Pv1-f кабель 1500 В

Категория: Wires, Cables & Cable Assemblies >>>
Поставщик: Dongguan,Slocable,Photovoltaic,Technology,Co.,Ltd.

Цена:0,30 $ - 0,37 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-15-2025	0.45 $*	0.98 $*
Aug-15-2025	0.22 $*	0.49 $*
Jul-15-2025	0.37 $*	0.80 $*
Jun-15-2025	0.83 $*	0.18 $*
May-15-2025	0.30 $*	0.74 $*
Apr-15-2025	0.22 $*	0.19 $*
Mar-15-2025	0.53 $*	0.70 $*
Feb-15-2025	0.75 $*	0.78 $*
Jan-15-2025	0.37 $*	0.70 $*

Характеристики

Products Description

Specifications	Cross Section	Conductor Diameter	External Diameter	Max DC Resistance	Rated Current
1x2.5mm²	2.5mm²	2mm	5.1mm±0.2	8.21Ω/km	30A
1x4.0mm²	4.0mm²	2.5mm	5.6mm±0.2	5.09Ω/km	50A
1x6.0mm²	6.0mm²	3.2mm	6.3mm±0.2	3.39Ω/km	70A
1x10.0mm²	10.0mm²	4mm	7.2mm±0.2	1.95Ω/km	95A
1x16.0mm²	16.0mm²	5.5mm	8.5mm±0.2	1.24Ω/km	132A
1x25.0mm²	25.0mm²	6.5mm	9.5mm±0.2	0.795Ω/km	176A
1x35.0mm²	35.0mm²	7.7mm	11.1mm±0.2	0.565Ω/km	218A
1x50.0mm²	50.0mm²	9.5mm	13.5mm±0.2	0.393Ω/km	280A

Advantage of PV Cable
· Dual wall insulation. Electron beam cross-linked.
· Resistance to UV, water, ozone, fluids, salt, general weathering.

· Halogen free, flame, retardant, low toxicity.
· Flexibility and stripping performance.
· TUV, CE, IEC approved.
· High voltage and high current carrying capacity.
· Resistance to abrasion.

Technical Data

Conductor: 99.99% copper, tinned	UV resistance: EN60811-501
Insulation material: XLPE(XLPO)	High voltage and High current
Double walls insulation	Temperature range: -40°C ~ +85°C
Halogen-free material: EN50525-1	Color: Black/Red/Blue/Brown/Grey/Yellow
OEM & ODM can be accepted	Smallest permissible bending radius: 5 x D
Flame test: EN60332-1-2	Smoke density: EN61034-2
Ozone resistance: EN50396	Oil resistance: EN60811
