TTGO T-камера плюс ESP32-DOWDQ6 8 МБ модуль камеры OV2640 объектив рыбий глаз
- Категория: Digital Cameras >>>
- Поставщик: Shenzhen,Robotlinking,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-16-2025 | 22.92 $* | 22.53 $* |
| Jul-16-2025 | 18.99 $* | 18.15 $* |
| Jun-16-2025 | 21.31 $* | 21.92 $* |
| May-16-2025 | 21.21 $* | 21.33 $* |
| Apr-16-2025 | 17.47 $* | 17.82 $* |
| Mar-16-2025 | 21.3 $* | 21.58 $* |
| Feb-16-2025 | 21.41 $* | 21.63 $* |
| Jan-16-2025 | 20.18 $* | 20.96 $* |
Характеристики
TTGO T-Camera Plus ESP32-DOWDQ6 8MB Camera Module OV2640 Fish-Eye Lens Rear Camera
This is a TTGO T-Camera Plus Camera Module OV2640 1.3 Inch Display Rear Camera Fish-eye Lens Rear Camera. The lens is used to transfer the image and data transmission.
Features:
1. The camera can be extended to become a rear camera.
2. This module can transfer images and data together.
1. The camera can be extended to become a rear camera.
2. This module can transfer images and data together.
Package Includes:
1 x TTGO T-Camera Plus Camera Module OV2640 1.3 Inch Display Rear Camera Fish-eye Lens Rear Camera
1 x TTGO T-Camera Plus Camera Module OV2640 1.3 Inch Display Rear Camera Fish-eye Lens Rear Camera
Hardware Specification | ||
Flash | QSPI flash/SRAM,up to 4X16MB | |
SRAM | 520 kB SRAM +8Mbytes External SPRAM | |
Button | Reset | |
USB to TTL | cp2104 | |
Power indicator lamp | red | |
Display | IPS Panel ST7789/ 1.3 Inch | |
Working voltage | 2.3-3.6v | |
Working current | About 160mA | |
Camera | OV2640 2Megapixel | |
on-board clock | 40Mhz crystal oscillator | |
Working temperature | -40~85 ℃ | |
Size&Weight | 51.52mm*25.04mm*8.54mm(7.81g) | |
Power Supply | ||
Power supply | USB 5V/1A | |
Battery | 3.7v lithium battery | |
Charging current | 1A | |
