Трубчатый каталитический реактор емкостью 1 5 тонны резервуар для углеродистой стали высокого давления
- Категория: Reactors >>>
- Поставщик: Laizhou,Yisu,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 8330.96 $* | 8747.43 $* |
| Aug-17-2025 | 8260.48 $* | 8673.83 $* |
| Jul-17-2025 | 6930.92 $* | 7277.49 $* |
| Jun-17-2025 | 8120.6 $* | 8526.68 $* |
| May-17-2025 | 7070.67 $* | 7424.63 $* |
| Apr-17-2025 | 7980.47 $* | 8379.50 $* |
| Mar-17-2025 | 7910.30 $* | 8306.85 $* |
| Feb-17-2025 | 7840.81 $* | 8232.57 $* |
| Jan-17-2025 | 7770.51 $* | 8159.30 $* |
Характеристики
Product Description
other chemical machinery & equipment alkyd resin manufacturing production line unsaturated polyester resin machine
Specification
Nominal Capacity L | Actual Capacity L | Electrical Heating Power (kw*pcs) | Oil Amount in Jacket L | Inner Pot Size φmm | Outer Pot Size φmm | Expander Capacity L | Motor Power kw | Speed of Stirring n/min | Weight kg |
50 | 78 | 2*4 | 96 | 400 | 600 | 10 | 1.1 | 80 | 270 |
100 | 127 | 2*6 | 127 | 500 | 700 | 10 | 1.1 | 80 | 340 |
300 | 327 | 4*6 | 218 | 800 | 1000 | 20 | 2.2 | 80 | 700 |
500 | 509 | 4*9 | 269 | 900 | 1100 | 20 | 3 | 80 | 930 |
1000 | 1017 | 4*12 | 400 | 1200 | 1400 | 40 | 4 | 80 | 1610 |
2000 | 2154 | 4*15 | 850 | 1400 | 1600 | 40 | 5.5 | 80 | 2010 |
3000 | 3201 | 4*15 | 1015 | 1600 | 1750 | 40 | 7.5 | 80 | 2590 |
4000 | 4020 | 5*15 | 1226 | 1600 | 1750 | 40 | 11 | 80 | 3160 |
5000 | 5170 | 4*18 | 1400 | 1800 | 2000 | 40 | 15 | 80 | 4000 |
Norminal Capacity (L) | Heating Power (KW*PCS) | Oil volume in jacketed space (L) | Inner diameter (mm) | Outer diameter (mm) | Supporting screw diameter (mm) | n-d | Expander capacity (L) | Motor power (KW) | Stirring rate (r/min) |
50L | 2*4 | 96 | Φ400 | Φ600 | Φ828 | 4-25 | 10 | 1.1 | 80 |
100L | 2*6 | 127 | Φ500 | Φ700 | Φ928 | 4-25 | 10 | 1.1 | 80 |
300L | 4*6 | 218 | Φ800 | Φ1000 | Φ1148 | 4-25 | 20 | 2.2 | 80 |
500L | 4*9 | 269 | Φ900 | Φ1100 | Φ1252 | 4-25 | 20 | 3 | 80 |
1000L | 4*12 | 400 | Φ1200 | Φ1400 | Φ1588 | 4-30 | 40 | 4 | 80 |
2000L | 4*15 | 850 | Φ1400 | Φ1600 | Φ1840 | 4-30 | 40 | 5.5 | 80 |
3000L | 4*15 | 1015 | Φ1600 | Φ1750 | Φ2040 | 4-35 | 40 | 7.5 | 80 |
4000L | 5*15 | 1226 | Φ1600 | Φ1750 | Φ2070 | 4-36 | 40 | 11 | 80 |
5000L | 4*18 | 1400 | Φ1800 | Φ2000 | Φ2320 | 4-36 | 40 | 15 | 80 |
for condenser | ||||
Reactor (L) | Packing volume (m³) | Vertical cooling area (m²) | Horizontal cooling area (m²) | Water storage tank (L) |
50 | 0.002 | 0.1 | 0.29 | 8 |
100 | 0.005 | 0.19 | 0.58 | 30 |
300 | 0.01 | 0.22 | 1.49 | 53 |
500 | 0.015 | 0.38 | 2.08 | 70 |
1000 | 0.025 | 0.62 | 3.17 | 140 |
2000 | 0.042 | 1.06 | 5 | 245 |
3000 | 0.063 | 1.52 | 10 | 346 |
4000 | 0.086 | 1.86 | 15 | 400 |
5000 | 0.096 | 2.07 | 20 | 500 |
condenser | |||||||||
Specification(m²) | 0.3 | 0.6 | 1.0 | 1.5 | 2 | 3 | 4 | 5 | 6 |
8 | 10 | 15 | Effective length(mm) | 550 | 600 | 1000 | 1000 | 1400 | |
1500 | 1500 | 1600 | 1800 | 2000 | 2200 | 2100 | 2100 | Outside diameter(mm) | 150 |
180 | 180 | 210 | 220 | 270 | 270 | 300 | 300 | 350 | 400 |
500 |
Packing & Delivery
Foam's used to keep the equipment intact with wooden frame outside encasing exterior.
