Трехосевой экскаватор BERKLEY низкорамный прицеп с наклонной горкой
- Категория: Truck Trailers >>>
- Поставщик: Guangzhou,Berkley,Motor,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 1306837.24 $* | 1372179.50 $* |
| Aug-19-2025 | 1295855.28 $* | 1360648.86 $* |
| Jul-19-2025 | 1087200.67 $* | 1141560.24 $* |
| Jun-19-2025 | 1273891.13 $* | 1337586.72 $* |
| May-19-2025 | 1109164.99 $* | 1164622.35 $* |
| Apr-19-2025 | 1251927.17 $* | 1314523.63 $* |
| Mar-19-2025 | 1240946.86 $* | 1302993.34 $* |
| Feb-19-2025 | 1229964.75 $* | 1291462.13 $* |
| Jan-19-2025 | 1218982.91 $* | 1279931.94 $* |
Характеристики
BERKLEY Low Bed Semi Trailer | ||
Item | Spec. | |
BODY CONSTRUCTION | Side Coaming:8mm Thick Cold-Rolled sheet steel. Tensile Strength = 650mPa | |
Flooring: 5mm Chequer-Plate flooring, mild steel at 350mPa tensile. Under-Floor construction consists of heavy duty I-Beam cross-members, with 30 x 30 x 3mm under-floor runners for extra support. | ||
Skid-Plate: 12mm Thick Skid-Plate, with two position bolt-on king pin boss-plates fitted as standard. | ||
Road-Train Bracket: 20mm thick folded C-Channel. With extra support gussets. Constructed from 350mPa mild steel. | ||
Rear Tail-Gate: Standard ADR construction: Industrial C-250 channel – with multiple supports welded. Standrad rear bumper bar installed (constructed from 100 x 100 x 6mm RHS) | ||
GENERAL | Length: Overall Length 45 FT (13720mm)- including the ramps | |
Width: Exterior: 2500mm | ||
Height: 20 inch axles: 1100mm, 19.5 inch axles: 995mm, 15 inch axles: 920mm | ||
Capacity (ATM): 45 Tonnes | ||
Capacity GTM): 25 Tonnes | ||
Tare Weight: | Without Bi-Fold Ramps: 9.8 Tonnes With Bi-Fold Ramps: 10.5 Tonnes | |
Axle: | 3/4 Axles *13/16 Ton FUWA/BPW/BERKLEY/Other | |
Tire: | 12R22.5/8.25r20 (12/16 Pieces) Linglong/Triangle/Double-Coin/Bridgestone/Other | |
Rim: | 9.00*22.5/6.5-20 (12/16 Pieces) Steel/Aluminum | |
Leaf Spring: | 90mm*13mm*10/90mm*16mm*10 | |
Suspension System: | Mechanical or Air Suspension | |
Ladder: | Mechanical Spring/Hydraulic | |
Kin Pin: | JOST 50mm or 90mm available. | |
Landing Gear: | JOST A400 Landing Gear (JOST E100 Also used). | |
Tool Box: | Steel or Aluminum | |
Chassis Beams I-Beam Construction: | 20mm thick Flange plates (350mPa), 6mm Webbing plate (450mPa) – Half the chassis webbing is double plated for heavy duty construction. | |
Pictures and configuration information are for reference only.The final product can be made according to specific requirements. | ||
Above Information are Berkley Standard Spec.If customer want to change Spec.Please Let us know. Want to know more details,please contact us directly. | ||
High Precision CNC Plasma Cutting Machine
Powder Coating
Portal tank longitudinal seam automatic welding
2500 ton CNC bending machine
Super large plate width single-sided welding double-sided forming and imposition welding machine
Tank Trailer
Bulk Cement Trailer
Dump Trailer
Flatbed Trailer
LowbedTrailer
Car Carrier Trailer
Q1. Are you a factory or trading company?
Q2. Could you accept special design and specification?
Q3. Are you looking for an agent?
Q4. Do you have stock?
Q5. How to control quality?
We are a comprehensive factory integrating product design, scientific research and development, production and sales. So we know what you're looking for. Welcome to our factory and production line at any time.
Q2. Could you accept special design and specification?
Sure of course. As we all know that the traffic regulations are different in different areas, our professional engineers will design and our well-trained staff will produce according to customer special requirements. Such as: special Size, special control, or OEM, etc.
Q3. Are you looking for an agent?
Yes, we're looking for the agent all over the world, you are welcome to contact us for further discussion.
Q4. Do you have stock?
Yes we have a few stock in our warehouse for your urgent order, but the main design already finished, the only we can change are some of the spare parts such like tires, axles, stickers, painting etc.
Q5. How to control quality?
We set up all process inspection and quality control standard, include raw materials, production process, finished products. Advanced equipment and standard inspection process ensure the quality.
