Бульдозер New 120hp 160hp 165hp 220hp колесный бульдозер на
- Категория: Bulldozers >>>
- Поставщик: Shandong,Chengda,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-16-2025 | 50799.21 $* | 51815.48 $* |
| Jul-16-2025 | 41199.45 $* | 42023.4 $* |
| Jun-16-2025 | 49999.64 $* | 50999.30 $* |
| May-16-2025 | 49599.24 $* | 50591.36 $* |
| Apr-16-2025 | 39599.27 $* | 40391.78 $* |
| Mar-16-2025 | 48799.71 $* | 49775.31 $* |
| Feb-16-2025 | 48399.87 $* | 49367.22 $* |
| Jan-16-2025 | 47999.73 $* | 48959.39 $* |
Характеристики
Earth-Moving Machinery Bulldozers Ripper Crawler Dozer 80hp 160hp 180hp 220hp Bulldozers
A bulldozer is an earth-moving machine capable of excavating, transporting and discharging rock and soil, and is widely used in open-pit mines. For example, it is used for building dumps, leveling automobile dumps, stacking scattered ore rocks, leveling work flats and construction sites, etc. It is not only used for auxiliary work, but also for main mining work. For example: stripping and mining of placer deposits, traction and boosting of scrapers and rock plows, cooperation with other earthmoving machinery to
reduce the height of stripping steps in non-transport mining methods, etc.
reduce the height of stripping steps in non-transport mining methods, etc.
Model | SD16 standard | SD16 Coal type | |
Work performance | |||
Operation weight | 17000kgs | 17370kgs | |
Engine power | 120/160 kw/hp | 120/160 kw/hp | |
Min.turn radius | 4466mm | 4466mm | |
Ground pressure | 58kpa | 59.2kpa | |
Engine | |||
Engine model | WP10G178E355 | WP10G178E355 | |
Displacement standard | Euro III | Euro III | |
Type | Inline Direct injection Four-stroke Turbocharged | Inline Direct injection Four-stroke Turbocharged | |
Displacement | 9.726L | 9.726L | |
Rated power/speed | 131/1850 kw/rpm | 131/1850 kw/rpm | |
Max.torque | 830/(1000-1200) | 830/(1000-1200) | |
Overall dimension | |||
L | 5140mm | 5427mm | |
W | 3388mm | 3900mm | |
H | 3032mm | 3032mm | |
Walking performance | |||
Forward/Reverse(km/h) | 0-3.29, 0-5.82, 0-9.63, 0-4.28, 0-7.59, 0-12.53 | 0-3.29, 0-5.82, 0-9.63, 0-4.28, 0-7.59, 0-12.53 | |
Gradeability | 30 deg | 30 deg | |
Ground clearance | 400mm | 400mm | |
Chassis | |||
Suspension type | Sigmoid beam swing type, balanced beam suspension structure | Sigmoid beam swing type, balanced beam suspension structure | |
Track center distance | 1880mm | 1880mm | |
Track shoe width | 510/560/610mm | 610mm | |
Ground contact length | 2430mm | 2430mm | |
Number of track shoes | 37pcs | 37pcs | |
Track pitch | 203mm | 203mm | |
Number of supporting wheels | 2 | 2 | |
Number of supporting wheels | 6 | 6 | |
Hydraulic system | |||
Work pump | Fixed gear pump | Fixed gear pump | |
Work valve | Multi-way valve | Multi-way valve | |
Lift cylinder bore | Ø110 | Ø110 | |
Inclined cylinder bore | Ø160 | Ø160 | |
Oil Tank | |||
Fuel tank | 315L | 315L | |
Hydraulic oil tank | 110L | 110L | |
Work Equipment | |||
Blade | Angle, straight/U type | Coal type | |
Blade width | 3970mm, 3388mm, 3556mm | 3900mm | |
Blade height | 1040mm, 1149mm, 1120mm | 1235mm | |
Work volume | 4.3m3, 4.5m3, 5m3 | 6.04m3 | |
Blade lift height | 1095mm | 1095mm | |
Shovel depth | 540mm | 540mm | |
Ripper | 3 teeth | ||
Operation type | |||
Walking | Mechanical | Mechanical | |
Working | Mechanical | Mechanical | |
Shandong ChuangWei Machinery Co., Ltd established in 2005 is one of the qualified manufacturers of construction machine and various trailers.Integrated production, scientific research & development and professional sales teams, all those advantages can provide the full service of trailers, semi-trailers, tractor head, dump truck, engineering machinery and trailer parts, our company is a leading provider in this industry, with annual export value reaching above 50million dollars and revenue almost 600 million yuan RMB.
With high standard machinery and automatic equipment, powerful R&D team and elite sales team, We have built a long business relationship with many world famous enterprises such as SINOTRUK\\SHACMAN\\FAW\\DFAC\\XUGONG Group\\LIUGONG Group\\SEM Group etc.Besides mature after-sale systems, we can meet different needs of customers both home .
Every year our customers from all over the world come to China visit us.They personally inspected our factory and very satisfied with the quality of our products, and established long -term cooperative relationships with our company.
Each year they imported a large number of trucks, trailers and spare parts from our company. So far, about 60% of our company's turnover comes from the repurchase of old customers. We look forward to having long -term cooperation with you.
