Сверхмощная электрическая лебедка JM на 40


Поделиться:


Цена:8 200,00 $ - 8 250,00 $*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-15-2025 9758.87 $* 10246.99 $*
Aug-15-2025 9676.34 $* 10160.37 $*
Jul-15-2025 8118.2 $* 8524.19 $*
Jun-15-2025 9512.12 $* 9988.33 $*
May-15-2025 8282.55 $* 8696.34 $*
Apr-15-2025 9348.71 $* 9815.0 $*
Mar-15-2025 9266.52 $* 9729.43 $*
Feb-15-2025 9184.40 $* 9643.61 $*
Jan-15-2025 9102.57 $* 9557.4 $*

Характеристики





Product description
This electric winch is widely used to install and disassembly various huge and oversize concrete and steel structure as well as mechanical equipment. This electric winch is suitable for bridge construction, port, dock, quay, etc. In a word, it is suitable for large factories, mine engineering, bridge engineering, etc.






Main Features:
The full floating planetary gear reducer makes the operation more stable and the structure more reasonable.
Adopt multi - plate friction normally closed system.
The actuator has high braking torque and safety.
The product has the characteristics of small volume, compact structure and high transmission efficiency .
Has the function of free fly Adopt brand motor, long service life.
The mounting bracket can be manufactured separately according to user's requirement
According to the needs of users, the special winch balance valve, shuttle valve. Adopt manual, pneumatic clutch device.




Product Parameter


Model
Rated Line Pull(KN)
Capacity of drum(m)
Wire rope
Motor
Diameter
(mm)
lifting speed
(m/min)
Motor model
Motor rating
(KW)
JM1
10
100
9.3
15
Y112M-6
3
JM2
20
150
13
16
Y160M-6
7.5
JM3.2
32
200
15.5
12
YZR160M-6
7.5
JM5
50
250
21.5
9.5
YZR160L-6
11
JM8
80
250
26
8
YZR180L-6
15
JM10
100
250
30
8
YZR200L-6
22
JM12
120
300
32
8
YZR225M-6
30
JM16
160
500
37
10
YZR250M-8
37
JM32
320
700
50
9
YZR315S-8
75
JM50
500
700
60
9
YZR315M-8
90


Other products


spider crane
EW3.0 B mini crawler crane, powered by Japanese gasoline engine, Taiwan hydraulic valve, hydraulic pipe fittings, rated lifting capacity of 3 tons, with all lifting functions of spider crane and basic safety configuration. It is widely used in the maintenance and installation of electrical equipment in substations, the maintenance and installation of equipment in mechanical and chemical workshops, and glass curtain walls and other occasions with narrow spaces.


Gantry crane
Gantry crane is a variant of bridge crane, also called gantry crane. Mainly used for outdoor cargo yard, stock yard cargo, bulk cargo loading and unloading operations. Gantry cranes have the characteristics of high site utilization, large operating range, wide adaptability and strong versatility, and are widely used in port freight yards.
Its metal structure is like a door-shaped frame, with two supporting feet installed under the main beam, which can walk directly on the track on the ground, and the two ends of the main beam can have outhanging cantilever beams.


single girder overhead crane
The single-beam bridge crane is a lifting equipment that is horizontally framed over the workshop, warehouse and material yard for material lifting. Because its two ends are located on tall concrete columns or metal supports, it is shaped like a bridge. The bridge frame of the single-beam bridge crane runs longitudinally along the tracks laid on the elevated bridges on both sides, which can make full use of the space under the bridge frame to lift materials without being hindered by ground equipment. It is the most widely used and the largest number of cranes.


Certifications




Company Information
Henan Eternal WinMachinery Equipment Co.,ltd,established in 1998 ,located in crane hometown,which integrates the R&D
,manufacture,sales ,installation and service of all kind of overhead crane , gantry crane ,ship crane ,spider crane ect lifting
equipment . Our products have been famous all over the world , such as overhead crane ,gantry crane ( rail mounted gantry crane,RTG gantry crane ,quay crane ) ,ship crane , spider crane ,jib crane ,hoist ,winch and so on. Eternal win has been “quality first”as a core foundation ,which deploys advanced facilities of the domestic and international brand,owns professional R&D term with more than 600 people.The team is the largest R&D term in China’s general crane industry ,and has won over 80 national provincial man municipal scientific achievements, which lays a solid foundation for producing high quality products. Eternal Win adheres to “ customer-oriented” marketing concept ,owns strong sales term and after service power,who always is ready to provides quality service to our customers Eternal Win insists on the principle of “delicate manufacture,continual improvement,seeking superiority,satisfying customer”and by absorbing management essence home and abroad ,introducing first-class talents,implementing first-class management and manufacturing first-class products .Sincerely cooperating with all the peoples from all walks of lift to realize mutual benefit.




Packaging & Delivery






Customer visit








FAQ
Q 1: WHAT DO I NEED TO OFFER WHEN PURCHASING CRANES FROM YOU?
There are some necessary parameters about the cranes so you can tell us the lifting height,loading weight,span and other details you have. We can offer you a best solution.
Q 2:WHAT PAYMENT METHODS DO YOU HAVE?
You can choose the best way to pay and we have many kinds payment method ,such as westlink, paypal, L/C, T/T. Don't worry about this problem.
Q 3: WHAT AFTER-SALE SERVICE CAN YOU OFFER?
We are a professional machinery company so we will offer 24/7 service and whenever you have any doubts just contact us. We are happy to help you fix them.
Q 4: WHAT TRADE TERMS DO YOU USE?
We often use FOB price and we can change according to your requirements.
Q 5: HOW TO SHIP?
The most often shipment method is by sea,which is cheaper than by air. It depends on clients' decision. We will try our best to help you.
