Многофункциональная зигзагообразная пружинная машина
- Категория: Furniture Making Machines >>>
- Поставщик: Guangzhou,Xidengbao,Mattress,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.7 $* | 0.39 $* |
| Aug-16-2025 | 0.86 $* | 0.50 $* |
| Jul-16-2025 | 0.77 $* | 0.79 $* |
| Jun-16-2025 | 0.99 $* | 0.0 $* |
| May-16-2025 | 0.86 $* | 0.5 $* |
| Apr-16-2025 | 0.86 $* | 0.54 $* |
| Mar-16-2025 | 0.44 $* | 0.62 $* |
| Feb-16-2025 | 0.73 $* | 0.38 $* |
| Jan-16-2025 | 0.36 $* | 0.5 $* |
Характеристики
Specification
Model | SF-COIL |
Production efficiency | 160 single peak/Min，160 double peak/Min |
Peak Height | 38-70mm |
Peak Width | 24~36mm |
Wire Diameter | Φ2.5~5.0mm |
Spring pitch | 16-60 mm |
Regular spring pitch | 20-30 mm |
Diameter of spring | 3.0-4.0 mm |
Feeding speed | 12 m/min |
Power height of S-shape spring | 40-50 mm |
Cutting type | Adjustable single,double peak |
Host motor power | 2.2 Kw |
Punch motor power | 0.37 Kw |
Punch pressure | 1 ton |
Zig zag spring forming machine motor power | 2.2KW |
Zig zag spring coiling device power | 0.7KW |
Weight | 1000Kg |
Total power | 3KW |
