Подержанный мобильный телескопический грузовой кран Zoomlion 25 30 35 50 тонн Qy25K5d Ztc350h Qy50kd Ztc550h Stc500
- Категория: Other Used Cranes >>>
- Поставщик: Henan,One,Five,Four,Seven,Import,And,Export,Trading,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 101745.68 $* | 106832.34 $* |
| Aug-16-2025 | 100890.1 $* | 105935.4 $* |
| Jul-16-2025 | 84645.53 $* | 88877.28 $* |
| Jun-16-2025 | 99180.47 $* | 104139.85 $* |
| May-16-2025 | 86355.20 $* | 90673.67 $* |
| Apr-16-2025 | 97470.72 $* | 102344.42 $* |
| Mar-16-2025 | 96615.84 $* | 101446.64 $* |
| Feb-16-2025 | 95760.70 $* | 100548.6 $* |
| Jan-16-2025 | 94905.9 $* | 99650.24 $* |
Характеристики
Product Description
Specification
Description | Unit | Parameter value | ||
Overall length | mm | 13930 | ||
Overall width | mm | 2780 | ||
Overall Height | mm | 3630 | ||
Axle base | 1st ,2nd axle | mm | 1470 | |
2nd ,3rd axle | 4300 | |||
3rd ,4th axle | 1350 | |||
Wheel Base | mm | 2304+2075 | ||
Front overhang/rear overhang | mm | 2389/2064or 2376/2064 | ||
Front extension/rear extension | mm | 2131/226 or 2144/226 | ||
Total vehicle mass in travel configuration | kg | 42200 | ||
Axle load | Front axle | kg | 16200 | |
Rear axle | 26000 | |||
Engine Model | WD615.338 | |||
Engine rated power | kw/(r/min) | 276/2200 | ||
Engine rated torque | N.m/(r/min) | 1500/1300-1600 | ||
Max. travel speed | km/h | 85 | ||
Min. steady travel speed | km/h | 2~3 | ||
Min. turning diameter | m | 24 | ||
Min. ground clearance | mm | 327 | ||
Max. grade ability | % | 42 | ||
Approach angle | ° | 19 | ||
Departure angle | ° | 15 | ||
Braking distance (at 30 km/h, full load ) | m | ≤10 | ||
Oil consumption per 100km | L | 40 | ||
Exterior noise level during acceleration traveling | dB (A) | ≤88 | ||
Noise level at seated position | dB (A) | ≤90 | ||
