Новая система IP-кодера IPTV MPEG4 AVC/H.264/H265 кодирование видео HD 2/4/8 // 16/24 каналов
- Категория: TV Receivers & Accessories >>>
- Поставщик: Yantai,Yatai,Photoelectricity,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 0.98 $* | 0.88 $* |
| Aug-20-2025 | 0.37 $* | 0.46 $* |
| Jul-20-2025 | 0.57 $* | 0.51 $* |
| Jun-20-2025 | 0.24 $* | 0.74 $* |
| May-20-2025 | 0.21 $* | 0.16 $* |
| Apr-20-2025 | 0.25 $* | 0.82 $* |
| Mar-20-2025 | 0.47 $* | 0.81 $* |
| Feb-20-2025 | 0.91 $* | 0.52 $* |
| Jan-20-2025 | 0.11 $* | 0.76 $* |
Характеристики
Offer
Product Overview
Key Features
l Support 2/4/8//16/24 HDMI inputs, with2/4/ 8/16/24 SPTS output (each encoder module, only support STPS, NO MPTS), max 24 HDMI inputs
l MPEG4 AVC/H.264/H265 video encoding format
l MPEG1 Layer II, LC-AAC,HE-AAC audio encoding format and AC3 Pass Through, and audio gain adjustment
l Support IP Output over UDP (Unicast/Multicast), SRT, RTSP, RTP, RTMP, HTTP, HLS, M3U8
l Support QR code, LOGO, caption insertion (Language Supported: English,for more languages please consult us…)
l Support “Null PKT Filter” function
l Control via web management, and easy updates via web
HDMI Encoding Section | ||
Video | Encoding | HEVC/ H.265 , MPEG 4 AVC/H.264 |
Interface | 2/4/8/16/24 HDMI input | |
Resolution | 1920*1080_60P, 1920*1080_50P; 1920*1080_59.94P, 1280*720_60p, 1280*720_59.94 1280*720_50P | |
Chroma | 4:2:0 | |
Bitrate | 1Mbps~15Mbps | |
Rate Control | CBR/VBR | |
GOP Structure | IP | |
Audio | Encoding Format | MPEG-1 Layer 2, LC-AAC, HE-AAC, HE-AAC V2; AC3 Pass-through |
Sample rate | 32KHz,44.1KHz,48KHz | |
Bit-rate | 48~384Kbps | |
Stream output | IP out over UDP (Unicast/Multicast),SRT, RTP,RTSP, RTMP, HTTP, HLS (RJ45, 1000M ) (8 HDMI inputs with 8 SPTS for each encoder board) | |
System function | Network management(WEB) | |
Chinese and English language | ||
Ethernet software upgrade | ||
Miscellaneous | Dimension (W×L×H) | 482mm×328mm×44mm |
Environment | 0~45℃(work);-20~80℃(Storage) | |
Power requirements | AC 110V± 10%, 50/60Hz, AC 220 ± 10%, 50/60Hz | |
