SOCMA 4 тонны Электрический Небольшой

Цена:14 200,00 $ - 16 500,00 $*

Количество:

Product Overview

FB450 5 Ton Electric Froklift

PRODUCT SPECIFICATIONS

Model							FB440
Characteristic	Rated lifting weight			kg	4000
		Load center distance			mm	500
		Overhang			mm	350
		Front overhang			mm	494.5
		Wheelbase			mm	1800
		total weight (No load With battery)			kg	5150
size	Total length (To vertical surface of fork)			mm	2595
		Total width			mm	1274
		Height of overhead guard			mm	2140
		Standard mast height that does not rise			mm	2120
		Standard mast Maximum stretch height			mm	4080
		Maximum fork height (Rated lifting weight)			mm	3000
		Standard mast inclination( Lean forward/Reclining)			deg	7/7
		Ground clearance of frame			mm	130
		Standard mast Free lifting height			mm	140
		Turning radius (Smallest outside)			mm	145
		Minimum theoretical width of right-angle channel			mm	2280
		Minimum theoretical width of right-angle stacking channel			mm	2340
		Fork pitch range			mm	4280
		The smallest x The largest			mm	250x1100
performance	Maximum travel speed (No load)			Km/h	19/17.5
		Lifting speed (fully loaded/No load)			Mm/s	450/550
		speed of decent(fully loaded/No load)			Mm/s	500/500
		Largest traction(fully loaded/No load)			N	17760\\16800
		Maximum grade (fully loaded)			%	20
Tires	Front wheel				23x9-10
Tires		rear wheel				18x7-8
powersystem	Battery(Optional lithium battery)	Voltage	v	80
			Capacity (Optional range)	ah	400 ~ 720
		Travel power of walking motor			KW/RPM	2X7.5
		Lifting motor rated power			KW/RPM	23.5
		Controller form				AC
