Характеристики
Product Paramenters
Product Characters
Self service kiosk controlled by mini-pc, powerful, flexible and high stable.
The kiosk can be equipped with QR-code scanner/80mm ticket printer/IC ID card reader/Bank card reader/Metal pin-pad and other function modules.
The mini-pc of kiosk supports all kinds of ANDROID/WINDOWS software to process, support self-service inquiry, self service ticket collect, self service payment, and other kinds of intelligent functions.
The kiosk supports OEM/ODM customization.
The kiosk suits for all kinds of intelligent scene terminal applications.
The kiosk can be equipped with QR-code scanner/80mm ticket printer/IC ID card reader/Bank card reader/Metal pin-pad and other function modules.
The mini-pc of kiosk supports all kinds of ANDROID/WINDOWS software to process, support self-service inquiry, self service ticket collect, self service payment, and other kinds of intelligent functions.
The kiosk supports OEM/ODM customization.
The kiosk suits for all kinds of intelligent scene terminal applications.
Self service inquiry kiosk charaters:
(1) 27”\\32”\\43”\\49” monitor optional;
(2) Flowing color dynamic display;
(3) Multi-point capacitive touch;
(4) Industrial level CPU & motherboard;
(5) Android or Windows dual os optional;
(6) Ultra-thin streamline shell case;
(7) Neutral function module option list;
(8) Support OEM\\ODM;
² Support intelligent environment applications.
(1) 27”\\32”\\43”\\49” monitor optional;
(2) Flowing color dynamic display;
(3) Multi-point capacitive touch;
(4) Industrial level CPU & motherboard;
(5) Android or Windows dual os optional;
(6) Ultra-thin streamline shell case;
(7) Neutral function module option list;
(8) Support OEM\\ODM;
² Support intelligent environment applications.
Application
*PRODUCT NAME | (1)BASIC PARAMETERS | Product Name | Self Service Inquiry Kiosk | |||||||||
Product Model | ST-IK (H) 1 43" | |||||||||||
* PRODUCT SPECIFICATION | ||||||||||||
CATEGORIES | CATEGORIES -2 | DESCRIPTIONS | ||||||||||
*PRODUCT SPECIFICATION | (1)LCD PARAMETERS | Screen Size | 43 " | |||||||||
Screen Type | LED industrial grade A standard LCD screen | |||||||||||
Screen Brand | LG | |||||||||||
Display Area | 943MM(L)*531MM(W) | |||||||||||
Resolution | 1920*1080 | |||||||||||
Screen Ratio | 16:9 | |||||||||||
Brightness | 350cd/㎡ | |||||||||||
Contrast | 1500:1 | |||||||||||
Response Time | 5.5ms | |||||||||||
Max. Color | 16.7m | |||||||||||
Refresh Rate | 50\\60hz | |||||||||||
Visual Angle | 178°(H)\\178°(V) | |||||||||||
Service Lift | 60000hours | |||||||||||
(2)TOUCH SCREEN PARAMETERS | Touch Screen Type | Projected capacitive touch screen (G+G) | ||||||||||
Response Time | 3ms | |||||||||||
Touch Points | 10-point touch, can realize multi-touch functions such as zooming in and zooming out pictures | |||||||||||
Effective Touch Recognition | ＞1.5mm(Opaque objects such as fingers and touch pens) | |||||||||||
Scan Rate | 50scans\\s | |||||||||||
Scan Accuracy | 4096*4096 | |||||||||||
Communication Methods | Full speed USB2.0\\3.0 | |||||||||||
Theoretical Clicks | 60 million times or more | |||||||||||
Working Current/ Voltage | 180ma\\dc+5v±5% | |||||||||||
Anti-light Interference | Normal use when sunlight, incandescent lamp, fluorescent lamp, etc. strong light changes | |||||||||||
Touch Data Output Method | Coordinate output | |||||||||||
Surface Hardness | Physically tempered Mohs Grade 7 explosion-proof glass | |||||||||||
Operating System Compatibility | Windows\\Android | |||||||||||
Drive | Drive-free, plug and play | |||||||||||
(3)HOST CONFIGURATION | Processor | ZC-40A high -performance CPU, 2.0GHz; | ||||||||||
Chipset | 1. Double Cortex-A72 large core+four Cortex-A53 small core 64-bit CPU 2. Built-in low-power MCU Cortex-M0 | |||||||||||
GPU | Quad-core ARM Mali-T860MP4 High-performance GPU | |||||||||||
Memory | 1G (optional) | |||||||||||
Storage | 16G (optional) | |||||||||||
Display function | LVDS output: 1 single/double road, you can directly drive 50/60Hz LCD screen | |||||||||||
EDP output: EDP interface LCD screen that can directly drive multiple resolution | ||||||||||||
Network features | Wifi, BT: built -in WIFI, BT4.0 (optional) support dual -frequency WIFI | |||||||||||
3G: built -in WCDMA, EVDO, 4G full Netcom, support voice calls | ||||||||||||
Ethernet: 2, which is 100M/1000M Ethernet, respectively | ||||||||||||
Audio function | Audio and video output: Support left -right channel output, built -in dual 4R/20W, 8R/10W power amplifier | |||||||||||
Expansion port | \\ | |||||||||||
Back panel I\\O interface | TF card: support TF card | |||||||||||
HDMI output: 1, support 1080P@60Hz, 4kx2k@60Hz output | ||||||||||||
HDMI in: hdmi input, 24Pin FPC custom interface | ||||||||||||
USB interface: a Type C, 1 USB3.0, 1 USB2.0 Host, 3 USB sockets | ||||||||||||
Operating system | Android 7.1 | |||||||||||
(5)CABINET PARAMETERS | Cabinet Material | Tempered explosion-proof glass, Aluminum alloy frame, Iron sheet metal body | ||||||||||
Cabinet Color | Black\\White\\Silver\\Customizable | |||||||||||
* EQUIPMENT SPECIFICATION | ||||||||||||
CATEGORIES | CATEGORIES -2 | DESCRIPTIONS | ||||||||||
*EQUIPMENT SPECIFICATION | (1)POWER PARAMETERS | Input Power | AC110-240V, 50\\60Hz | |||||||||
Power Consumption | ≤85W | |||||||||||
Standby Power Consumption | ＜3W | |||||||||||
(2)WORKING ENVIRONMENT | Operating Temperature | 0℃-38℃ | ||||||||||
Working Humidity | 10%-95% | |||||||||||
Storage Temperature | 0℃-40℃ | |||||||||||
Storage Humidity | 10%-95% | |||||||||||
(3)ACCESSORIES | Bracket | \\ | ||||||||||
Power Cable | 1 PC | |||||||||||
Manual | 1 PC | |||||||||||
Warranty Card | 1 PC | |||||||||||
Certificate of Conformity | 1 PC | |||||||||||
(4)PHYSICAL PARAMETERS | Screen Size | 43" | ||||||||||
Net Weight | KGS | |||||||||||
Gross Weight | KGS | |||||||||||
Machine Dimension | MM(H)* MM(W)* MM(D) | |||||||||||
Package(Carton) Dimension | MM(H)* MM(W)* MM(D) | |||||||||||
