10tpd машина для переработки использованных шин пиролиза
- Категория: Rubber Recycling Machinery >>>
- Поставщик: Xinxiang,Huayin,Renewable,Energy,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 45220.60 $* | 47481.87 $* |
| Aug-16-2025 | 44840.42 $* | 47082.47 $* |
| Jul-16-2025 | 37620.45 $* | 39501.16 $* |
| Jun-16-2025 | 44080.63 $* | 46284.29 $* |
| May-16-2025 | 38380.44 $* | 40299.36 $* |
| Apr-16-2025 | 43320.74 $* | 45486.91 $* |
| Mar-16-2025 | 42940.21 $* | 45087.46 $* |
| Feb-16-2025 | 42560.11 $* | 44688.5 $* |
| Jan-16-2025 | 42180.55 $* | 44289.72 $* |
Характеристики
Products Description
Waste tyre pyrolysis is an advanced technology that can turn the waste into useful resources : Pyrolysis oil , carbon black , steel wire. It not only solves the problem of waste tires polluting the environment, but also brings benefits to people. At present, we have helped thousands of customers install and debug equipment, and our equipment and services have received praise from customers all over the world
Product Paramenters
Model | HY-05 | HY-08 | HY-10 | HY-15 | HY-30 | ||||
Capacity | 5 t/d | 8 t/d | 10 t/d | 15 t/d | 30-50 t/d | ||||
Working Type | Batch | Batch | Batch | Batch | Continuous | ||||
Reactor size(m) | D2.2*L5.5 | D2.6*L6.6 | D2.8*L6.6 | D2.8*L8.1 | D1.2*L24 | ||||
Reactor material | Q245R | Q245R | Q245R | Q245R | 310S stainless steel | ||||
Power | 29.4KW | 29.4KW | 32KW | 34KW | 100KW | ||||
Heating Fuel | Pyrolysis oil /coal/ wood/natural gas ( if you use fuel oil gas heating material , then the oil burners are required | ||||||||
Burners | 3*300,000 kcal | 3*300,000 kcal | 3*300,000 kcal | 4*300,000 kcal | 12*30000kcal | ||||
Working pressure | Normal | Normal | Normal | Normal | Normal | ||||
Landing Area | 200m2 | 250m2 | 300m2 | 350m2 | 700m2 | ||||
Number of Containers | 1*40FR+1*40HQ | 1*40FR+2*40HQ | 1*40FR+2*40HQ | 1*40FR+2*40HQ | bulk cargo | ||||
Noise (dB) | ≤60 | ≤60 | ≤60 | ≤60 | ≤60 | ||||
Cooling Mode | Circle Water | Circle Water | Circle Water | Circle Water | Circle Water | ||||
Our Advantages
1. High efficiency. The feeding port of the pyrolysis reactor is 1400mm, so the waste material doesn’t need pretreatment, it can be put into the pyrolysis reactor directly with the auto feeder machine.
2. High stability. The rollers are engineered underfeeding port and oil outlet port which are external from the heating area to bring perfect rotating balance and longer service life.
3. Energy saving: Non-condensable gas will go back to the heating system for second burning as heating material, saving your heating fuel.
4. High oil yield: Larger condensation area to ensure sufficient condensation of oil gas into liquid oil.
5. Eco-friendly: The stainless steel deduster is filled with ceramic filters inside, which brings it strong dust adsorption capacity and a good dedusting effect.
6. High safety level: Equipped with Alarm, auto pressure releasing device, anti backfire device, vacuum pump to ensure the machine working smoothly.
2. High stability. The rollers are engineered underfeeding port and oil outlet port which are external from the heating area to bring perfect rotating balance and longer service life.
3. Energy saving: Non-condensable gas will go back to the heating system for second burning as heating material, saving your heating fuel.
4. High oil yield: Larger condensation area to ensure sufficient condensation of oil gas into liquid oil.
5. Eco-friendly: The stainless steel deduster is filled with ceramic filters inside, which brings it strong dust adsorption capacity and a good dedusting effect.
6. High safety level: Equipped with Alarm, auto pressure releasing device, anti backfire device, vacuum pump to ensure the machine working smoothly.
Our Service
The engineer will be sent to your place to Guide Installation, Test running, and Training of workers.
Besides, Installation preparation manuals will be sent to you so that you can do relevant preparation work before our engineer arrives. 3D drawing, layout drawing, and foundation drawing will be provided based on your land size and other specific requirements.
Besides, Installation preparation manuals will be sent to you so that you can do relevant preparation work before our engineer arrives. 3D drawing, layout drawing, and foundation drawing will be provided based on your land size and other specific requirements.
Company Profile
Xinxiang Huayin Renewable Energy Equipment Co.,Ltd. is located in Xinxiang City, Henan Province, which is specialized in manufacturing waste tires/plastics to fuel oil pyrolysis machine and waste oil to diesel distillation machine since 1993. we have obtained many invention patents, CE, SGS, ISO9001 and ISO14001 certifications . our plants have been exported to over 86 countries around the world .
Our main product : Batch and continuous waste tyre/plastic pyrolysis plant , oil sludge pyrolysis plant , waste oil recycling to diesel plant , aluminum scrap pyrolysis plant.
Our main product : Batch and continuous waste tyre/plastic pyrolysis plant , oil sludge pyrolysis plant , waste oil recycling to diesel plant , aluminum scrap pyrolysis plant.
Customer Photos
FAQ
1. What is the price of one complete set of waste pyrolysis plants?
The price of the pyrolysis plant depends on the configuration, and capacity, please contact us to get the latest quotation.
2. What payment methods do you accept?
A: We can accept T/T, L/C, Western Union.
3. Does waste pyrolysis plants pollute the environment?
With a powerful de-dusting system, the smoke will be desulfurization and purified before being discharged out. SGS emission reported provided.
4. How many countries have your machines been exported to?
HUAYIN equipment has been exported to over 80 countries including Romania, Hungary, Turkey, Slovakia, Ecuador, Guatemala, Haiti, Mexico, Peru, Canada, Jordan, UAE, Lebanon, Italian, Chile, Poland, England, Thailand, Greece, Mexico, Benin, Indonesia, India, Singapore, Russia, etc.
5. Regarding after sales service ?
The engineer will be sent to your place to Guide Installation, Test running, and Training of workers.
Besides, Installation preparation manuals will be sent to you so that you can do relevant preparation work before our engineer arrives. 3D drawing, layout drawing, and foundation drawing will be provided based on your land size and other specific requirements.
The price of the pyrolysis plant depends on the configuration, and capacity, please contact us to get the latest quotation.
2. What payment methods do you accept?
A: We can accept T/T, L/C, Western Union.
3. Does waste pyrolysis plants pollute the environment?
With a powerful de-dusting system, the smoke will be desulfurization and purified before being discharged out. SGS emission reported provided.
4. How many countries have your machines been exported to?
HUAYIN equipment has been exported to over 80 countries including Romania, Hungary, Turkey, Slovakia, Ecuador, Guatemala, Haiti, Mexico, Peru, Canada, Jordan, UAE, Lebanon, Italian, Chile, Poland, England, Thailand, Greece, Mexico, Benin, Indonesia, India, Singapore, Russia, etc.
5. Regarding after sales service ?
The engineer will be sent to your place to Guide Installation, Test running, and Training of workers.
Besides, Installation preparation manuals will be sent to you so that you can do relevant preparation work before our engineer arrives. 3D drawing, layout drawing, and foundation drawing will be provided based on your land size and other specific requirements.
