A) Inductive load(A)

Inrush
current
(A)

Resistive load

Lamp load

Inductive
load

Motor load

125 VAC

250 VAC

300 VAC

2.5

1.5

1.25

0.75

2.5

1.5

2.5

1.5

0.75

30

max.

15

max.

8 VDC

14 VDC

30 VDC

125 VDC

250 VDC

6(2)

0.4

0.2

0.4

0.2

1.5

0.4

0.2

0.05

0.03

0.05

0.03

2.5

0.05

0.03

Notes:

1. Inductive load has a power factor of 0.4min. (AC) and a time constant or

7msec (DC).

2. Lamp load has an inrush current of 10 times the steady-state current,

while motor load has an inrush current or 6 times the steady-state current.

·Characteristics

Operating speed	0.01mm to 1m/sec
Operating frequency	Mechanically: 240 operations/min. Electrically: 20 operations/min.
Contact resistance	15mΩmax. (initial)
Insulation resistance	100MΩmin. (at 500VDC)
Dielectric strength	1000VAC, 50/60Hz for 1 minute between non-continuous terminals 2000VAC, 50/60Hz for 1 minute between current-carrying part and ground
Vibration	Mechanical durability: 10 to 55Hz 1.5mm double amplitude
Shock	Mechanical durability: Approx. 1,000m/sec2 (approx. 100G's) Malfunction durability: Approx. 300m/sec2 (approx. 30G's)
Ambient operating temperature	General purpose type: -25°to +80°C Sealed type: -15 to 80°C
Humidity	General purpose type: 85%RH max. Sealed type: 95%RH
Service life	Mechanically: 20,000,000 operations min Electrically: 500,000 operations min.
Weight	Approx. 22 to 58g
