RUIAO гибкий пластиковый весовой подшипник и большая длина рабочего кабеля

RUIAO гибкий пластиковый весовой подшипник и большая длина рабочего кабеля

Категория: Drag Chain >>>
Поставщик: Hebei,Ruiao,Machine,Tool,Accessories,Producing,Co.,Ltd.

Цена:10,00 $ - 12,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-19-2025	12.60 $*	13.48 $*
Aug-19-2025	12.75 $*	13.22 $*
Jul-19-2025	10.51 $*	11.13 $*
Jun-19-2025	12.13 $*	13.58 $*
May-19-2025	10.9 $*	11.56 $*
Apr-19-2025	11.85 $*	12.25 $*
Mar-19-2025	11.76 $*	12.55 $*
Feb-19-2025	11.50 $*	12.71 $*
Jan-19-2025	11.60 $*	12.47 $*

Характеристики

Product Name	RUIAO Flexible Plastic Weight Bearing And Over Length Working Cable Hose Carrier
Material	reinforced nylon PA66
Color	black structure ,different color dots required
Shape	rectangular
Thickness	customized
Fuction	drag chain cable hose carrier
Certification	ISO9001/CE/ROHS
Used	CNC machine tools , Laser equipment, grinder, milling machine, machining center

Product Description

Hot sale flexible cable hose carrier:

Inner height : 35mm, 45mm, 56mm

Inner width : 50mm, 75mm,100mm, 125mm

150mm,175mm,200mm,250mm,300mm

model	inside diameter	outside diameter	bending radius	pitch
TLX35K.50	35*51	60*79	75 100 125 150 175 200 250	62
TLX35K.60	35*61	60*89
TLX35K.75	35*76	60*104
TLX35K.100	35*101	60*129
TLX35K.125	35*126	60*154
TLX35K.150	35*151	60*179
TLX35K.175	35*176	60*204
TLX35K.200	35*201	60*229
TLX35K.250	35*251	60*279
TLX35K.300	35*301	60*329

TLX45K.50	45*51	70*79	75 100 125 150 175 200 250	74
TLX45K.60	45*61	70*89
TLX45K.75	45*76	70*104
TLX45K.100	45*101	70*129
TLX45K.125	45*126	70*154
TLX45K.150	45*151	70*179
TLX45K.175	45*176	70*204
TLX45K.200	45*201	70*229
TLX45K.250	45*251	70*279
TLX45K.300	45*301	70*329

TLX56K.100	56*100	86*140	125 150 175 200 250 300 350 400 500	90
TLX56K.125	56*125	86*165
TLX56K.150	56*150	86*190
TLX56K.175	56*175	86*215
TLX56K.200	56*200	86*240
TLX56K.250	56*250	86*290
TLX56K.300	56*300	86*340

small size flexible cable hose carrier

Inner height : 7mm, 8mm, 10mm,15mm,18mm
Inner width:

7mm,8mm,10mm,15mm,20mm,25mm,

30mm,40mm,50mm

model	inside diameter	outside diameter	bending radius	pitch
TP7.7	7*7	10.1*12.5	15
TP8.8	8*8	11.2*14	15
TP10.10	10.4*10.5	14*17	18 28	13
TP10.15	10.4*15.5	14*22
TP10.20	10.4*20.5	14*27
TP10.25	10.4*25.5	14*32
TP15.15	15*15	20.2*25	28 38 48	27
TP15.20	15*20	20.2*30
TP15.30	15*30	20.2*40
TP15.40	15*40	20.2*50
TP15.50	15*50	20.2*60
TP18.18	18*18	23*29	28 38 48	30
TP18.25	18*25	23*36
TP18.35	18*35	23*46
TP18.40	18*40	23*51
TP18.50	18*50	23*61

Products Show

Our Service

Our Company

Packing & Delivery

Packing Details of cable hose carrier : Packing in standard exporting carton, wooden case

Delivery Details : 7-15 days after order confirmed

hot sale : RUIAO Flexible Plastic Weight Bearing And Over Length Working Cable Hose Carrier

Our Certifications

Application

FAQ

Q: Are you trading company or manufacturer ?

A: We are Manufacturer , we have specialized in drag chain's line nearly 30 years .

Q: How long is your delivery time?

A: quantity smaller than 500 meters can be deliveried within one week .

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but customer need to share shipping freight together .

Q: What is your terms of payment ?

A: Payment<=3000USD, 100% in advance. Payment>=3000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below:

hot sale : Nylon Bridge or Enclosed CNC Energy Drag Chain Cable Carriers Flexible Cable Tray
