Высокопроизводительная ударная Дробилка 450-520 tph
US $42999-$43200
Качественная Улучшенная передвижная ударная молотковая камнедробилка с высокой эффективностью дробления обладает производительностью
- Категория: Sand Making Machinery >>>
- Поставщик: Shanghai,Jianye,Heavy,Industry,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 7828896.4 $* | 8220341.26 $* |
| Aug-18-2025 | 7763107.83 $* | 8151262.19 $* |
| Jul-18-2025 | 6513115.31 $* | 6838771.72 $* |
| Jun-18-2025 | 7631529.30 $* | 8013105.37 $* |
| May-18-2025 | 6644693.59 $* | 6976928.48 $* |
| Apr-18-2025 | 7499951.25 $* | 7874949.59 $* |
| Mar-18-2025 | 7434162.51 $* | 7805870.8 $* |
| Feb-18-2025 | 7368372.55 $* | 7736791.93 $* |
| Jan-18-2025 | 7302583.85 $* | 7667712.37 $* |
Характеристики
Equipment introduction
Sand-Making Machine, Also Known As Impact Crusher And Sand-Making Machine, Is Suitable For Crushing And Shaping Soft Or Medium Hard And Extremely Hard Materials. It Is Widely Used In Various Ores, Machine-Made Sand Plants, Etc., And Has Higher Output Efficiency Than Other Types Of Crushers For High-Hard And Ultra-Hard Materials.
Equipment parameters
Feeding size： <40mm
Capacity： <600
Application field： It is suitable for gravel, rock, construction waste, tailings, bauxite, quartz and other materials fine
Capacity： <600
Application field： It is suitable for gravel, rock, construction waste, tailings, bauxite, quartz and other materials fine
crushing or sand making, and can also be used for aggregate shaping
Scope of application：Pebbles, rocks (diabase, granite, limestone, basalt, gneiss, etc.), construction waste, gangue, mine
Scope of application：Pebbles, rocks (diabase, granite, limestone, basalt, gneiss, etc.), construction waste, gangue, mine
tailings, etc
Equipment advantage
1. Large processing capacity and high output -- compared with the domestic similar sand making equipment, the output of 6x vertical shaft impact crusher is increased by 30%.
2. Stable performance: compared with similar domestic sand making equipment, 6x vertical shaft impact crusher has low maintenance frequency and short time.
3. Low energy consumption: compared with similar domestic sand making equipment, the energy consumption of 6x vertical shaft impact crusher is reduced by 25%.
4. Low consumption of wearing parts --- ideal impact angle, reasonable material impact speed design and less friction between wear-resistant parts, 30% lower than the operation cost of domestic similar products, directly reduce the use cost of 6x series impact crusher, and greatly improve the profit margin of 6x vertical shaft impact crusher.
5. The finished product has good grain shape, which is hexahedral polyhedron, and is suitable for shaping machine-made sand and stone. It has been proved by many customers that the comprehensive effect of sand making and shaping is improved by 30% compared with other domestic equipment with the same power.
2. Stable performance: compared with similar domestic sand making equipment, 6x vertical shaft impact crusher has low maintenance frequency and short time.
3. Low energy consumption: compared with similar domestic sand making equipment, the energy consumption of 6x vertical shaft impact crusher is reduced by 25%.
4. Low consumption of wearing parts --- ideal impact angle, reasonable material impact speed design and less friction between wear-resistant parts, 30% lower than the operation cost of domestic similar products, directly reduce the use cost of 6x series impact crusher, and greatly improve the profit margin of 6x vertical shaft impact crusher.
5. The finished product has good grain shape, which is hexahedral polyhedron, and is suitable for shaping machine-made sand and stone. It has been proved by many customers that the comprehensive effect of sand making and shaping is improved by 30% compared with other domestic equipment with the same power.
Working principle
Central feeding: the material falls into the waterfall feeding device, enters into the high speed rotating rotor through the
central feeding hole of 6x impact crusher, and then is fully accelerated and thrown out through the launching port. It first
collides with a part of the material which rebounds and then falls freely, and then impacts on the vortex lining in the
surrounding vortex chamber, and then rebounds to the top of the crushing chamber, A continuous material curtain is formed by the impact of the deflected downward movement and the material emitted from the impeller channel, and then discharged through the lower discharge port. The central feeding is accompanied by a ring-shaped waterfall: the material falls into the waterfall feeding device, and then falls through the annular hole, and is divided into two strands by the bulk tray. One strand enters the high-speed rotating impeller through the central feeding hole, and the other falls from the periphery of the powder tray. The material entering the impeller is accelerated rapidly in the impeller and then thrown out at high speed. The material entering the impeller first impacts and breaks with another part of the material falling freely around the tray, Then they impact on the vortex material lining in the surrounding vortex chamber, which is first rebounded to the top of the crushing chamber, and then deflected downward to form a continuous material curtain with the materials emitted from the impeller channel, and then discharged through the lower discharge port.
central feeding hole of 6x impact crusher, and then is fully accelerated and thrown out through the launching port. It first
collides with a part of the material which rebounds and then falls freely, and then impacts on the vortex lining in the
surrounding vortex chamber, and then rebounds to the top of the crushing chamber, A continuous material curtain is formed by the impact of the deflected downward movement and the material emitted from the impeller channel, and then discharged through the lower discharge port. The central feeding is accompanied by a ring-shaped waterfall: the material falls into the waterfall feeding device, and then falls through the annular hole, and is divided into two strands by the bulk tray. One strand enters the high-speed rotating impeller through the central feeding hole, and the other falls from the periphery of the powder tray. The material entering the impeller is accelerated rapidly in the impeller and then thrown out at high speed. The material entering the impeller first impacts and breaks with another part of the material falling freely around the tray, Then they impact on the vortex material lining in the surrounding vortex chamber, which is first rebounded to the top of the crushing chamber, and then deflected downward to form a continuous material curtain with the materials emitted from the impeller channel, and then discharged through the lower discharge port.
Technology advantage
Model | Lmpeller speed(r/min) | Max feeder size(mm) | Power(kw) | Capacity(t/h) | Overalldimensions(L/WH)(mm) | Overall dimensions(mm) |
JY6X9026 | 1200-1500 | 40 | 132*2 | 100-210 | 4510*2400*2860 | 2400*1560*2600 |
JY6X1040 | 1100-1420 | 40 | 200*2 | 120-300 | 5570*2520*3120 | 2440*2250*2650 |
JY6X1150 | 1070-1190 | 50 | 250*2 | 180-460 | 5570*2520*3120 | 2700*2340*2900 |
JY6X1263 | 900-1100 | 50 | 315*2 | 260-700 | 5700*2950*3490 | 2700*2690*2890 |
Model | Lmpeller speed(r/min) | Max feeder size(mm) | Power(kw) | Capacity(t/h) | Overalldimensions(L/WH)(mm) |
JYS6020 | 1460-2100 | ≤30 | 60-110 | 30-100 | 3600*2150*2800 |
JYS8623 | 1380-1810 | ≤40 | 150-220 | 60-180 | 4520*2580*3300 |
JYS9928 | 1200-1580 | ≤40 | 180-320 | 100-280 | 4720*2700*3460 |
JYS1238 | 1100-1360 | ≤40 | 220-400 | 150-420 | 4980*2970*3680 |
AFTER-SALES SERVICE AND CONCEPT
PRODUCTION LINE PROFILE
Our Company Has Reliable Products And Experienced Service Team. 1et The Internet Techinology Apply To Every Tache Of Pro-Duct Andoperation. Sale By Internate Actively, Provide The Atest Product Information And Technical Service. We Believyou-Not Only Need a Product, Butalso Good After Service. Based On The Techinology And Quality Products,We Would Provide The Gratfed, Save Worry, Disburden Service For Ouicustomers.PRE-SALE
1.Guide Our Customers To Deploy The Most Useful Equipment Item According To Theirs Requiryment.
1.Guide Our Customers To Deploy The Most Useful Equipment Item According To Theirs Requiryment.
2.Provide Technical Date, Including Equipment Bill, Layout, Base Specification And Installation Picture To Consult,
3.Design And Manufacture Product According To The Customers'Special Requestment.
4.Dispatch The Technical Person To Reach The Locale To Layout Field, Design The Best Installtion Flow And Scheme To Consult For Free.
3.Design And Manufacture Product According To The Customers'Special Requestment.
4.Dispatch The Technical Person To Reach The Locale To Layout Field, Design The Best Installtion Flow And Scheme To Consult For Free.
SALE
1 Product According To The Standard Of Technology Strictly.
1 Product According To The Standard Of Technology Strictly.
2.Experiment The Machine By The Operating Regulate,
3.Verify The Product Before Leaving Factory Strictly,
4.Organize Shipping By The Contract In Time.
3.Verify The Product Before Leaving Factory Strictly,
4.Organize Shipping By The Contract In Time.
AFTER-SALES
1 Dispatch Special Worker After Service To Arrive Locale To Guide The User To Install And Debug, Experiment Circulate, Train Operating Persons For Free.
1 Dispatch Special Worker After Service To Arrive Locale To Guide The User To Install And Debug, Experiment Circulate, Train Operating Persons For Free.
2. Guarantee Of Repair, Replacement And Refund Of Substandard Products, The Period Of Guarantee Is 1 Year(Except Abrasion In Normal, Wearing Parts, The Damaged Parts By Misoperation) If The Equipment Appears Fault During Guarantee, Our Company Woulde To Reach The Locale After Take The User's Telephone, Remove The Fault, Ensure The User's Produce Innormal.
