Известные китайские бренды строительной техники воздушно-рабочее оборудование по
- Категория: Work Platforms >>>
- Поставщик: Cruking,Engineering,Equipment,(Xiamen),Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 10139.12 $* | 10646.14 $* |
| Aug-16-2025 | 10054.76 $* | 10557.14 $* |
| Jul-16-2025 | 8435.10 $* | 8857.54 $* |
| Jun-16-2025 | 9883.47 $* | 10377.73 $* |
| May-16-2025 | 8605.59 $* | 9035.70 $* |
| Apr-16-2025 | 9713.65 $* | 10199.94 $* |
| Mar-16-2025 | 9628.24 $* | 10109.79 $* |
| Feb-16-2025 | 9542.8 $* | 10019.24 $* |
| Jan-16-2025 | 9457.55 $* | 9930.52 $* |
Характеристики
AERIAL WORKING EQUIPMENT
Contact Way
Product Overview
*20M articulated mobile elevating work platform aiming to satisfy customers’ requirements. Intelligent and perfect control system features the humanized layout, the maintenance-free design and easy use and maintenance, providing the multiple options and comprehensive safety.
* Off-road chassis, 4W drive system, solid off-road wide tire, full-time axle balance system, 38kw power, excellent adaptation to any terrain. Work platform is enable to extend out, enlarging the work space, together with the foldable fence making the transportation easier.
* Off-road chassis, 4W drive system, solid off-road wide tire, full-time axle balance system, 38kw power, excellent adaptation to any terrain. Work platform is enable to extend out, enlarging the work space, together with the foldable fence making the transportation easier.
Product Paramenters
em | Parameter | |
Parameters of running state | ||
Overall dimensions (L × W × H) | 8.49×2.49×2.38 m | |
Working platform overall dimensions | 1.8×0.76×1.1 m | |
Max. speed | 4.8 km/h | |
Max. gradeability | ≥45％ | |
Min. external turning radius | ≤5 m | |
Ground clearance/m (center) | 0.3 m | |
Wheelbase | 2.5 m | |
Total mass | 9100 kg | |
Main Operation Performance Parameters | ||
Rated working height | 20.7 m | |
Max. platform height | 18.7 m | |
Max. working range | 11.98 m | |
Max. net spanning height | 8.0 m | |
Scope of luffing of No. 1 arm | 0°～72° | |
Scope of luffing of No. 2 arm | 0°～73° | |
Fly Jib Luffing Range | -64°～70° | |
Scope of platform swing | 160° | |
Slewing angle | 360° | |
Max. load capacity | 256/350 kg | |
Max. rearward slewing | 0.66 m | |
Control system | 12V DC proportional control | |
Tire | 830*285（835*295，33×12-20） | |
Power parameters | ||
Power source | 420 Ah/48 V DC | |
Power unit | 12 kw/32 V AC | |
Auxiliary power unit | 12 V DC | |
Traveling motor | 3.3 kw/32 V AC | |
Details Images
