Compassarmor armored PE filament yarn UHMWPE fiber high strength modulus anti aging anti uv impact resistance NIJ IIIA PE fiber





Compassarmor armored PE filament yarn UHMWPE fiber high strength modulus anti aging anti uv impact resistance NIJ IIIA PE fiber

Advantage

High strength and high modulus , the tenacity can be up to 15times that of a good quality steel.
Low density:0.97g/cm3 ligher than water
High impact resistance
anti aging and anti uv capability
corrosion and sea water resistance
abrasion and fatigue resistance
Low dielectric consitant, high electrical resistance and a dielectric loss factor
Temperature resistance: the strength and modulus increase at low temperature

Black,Deep Gray, Light Gray,Brilliant Blue,Moss Green,Army Green Apple Green,Apple Green,Neon Green, Lemon Yellow,Golden Yellow,Orange Yellow, Neon Orange Flame Red







Compassarmor armored PE filament yarn new material fiber high strength modulus anti aging anti uv impact resistance PE fiber



Para-aramid filament flame retardant yarn new material high temperature resistant fiber yarn high strength and high film aramid

polyphenylene terephthalamide























Para-aramid is known as polyphenylene terephthalamide and AramorED is a registered trademark of ballisrtic fiber of compassarmor
Compassarmor filament has the characteristics of high strength and low density. The specific strength is 5-6 times that of steel and the specific modulus is 2-3times that of steel or glass fiber.
It has goods thermal stability.
The thermal shrinkage rate is 0 at 190 degree C and the thermal decomposition temperature is greater than 530 degree C, Limiting oxygen index is not less than 29%







Product name:Para-aramid yarn
Color:Grey, black ,blue,green bright red, orange
Linear density(dtex):933~1670
Linear density(D):840~1500
Linear density deviation rate(%):±3
Breaking Strength(cN/dtex):≥ 22.5~23.5
Breaking strength(g/d):≥ 25.5~26.6
Breaking elongation(%):3.4~4.5
Modulus of Elasticity(Gpa):90±10
Modulus of Elasticity(cN/dtex):625±69
Finish oil content(%):M±0.5
Hot air shrinkage rate(190 Degree C 15 min) : ≤0.2
Pyrolysis temperature(Degree C) : >530
