Гарантия качества свинцово-кислотная батарея Agm цена 12 В 5Ah 7AH 9Ah
Гарантия качества свинцово-кислотная батарея Agm цена 12 В 5Ah 7AH 9Ah
Гарантия качества свинцово-кислотная батарея Agm цена 12 В 5Ah 7AH 9Ah
Гарантия качества свинцово-кислотная батарея Agm цена 12 В 5Ah 7AH 9Ah
Гарантия качества свинцово-кислотная батарея Agm цена 12 В 5Ah 7AH 9Ah
Гарантия качества свинцово-кислотная батарея Agm цена 12 В 5Ah 7AH 9Ah
Гарантия качества свинцово-кислотная батарея Agm цена 12 В 5Ah 7AH 9Ah

Гарантия качества свинцово-кислотная батарея Agm цена 12 В 5Ah 7AH 9Ah


Поделиться:


Цена:6,00 $ - 12,00 $*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-16-2025 7.1 $* 7.10 $*
Aug-16-2025 7.72 $* 7.61 $*
Jul-16-2025 6.20 $* 6.64 $*
Jun-16-2025 7.49 $* 7.15 $*
May-16-2025 6.60 $* 6.50 $*
Apr-16-2025 7.87 $* 7.56 $*
Mar-16-2025 7.78 $* 7.48 $*
Feb-16-2025 7.18 $* 7.21 $*
Jan-16-2025 7.22 $* 7.17 $*

Характеристики



Product Description






GEL 12V 200AH Specification


Model
6-CNF-200
Cells Per Unit
6
Voltage Per Unit
12
Capacity
200Ah@20hr-rate to 1.75V per cell @25℃
Weight
Approx. 60.0 Kg (Tolerance±1.5%)
Internal Resistance
Approx. 5.2 mΩ
Terminal
F16(M8)/F10(M8)
Max. Discharge Current
2000A (5 sec)
Design Life
15 years (floating charge)
Maximum Charging Current
40.0A
Reference Capacity
C3 136.5AH C5 151.5AH C10 174.0AH C20 200.0AH
Float Charging Voltage
13.6 V~13.8 V @ 25℃ Temperature Compensation: -3mV/℃/Cell
Cycle Use Voltage
14.2 V~14.4 V @ 25℃ Temperature Compensation: -4mV/℃/Cell
Operating Temperature Range
Discharge: -40℃~60℃ Charge: -20℃~50℃ Storage: -40℃~60℃
Normal Operating Temperature Range
25℃±5℃
Self Discharge
SUNPAL Valve Regulated Lead Acid (VRLA) batteries can
be stored for up to 6 months at 25℃ and then recharging
is recommended. Monthly Self-discharge ratio is less
than 3% at 25℃.Please charged batteries before using.
Container Material
A.B.S. UL94-HB, UL94-V0 Optional.


Constant Current Discharge Characteristics : A(25℃)


F.V/Time
15MIN
30MIN
1HR
2HR
4HR
8HR
10HR
20HR
1.60V
273.6
183.4
111.8
66.9
37.9
21.4
18.1
11.0
16.5V
268.0
181.8
111.3
66.4
37.7
21.2
17.9
10.6
1.70V
263.8
180.7
110.2
65.9
37.5
21.0
17.7
10.3
1.75V
254.1
177.9
109.2
65.4
37.2
20.8
17.5
10.0
1.80V
237.0
171.7
106.6
64.2
36.3
20.5
17.4
9.40
1.85V
215.0
162.4
101.3
61.4
34.6
19.6
16.8
9.00


Constant Power Discharge Characteristics : WPC(25℃)


F.V/Time
15MIN
30MIN
1HR
2HR
4HR
8HR
10HR
20HR
1.60V
502
348
215
131
75.3
42.5
36.0
19.5
16.5V
494
344
215
131
75.2
42.3
35.8
19.1
1.70V
488
345
213
130
75.0
42.0
35.4
18.8
1.75V
471
341
211
129
74.3
41.7
35.1
18.4
1.80V
440
330
207
127
72.6
41.0
34.7
18.1
1.85V
401
313
198
123
69.1
39.3
33.7
17.0










NOTE:
Due to differences in specifications or specific parameters such us
brand,capacity,quantity, etc., the price listed are for reference only.
Please contact us before placing an order. Thank you!




Company Profile




Factory Show












Cooperative Partner




Certifications




Packing & Delivery




FAQ
Q1: What's your MOQ?
A1:No limited.More quantity has better price,we will check the best price for you.

Q2: How about your delivery time?
A2: Generally within 7-15 days,we well arrange it for you as soon as possible.

Q3: What's your warranty?
A3: Our battery and charger all cover with warranty
For LIFEPO4 battery:3-5 years warranty.
For charger:12 months product warranty.

Q4: Which product is hot sale in your company?
A4: LiFePO4 battery 230ah,280ah,302ah,50ah;12V,24V,48V LiFePO4 battery pack and so on.

Q5: What is your term of payment?
A5:We adopt Alibaba trade assurance,T/T,Paypal,Wester union and so on.

Q6: Which shipping method you usually take?
A6:Train/Sea DDP,Express,We can also ship with your own shipping agent
