Доступная портативная волоконная лазерная маркировочная машина 20 Вт 30 мини-волоконный лазерный маркер DST Metal Kingdom Key тренировочная мощность
- Категория: Industry Laser Equipment >>>
- Поставщик: Hangzhou,Dongning,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 1904.72 $* | 1999.50 $* |
| Aug-16-2025 | 1888.44 $* | 1982.18 $* |
| Jul-16-2025 | 1584.4 $* | 1663.87 $* |
| Jun-16-2025 | 1856.0 $* | 1949.67 $* |
| May-16-2025 | 1616.4 $* | 1697.6 $* |
| Apr-16-2025 | 1824.91 $* | 1915.63 $* |
| Mar-16-2025 | 1808.22 $* | 1898.33 $* |
| Feb-16-2025 | 1792.99 $* | 1882.35 $* |
| Jan-16-2025 | 1776.5 $* | 1865.40 $* |
Характеристики
Products Description
Laser Machine Features | Laser output power | 20/30W | ||
Laser Generator | Fiber Laser Generator | |||
Laser wavelength | 1064nm | |||
Marking speed | ≦7000mm/s | |||
control board | Industrial grade highly integrated all-in-one motherboard | |||
Operating platform | Built-in 8-inch touch screen | |||
Cooling system | Normal temperature air cooling (no compressed air required) | |||
Interface | USB interface | |||
Interface Power Requirements | Lithium battery power supply lasts for 6-8 hours, rechargeable and plug-in | |||
power requirements | AC220V,50-60Hz | |||
Product size | 28*18*25cm | |||
Package size | 50.5*48*36cm | |||
Controller weight | 9kg | |||
Printing Head weight | 1.8kg | |||
Storage environment temperature | -10 ℃ - 45℃ (no freezing) | |||
Working temperature | 10% -85%（non-condensing） | |||
Working environment humidity | 10% -85%（non-condensing） | |||
Marking range | Standard 110*110mm | |||
Up to mark line type | Dot matrix, vector | |||
Minimum Line Width | 0.01mm | |||
Accurate repeat positioning | 0.01mm | |||
The number of character lines that meet the standard | Edit freely within the marking range | |||
Character type | Support font type | Single-line font, double-line font, dot-matrix font | ||
Graphics file type | PLT format vector file input and output | |||
Graphic element | Point, line, arc text, rectangle, circle | |||
Variable text | Serial number, time, date, counter, shift | |||
Barcode type | Code39, Code93,Code128, EAN-13 | |||
Configuration parameters | ||||
Description | Specification | |||
Fiber Laser System | 20/30w | |||
Scanning system | High-Speed digital galvanometer | |||
Operating system | 8 inch touch screen | |||
Focusing field lens | F=160mm | |||
Powered by | Lithium battery | |||
Switch | Metal snap button | |||
Chassis | Sheet metal | |||
Product Detail
Recommend Products
Company Profile
Exhibition
Certifications
FAQ
Q1. Can this printer print my product?
A: We have water-based ink cartridge and quick dry ink cartridge to suit different materials. Most of the products can be printed
with EXP date, batch code, bar code, QR code, serial number, logo and other printing information.
Q2. Can the mark be erased?
A: No, if you do not scrape with hard tool, it can not be erased.
Q3. How long will it take for the ink to become dry?
A: 3-5 seconds.
Q4. How can I know your machine works well?
A: Before delivery, we have tested every machine and adjusted it to the best condition. If you have special production condition,
we could also adjust the machine for you.
Q5.Can you ship the machine to my address?
A:Yes, we could use DHL to express the machine. While transport cost will be higher. Also, it is suitable for the small models.
Q6. Where are you? Can we go to China and visit your factory?
A:Yes, of course. We are in Hangzhou,China. Welcome to our factory.
Q7:Do you have manual with the machine?
A:Yes, of course. It is in English version.
Q8:Do you have other color inks?
A: Yes, We have white, yellow, red, green, blue, black these color for you choice.
A: We have water-based ink cartridge and quick dry ink cartridge to suit different materials. Most of the products can be printed
with EXP date, batch code, bar code, QR code, serial number, logo and other printing information.
Q2. Can the mark be erased?
A: No, if you do not scrape with hard tool, it can not be erased.
Q3. How long will it take for the ink to become dry?
A: 3-5 seconds.
Q4. How can I know your machine works well?
A: Before delivery, we have tested every machine and adjusted it to the best condition. If you have special production condition,
we could also adjust the machine for you.
Q5.Can you ship the machine to my address?
A:Yes, we could use DHL to express the machine. While transport cost will be higher. Also, it is suitable for the small models.
Q6. Where are you? Can we go to China and visit your factory?
A:Yes, of course. We are in Hangzhou,China. Welcome to our factory.
Q7:Do you have manual with the machine?
A:Yes, of course. It is in English version.
Q8:Do you have other color inks?
A: Yes, We have white, yellow, red, green, blue, black these color for you choice.
