Маленькая портативная буровая установка

Категория: Mining Machine Parts >>>
Поставщик: Zhengzhou,Kaishan,Mechanical,&,Electrical,Equipment,Co.,Ltd.

Цена:500,00 $ - 600,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-20-2025	595.34 $*	625.90 $*
Aug-20-2025	590.55 $*	620.65 $*
Jul-20-2025	495.51 $*	520.32 $*
Jun-20-2025	580.77 $*	609.69 $*
May-20-2025	505.23 $*	530.23 $*
Apr-20-2025	570.30 $*	599.58 $*
Mar-20-2025	565.14 $*	593.61 $*
Feb-20-2025	560.17 $*	588.84 $*
Jan-20-2025	555.3 $*	583.63 $*

Характеристики

Product Description

It's used for drilling large blast hole.It's especially convenient to be used during the initial period of opencast working,other drill carriage unable to reach,unable to carry on the normal work.

1.High performance-all air driven down the hole drill

2.Simple structure and single dynamic

3.Adapt to any geological feature

4.Easy operating and move

5.Good noise reduction effect, reduce the pollution

Product Paramenters

Model	Hole diameter	Hole depth	Working pressure	Air consumption	Remark
Model		(mm)	(m)	(MPa)	Remark	(m3/min)
KQD 70	60--80	≥15	0.5—0.7	≥3.5	3kw
KQD100B	80--100	≥20	0.5—0.7	≥6	4kw
KQD 100	80--100	≥20	0.5—0.7	≥6	4kw
KQD 120	80-100	≥20	0.5—0.7	≥6	5.5kw
KQD145B	90-130	≥50	0.7-1.4	≥12	7.5kw
KQD150B	90-130	≥50	0.7-1.4	≥12	7.5kw
KQD165	90-150	≥50	0.7-1.4	≥15	11kw

Matched Portable Diesel Screw Air Compressor

Model	CVFY-7/7
Capacity (m³/min)	7
Working Pressure (Mpa)	7
Weight (kg)	2200
Dimension (mm)	280015001850

Hammer :

Weight	11.5kg
Overall Length	777mm
Outside Diamater	57mm
Operating Air pressure	0.49-0.63Mpa
Impact Rate	≥14.5Hz
Air Consumption	≤58L/S
Backhead Thread	(Square) 42101.5
Dia of the hole	Ø60-70mm

Related Products

Company Profile

Zhengzhou Kaishan Mechanical & Electrical Equipment Co., Ltd.Our company are specialized in this filed for over 25 years with high quality and competitive price. We provide various kinds of high-end rock drilling equipment and air compressors, including borehole drilling rig, screw air compressor, industrial piston air compressor, and construction tools and parts. These products have been widely used in many industries like open pit mines, quarry and construction projects of railway, road, hydroelectric power station, and buildings.We aims at producing and selling high-quality product and providing high quality pre-sale and after-sale service.
Welcome to contact us if you are interested in our products. In addition to our standard products listed on this website, we can also provide OEM and ODM services. Besides, you are also welcome to become one of our agents around the world.

Exhibition

Certifications

FAQ

Q1: Are you a manufacturer?
A: Yes, we are a professional down the hole drill rig and top hammer drill rig manufacturer.
Q2: What does your company produce?
A: The main products of our company include blasting drilling rig,water well drilling rig and all kinds of air compressors.
Q3: How about your delivery time?
A: Normally the delivery time is about 7-15 days. For some special case, we can make it within 2 weeks, it depends on different products.
Q4: What methods of payment do you accept?
A: We accept T/T, L/C.
Q5: Do you offer any deals or discounts?
A: Yes, price depends on different quantity, different quantity will give you different price.
