Однофазный 220 В в трехфазный трансформатор 380 Преобразователь мощности 10 кВА 15 20 30 повышающий понижающий преобразователь
- Категория: Industrial Controls >>>
- Поставщик: Beijing,Bense,Times,Import,And,Export,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 0.46 $* | 0.35 $* |
| Aug-20-2025 | 0.9 $* | 0.57 $* |
| Jul-20-2025 | 0.76 $* | 0.58 $* |
| Jun-20-2025 | 0.75 $* | 0.9 $* |
| May-20-2025 | 0.68 $* | 0.97 $* |
| Apr-20-2025 | 0.3 $* | 0.70 $* |
| Mar-20-2025 | 0.97 $* | 0.23 $* |
| Feb-20-2025 | 0.83 $* | 0.30 $* |
| Jan-20-2025 | 0.30 $* | 0.24 $* |
Характеристики
MAIN TECHNICAL SPECIFICATION
Model | 3 phase 3-WIRE OR 3 phase 4-wire |
Input voltage: | single phase 220V ± 15% |
Input frequency: | 50HZ |
Output voltage: | 380V |
Output frequency: | 50HZ /60HZ |
Output power: | 1.5KVA~ 100KVA |
Load regulation rate: | ≤ ± 1% |
Circuit mode | IGBT / PWM modulation |
Output waveform | Standard sine wave CF=1.4 |
Input voltage | 220V±15% |
The output voltage | Three-phase 380V |
Output current | Phase current high grade 41A low grade 82A |
Frequency stability | ≤0.01% |
Load regulation rate | ≤1% |
Waveform distortion rate | ≤2% (pure resistive load) |
Phase angle | 120°±1° |
Crest factor ratio | 31 |
Panel display | Output voltage, output current, output frequency, output power, and output power factor (switch display) |
Protective function | Output overcurrent protection, overvoltage protection, over temperature protection, short circuit protection, self-diagnosis protection, protection and alarm device |
Protection reaction time | ≤2ms |
Machine efficiency | ≥87% |
Insulation withstand voltage | 1800V AC/10mA/1 min |
Insulation resistance | 500V DC/50 MΩ |
cooling method | Forced air cooling |
noise | Less than 60db at 1 m |
Working temperature | 0~45° |
Relative humidity | 0~95 % (non-condensing state) |
Note | Please make sure that the mains 220V can withstand the power of the power supply, otherwise there will be power failure protection. |
