Хит продаж, высокопрочный насос для бетонных насосов
US $4800-$5300
2023 насос бетонный гидравлический для бетономешалки грузовик
- Категория: Concrete Pumps >>>
- Поставщик: Contrust,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 15470.33 $* | 16244.66 $* |
| Aug-19-2025 | 15340.72 $* | 16107.49 $* |
| Jul-19-2025 | 12870.78 $* | 13514.5 $* |
| Jun-19-2025 | 15080.67 $* | 15834.50 $* |
| May-19-2025 | 13130.55 $* | 13787.67 $* |
| Apr-19-2025 | 14820.30 $* | 15561.58 $* |
| Mar-19-2025 | 14690.13 $* | 15425.94 $* |
| Feb-19-2025 | 14560.52 $* | 15288.30 $* |
| Jan-19-2025 | 14430.10 $* | 15152.96 $* |
Характеристики
Product Description
A concrete pump is a machine used for transferring liquid concrete by pumping.
The pump works by one piston drawing liquid concrete into a cylinder from a hopper while the other one simultaneously pushes its concrete out into the discharge pipes.
The Concrete Pump was particularly important in revolutionising the construction of large high rise buildings.
The pump works by one piston drawing liquid concrete into a cylinder from a hopper while the other one simultaneously pushes its concrete out into the discharge pipes.
The Concrete Pump was particularly important in revolutionising the construction of large high rise buildings.
Advantages
Easy Maintenance
The easy access to all the parts of the machine ensures that maintenance requires the minimum time for maintenance so your machine is up and running in no time at all.
Pumping
The pump has two powerful differential and pumping cylinders. The prodigious combined capacity and performance of these cylinder systems ensures a high output. Our pumps are designed to offer you maximum output with minimum number of strokes to increase the life of the cylinders. Affordability, fuel efficiency, best in class productivity are some of the best features of Contrust pump.
The easy access to all the parts of the machine ensures that maintenance requires the minimum time for maintenance so your machine is up and running in no time at all.
Pumping
The pump has two powerful differential and pumping cylinders. The prodigious combined capacity and performance of these cylinder systems ensures a high output. Our pumps are designed to offer you maximum output with minimum number of strokes to increase the life of the cylinders. Affordability, fuel efficiency, best in class productivity are some of the best features of Contrust pump.
Details Images
Inside details of concrete pump
Inside details of concrete pumping machine
Cement pump accessories
Trailer pump automatic control panel
Concrete pump machine pipe
Ready mixed concrete pumping tube
● The special pouring pump for secondary structure fine stone mortar can realize the transportation of fine stone concrete and mortar for long-distance high-rise buildings.
● The distribution valve adopts advanced S-tube valve, which has good sealing performance and simple and reliable structure.
● The eye plate (commonly known as wear plate) and floating cutting ring are made of hard alloy, which has good wear resistance, long service life and convenient replacement.
● The machine adopts electric-liquid control mode, with perfect electrc-hydraulic overload protection and instrument display system. It has anti-pump operation function, easy to eliminate blockage fault.
● The centralized lubrication system automatically controls the start and stop and running time by the program, effectively extending the service life of the rotating parts.
● The electrical components such as the contactor and the push button switch are reliable in operation, the control circuit is simple, and the electrical box is equipped with a switch for easy operation.
● The main seals are made of high quality seals to prevent internal and external leakage of the hydraulic system.
● The distribution valve adopts advanced S-tube valve, which has good sealing performance and simple and reliable structure.
● The eye plate (commonly known as wear plate) and floating cutting ring are made of hard alloy, which has good wear resistance, long service life and convenient replacement.
● The machine adopts electric-liquid control mode, with perfect electrc-hydraulic overload protection and instrument display system. It has anti-pump operation function, easy to eliminate blockage fault.
● The centralized lubrication system automatically controls the start and stop and running time by the program, effectively extending the service life of the rotating parts.
● The electrical components such as the contactor and the push button switch are reliable in operation, the control circuit is simple, and the electrical box is equipped with a switch for easy operation.
● The main seals are made of high quality seals to prevent internal and external leakage of the hydraulic system.
Specification
Technical data and parameter | Technical data and parameter |
Low voltage electrical apparatus | Schneider |
Main oil pump | Import Kawasaki 112 |
Eye plate | Alloy |
Ground wheel | Yes |
Filtering system | Double filter |
Motor power（kW） | 37 |
Oil pump displacement(cc) | 112 |
Concrete cylinder (mm) | Ø200 |
Theory Concrete pumping pressure(MPA) | 8 |
Theory concrete output（m³） | 30 |
Delivery distance H/V(M) | 400/100 |
Concrete slump(mm) | 140-230 |
Hopper volume x Feeding height(m^3*mm) | 0.7*1400 |
Total Weight（T） | 4.1 |
Product packaging
Full Container Packing. 20GP. container for 1 unit，40 HQ container for 2 units.
FAQ
● What kind of concrete do you have to choose?
● What is the Minimum Quality Order?
-- The MOQ is 1 set. If you order large amount, you will get discount.
● What is the payment terms?
-- T/T, L/C, Western Union,credit card.
● Which kind of shipment do you support?
-- Sea transportation, air transportation and international express.
● When will you deliver the machine?
-- General machine will take 7-15 workdays after receiving the balance payment. Customized machine will take around 20 days.
● Do you supply training and after-sale service?
-- Yes, we will supply installation and training on site or online. Also we have a professional service team that can solve problems as fast as possible.
● What about the warranty time of machine?
-- 12 months after shipment or 2000 working hours.
-- We have diesel engine and electric motor type. As for capacity, 30, 40, 60, 80 m³ per hour are popular.
● What is the Minimum Quality Order?
-- The MOQ is 1 set. If you order large amount, you will get discount.
● What is the payment terms?
-- T/T, L/C, Western Union,credit card.
● Which kind of shipment do you support?
-- Sea transportation, air transportation and international express.
● When will you deliver the machine?
-- General machine will take 7-15 workdays after receiving the balance payment. Customized machine will take around 20 days.
● Do you supply training and after-sale service?
-- Yes, we will supply installation and training on site or online. Also we have a professional service team that can solve problems as fast as possible.
● What about the warranty time of machine?
-- 12 months after shipment or 2000 working hours.
