Электромагнитный или цифровой 6-значный счетчик LY-06

Электромагнитный или цифровой 6-значный счетчик LY-06

Категория: Timers >>>
Поставщик: Beijing,Bense,Times,Import,And,Export,Co.,Ltd.

Цена:2,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-15-2025	2.56 $*	2.72 $*
Aug-15-2025	2.34 $*	2.4 $*
Jul-15-2025	2.59 $*	2.73 $*
Jun-15-2025	2.24 $*	2.45 $*
May-15-2025	2.98 $*	2.84 $*
Apr-15-2025	2.52 $*	2.5 $*
Mar-15-2025	2.84 $*	2.52 $*
Feb-15-2025	2.63 $*	2.26 $*
Jan-15-2025	2.37 $*	2.9 $*

Характеристики

Electromagnetic or digital 6 digits CE RoHS passed 24VDC LY-06 counter, lightning strike Line Seiki ME Series counter

LY-06 counter is a mini, non-reset total counter. It has a one piece plastic housing with an internal metal frame for added rigidness. This 6 or 7 digit counter is available in different mounting options - Rear, Base and Panel (Snap-in or Screw type). Standard input voltages are DC12V, DC24V and AC100V. Maximum count speed is 10Hz. Special input voltages are also available upon request.

Main technical specifications:

Working voltage: 12VDC or 24VDC;

Speed: the best 5CPS /second plus;

Pulse ratio: 10:15, ambient temperature: -10 C-60 °C;

Lifespan: 20.5 billion times;

Counting error rate, one in ten thousand;

Power consumption: less than 1.5W;

Display digits: six

Model	LY-06
Operating voltage	12VDC, 24VDC or other customized voltage
Counting range	0-999999
Speed	Best 5CPS/sec Addition
Pulse ratio	10:1
Ambient temperature	-10 °C--60 °C
Service life	>0.5 million times
Counting error rate	one ten thousandth
Power	less than 1.5W
Display digits	six digits
Return to zero mode	no return to zero
