Коаксиальный двойной ротор Интеллектуальное распознавание Ии и автоматическое отслеживание дрона защита UVA
- Категория: Aircraft >>>
- Поставщик: Chengdu,Lipao,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 595.90 $* | 625.20 $* |
| Aug-17-2025 | 590.65 $* | 620.8 $* |
| Jul-17-2025 | 495.56 $* | 520.55 $* |
| Jun-17-2025 | 580.6 $* | 609.81 $* |
| May-17-2025 | 505.76 $* | 530.64 $* |
| Apr-17-2025 | 570.30 $* | 599.3 $* |
| Mar-17-2025 | 565.16 $* | 593.48 $* |
| Feb-17-2025 | 560.17 $* | 588.82 $* |
| Jan-17-2025 | 555.87 $* | 583.9 $* |
Характеристики
The fuselage size | 110mm*110mm*500mm |
Development size | 750mm*750mm*500mm |
Bare-metal self-weight | 3kg |
The payload | ≯2kg (photoelectric pod + battery + warhead) |
Flight mode | Vertical take-off and landing |
Number of system operators | 1 person |
Operating ambient temperature | - 20 ° to 60 ° C C |
System unfolding time | 1 minute |
System shutdown time | 1 minute |
Battery capacity | 10000mAh –16000mah |
Working voltage | 24V |
Bare-metal self-respect | ≮ 5 MBPS |
Distance | 12KM |
Total Weight | <8kgs |
Name | Indicator |
Flight radius | ≯ 10 km, practical application within 4 km |
Maximum altitude | ≯ 5,000 meters |
Wind Resistance Rating | ≯ 5 levels |
Horizontal flight speed | ≯ 15 m/s |
Vertical ascent speed | ≯ 6.9m/sec |
Hovering accuracy | <0.7M (GPS mode) |
Unladen flight time | ≯ 25 minutes 16000mAh battery + camera pod + AI module |
Payload 0.5kg flight time | ≯ 25 minutes 16,000mAh battery + camera pod + AI module |
Payload 1kg flight time | ≯ 20 min. 16000mAh battery + camera pod + AI module |
Payload 1kg flight time | ≯ 15 minutes 16000mAh battery+camera pod +AI module |
Payload 1.5kg flight time | Forward flight, inverted flight, fixed-point hovering, etc. |
Name | Indicator |
Body Size | 110mm*110mm*500mm |
Expanded size | 750mm*750mm*500mm |
Bare weight | ≯ 3kg |
Payload | ≯ 1.5kg (photoelectric pod + cargo compartment), (upgradeable to 3kg for some parts) |
Flight mode | Vertical takeoff and landing |
Number of system operators | 1 person |
Operating temperature | -20°C to 60°C |
System deployment time | 1 minute |
Battery capacity | 10000mAh-16000mAh |
Working voltage | 24V |
* It is suitable for saturation attack and carries more than 5kg of ammunition. Larger caliber versions are also available. This
product has the characteristics of high reliability, compact structure and highly modular design, small size, good hovering
effect, foldable, and can be carried by a single soldier with many pieces of equipment, the main advantages are reflected in
* (1) Easy to carry, fast deployment and deployment, no special site requirements;
* (2) Intelligent flight management, vertical takeoff and landing, one-button start and stop, easy to operate;
* (3) Light dead weight, heavy load, strong mobility;
* (4) Good concealment, low noise, and good low interception;
product has the characteristics of high reliability, compact structure and highly modular design, small size, good hovering
effect, foldable, and can be carried by a single soldier with many pieces of equipment, the main advantages are reflected in
* (1) Easy to carry, fast deployment and deployment, no special site requirements;
* (2) Intelligent flight management, vertical takeoff and landing, one-button start and stop, easy to operate;
* (3) Light dead weight, heavy load, strong mobility;
* (4) Good concealment, low noise, and good low interception;
* (5) AD hoc network, flexible information interaction between nodes, can achieve cluster distributed cooperative action;
* (6) Intelligent AI recognition and automatic tracking, effective identification of people, vehicles, aircraft and other
battlefield targets and accurate target location, and the implementation of autonomous attacks.
* (7) Mobile phone, tablet delimit any point, line, fixed point cruise;
* (8) Digital cluster control
* (6) Intelligent AI recognition and automatic tracking, effective identification of people, vehicles, aircraft and other
battlefield targets and accurate target location, and the implementation of autonomous attacks.
* (7) Mobile phone, tablet delimit any point, line, fixed point cruise;
* (8) Digital cluster control
