SENTEC SPX510 Высокоточный цифровой измеритель плотности
- Категория: Densitometers >>>
- Поставщик: Chengdu,Sentec,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 952.58 $* | 1000.66 $* |
| Aug-15-2025 | 944.69 $* | 991.93 $* |
| Jul-15-2025 | 792.32 $* | 832.10 $* |
| Jun-15-2025 | 928.82 $* | 974.95 $* |
| May-15-2025 | 808.63 $* | 848.12 $* |
| Apr-15-2025 | 912.58 $* | 958.68 $* |
| Mar-15-2025 | 904.82 $* | 949.42 $* |
| Feb-15-2025 | 896.4 $* | 941.99 $* |
| Jan-15-2025 | 888.69 $* | 932.33 $* |
Характеристики
Related Products
OVERVIEW
SPX510 series intelligent on-line densitometer (also called on-line density transmitter) is a kind of equipment for continuous on line measurement of liquid concentration and density, which can be directly used in industrial production process. The densimeter adopts advanced technology, including a capacitive differential pressure sensor and a pair of pressure repeaters connected with it and inserted into the production process. There is a temperature sensor between the two pressure repeaters to compensate for the temperature change of the process liquid. The intelligent online densitometer is a two-wire density transmitter, which is mainly used for industrial process control. The online densitometer generates a corresponding 4-20mA signal according to the concentration and density. It can be calibrated and monitored remotely through digital communication. SPX510 series of in-line density meters provides on-line density measurements of a variety of liquid or liquid mixtures. In the petrochemical industry can be widely used in petroleum, oil refifining, oil regulation, oil and water interface testing, in the food industry for grape juice, tomato juice, fruit syrup, vegetable oil and soft drink processing and other production sites, dairy industry, paper industry, black pulp, green pulp, white pulp, alkali solution testing; wine alcohol; chemical urea, detergent, ethylene glycol, Testing of acid and alkali and polymer density. It can also be used in mining salt water, potassium, natural gas, lubricants, biopharmaceuticals and other industries.
Product Paramenters
SPECIFICATION | ||
Singnal output | 4-20mA current output, superimposed digital signal (HART protocol) | |
Density range: | 0-2g/cm3; 0-3g/cm3 | |
Accuracy | 0.001g/cm3 | |
Power supply | 16-30VDC power supply, 24VDC is recommended | |
Resolution | 0.001g/cm3 | |
Temperature range | 0-100℃ | |
Temperature accuracy | 0.5℃ | |
Ambient temperature | -10～60℃ | |
Humidity range | 0-90% | |
Damping adjustment | 0-16 seconds; 0-32 seconds | |
Wetted material | 316L stainless steel Hastelloy | |
Process connection | ANSI 150 ~ 1500 RF DIN 50 PN16 DIN 50 PN40 IDF and RJT Hygienic | |
shell | Aluminum alloy | |
MAIN FEATURES
• The on-line densimeter is suitable for flowing or static liquid and is suitable for pipeline and tank installation.
• Two wire transmitter with integrated structure, no moving parts, easy maintenance.
• It is easy to install and use, and the reading can be displayed by inserting liquid.
• Continuous on-line measurement of liquid density and temperature, without process interruption, can be directly used for production process control.
• Dual four digit LCD, temperature and density parameters can be displayed at the same time
• The intrinsically safe type can be used in hazardous sites, and the hygienic type can be installed in food hygiene
• The on-line densimeter is suitable for flowing or static liquid and is suitable for pipeline and tank installation.
• Two wire transmitter with integrated structure, no moving parts, easy maintenance.
• It is easy to install and use, and the reading can be displayed by inserting liquid.
• Continuous on-line measurement of liquid density and temperature, without process interruption, can be directly used for production process control.
• Dual four digit LCD, temperature and density parameters can be displayed at the same time
• The intrinsically safe type can be used in hazardous sites, and the hygienic type can be installed in food hygiene
SENTEC concentrates on the research and innovation of the sensing technology and keeps developing the high-quality and advanced solutions from the accumulated sensor experiences over last two decades. For decades, SENTEC quality guaranteed products insist strictly manufactured in accordance with ISO, CE directive and fully RoHS compliant. On the basis of large-scaled production factories and international excellent devices, SENTEC inspections, tests and calibrations are well recognized throughout the world with experienced OEM service.
Certifications
Feedback
Packing&Shipping
Q: How long will you give me the reply?
A: we will contact you in 1 hours as soon as we can.
High Accuracy 4-20mA Hart Output Intelligent Online Density Concentration Interface Transmitter
Q:Could I visit your factory?
A: Sincerely invite you to visit our factory.
High Accuracy 4-20mA Hart Output Intelligent Online Density Concentration Interface Transmitter
Q: Do you provide samples ?
A: Yes,we have materials in stock to help you to get the samples as soon as we can.
High Accuracy 4-20mA Hart Output Intelligent Online Density Concentration Interface Transmitter
Q: How about the quality of the managements ?
A: We have a complete quality control system , all of our products will be fully pre-inspection by QC departments before shipping to you . We have the certification of ISO,CE we could send the certification test of our company to you
High Accuracy 4-20mA Hart Output Intelligent Online Density Concentration Interface Transmitter
Q: What is your terms of payment ?
A: We could accept T/T, Paypal, WU ,Credit Assurance
High Accuracy 4-20mA Hart Output Intelligent Online Density Concentration Interface Transmitter
Q: What is the warranty for your product ?
A: Warranty: 2 years, Lifetime maintenance
High Accuracy 4-20mA Hart Output Intelligent Online Density Concentration Interface Transmitter
Q: How to contact you?
A: Email: sales01(@)cdsentec.com, Tel/wechat/whatsapp: +86 18848456685
A: we will contact you in 1 hours as soon as we can.
High Accuracy 4-20mA Hart Output Intelligent Online Density Concentration Interface Transmitter
Q:Could I visit your factory?
A: Sincerely invite you to visit our factory.
High Accuracy 4-20mA Hart Output Intelligent Online Density Concentration Interface Transmitter
Q: Do you provide samples ?
A: Yes,we have materials in stock to help you to get the samples as soon as we can.
High Accuracy 4-20mA Hart Output Intelligent Online Density Concentration Interface Transmitter
Q: How about the quality of the managements ?
A: We have a complete quality control system , all of our products will be fully pre-inspection by QC departments before shipping to you . We have the certification of ISO,CE we could send the certification test of our company to you
High Accuracy 4-20mA Hart Output Intelligent Online Density Concentration Interface Transmitter
Q: What is your terms of payment ?
A: We could accept T/T, Paypal, WU ,Credit Assurance
High Accuracy 4-20mA Hart Output Intelligent Online Density Concentration Interface Transmitter
Q: What is the warranty for your product ?
A: Warranty: 2 years, Lifetime maintenance
High Accuracy 4-20mA Hart Output Intelligent Online Density Concentration Interface Transmitter
Q: How to contact you?
A: Email: sales01(@)cdsentec.com, Tel/wechat/whatsapp: +86 18848456685
The specific price is subject to the parameters, please contact us for the quotation
