NGI N8352 2-канальный Высокоточный Многофункциональный симулятор батареи для тестирования электрического
- Категория: Other Electronic Measuring Instruments >>>
- Поставщик: Hunan,Next,Generation,Instrumental,T&c,Tech,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 107.97 $* | 112.80 $* |
| Aug-19-2025 | 106.45 $* | 111.13 $* |
| Jul-19-2025 | 89.37 $* | 93.59 $* |
| Jun-19-2025 | 104.40 $* | 109.52 $* |
| May-19-2025 | 91.12 $* | 96.86 $* |
| Apr-19-2025 | 103.7 $* | 108.86 $* |
| Mar-19-2025 | 102.69 $* | 107.70 $* |
| Feb-19-2025 | 101.6 $* | 106.15 $* |
| Jan-19-2025 | 100.23 $* | 105.19 $* |
Характеристики
Product Introduction
The price is for reference only. Please subject to our formal quotation.
N8352 series is specially designed for the R&D and test of portable battery-operated products, such as Bluetooth headsets,mobiles, AR/VR smart terminals, electric tools, etc. The current flows in both directions and can be used as either a power supply,or a load. N8352 is easy to use with touch screen and UI design. The output features are comparable to actual batteries, with fast dynamic response, no overshoot in voltage rise and fall, and stable waveform. The current accuracy is up to μA level, which can test the static power consumption. N8352 is equipped with 4.3 inch touch screen and is with built-in 2-channel DVM, which can be widely used in consumer electronics testing.Main Features
Voltage range: 0-6V/0-15V/0-20V
Current range: -1~1A/-2~2A/-3~3A/-5~5A
Voltage accuracy up to 0.01%+1mV
Voltage ripple noise low to 2mVrms
μA level current measurement
Dual LAN port and RS232 interface
Ultra-fast dynamic response without overshoot
High definition touch screen
Built-in two-channel high-accuracy DVM measurement
Current range: -1~1A/-2~2A/-3~3A/-5~5A
Voltage accuracy up to 0.01%+1mV
Voltage ripple noise low to 2mVrms
μA level current measurement
Dual LAN port and RS232 interface
Ultra-fast dynamic response without overshoot
High definition touch screen
Built-in two-channel high-accuracy DVM measurement
Product Advantages
Current flowing in both directions to make N8352 both a power supply and a load
The current flows in both directions. N8352 can both suck and output current.
The output terminal has a switch module, which can physically disconnect from the external circuit in the closed state.
The output terminal has a switch module, which can physically disconnect from the external circuit in the closed state.
Ultra-fast transient response without overshoot
N8352 series can ensure there is no overshoot in voltage changes under no-load or loading condition, preventing damage to the DUT due to voltage overcharge and over discharge. It can avoid bad effect to product quality. This feature can meet the demand for product test with strict power requirements.
About NGI
NGI is a professional manufacturer of intelligent equipment and test & control instruments, committed to developing, manufacturing battery simulators, power supplies, electronic loads, and many more instruments. The products can be widely used in the industries of battery, power supply, fuel cell, consumer electronics, new energy vehicle, semiconductor, etc.
Technical Data Sheet
Model | N8352A | N8352B | N8352C | N8352D | N8352E | N8352F | |||||
Current | ±1A/CH | ±2A/CH | ±3A/CH | ±5A/CH | ±1A/CH | ±3A/CH | |||||
Voltage | 6V/CH | 6V/CH | 6V/CH | 15V/CH | 20V/CH | 20V/CH | |||||
Power | 6W/CH | 12W/CH | 18W/CH | 75W/CH | 20W/CH | 60W/CH | |||||
Channels | 2CH | ||||||||||
