Подвесная платформа ZLP630 для покраски подвесная Рабочая оборудование очистки фасадов строительная
- Категория: Work Platforms >>>
- Поставщик: Henan,Ideal,Machinery,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 1785.24 $* | 1874.41 $* |
| Aug-19-2025 | 1770.43 $* | 1859.56 $* |
| Jul-19-2025 | 1485.62 $* | 1559.86 $* |
| Jun-19-2025 | 1740.1 $* | 1827.71 $* |
| May-19-2025 | 1515.90 $* | 1591.52 $* |
| Apr-19-2025 | 1710.47 $* | 1796.89 $* |
| Mar-19-2025 | 1695.54 $* | 1780.15 $* |
| Feb-19-2025 | 1680.16 $* | 1764.43 $* |
| Jan-19-2025 | 1665.24 $* | 1748.34 $* |
Характеристики
High rise building electric window cleaning equipment construction counterweights work gondola suspended platform cradle
Suspended Platform Application:
Glass and aluminum or marble curtain wall/Facade Painting and plastering/Facade Installing an insulating layer/Cleaning windows and so on.
Glass and aluminum or marble curtain wall/Facade Painting and plastering/Facade Installing an insulating layer/Cleaning windows and so on.
Products Description
1. Time-saving and cost-saving alternative to tubular scaffolding
2. Unlimited working height
3. Quick and easy to assemble and install
4. Lightweight and easy to transport
2. Unlimited working height
3. Quick and easy to assemble and install
4. Lightweight and easy to transport
Model | zlp630 | zlp800 | |
Appearance | Painting/hot galvanized | ||
Material | Steel/aluminum alloy | ||
Rated load | 630kg | 800kg | |
Lifting speed | 9-11m/min | 8-10m/min | |
Motor power | 2x1.5kw | 2x1.8kw | |
Brake torque | 2x16kN | 2x16kN | |
Steel rope angle adjusting range | 3°-8° | 3°-8° | |
Distance between two steel rope | ≤100m | ≤100m | |
Counterweight(optional) | 25kgx36pcs | 25kgx40pcs | |
Diameter of steel rope | 8.3mm | 9.1mm | |
Max lifting height(m) | 300m | 300m | |
Motor rotation speed | 1420r/min | 1420r/min | |
Voltage(3phases)(optional) | 220v/380v/415v/440v 50hz/60hz to be OEM | ||
Product Overview
Platform Suspension:
The different variants are to be distinguished by their suspension principles. Three different stirrups allow choosing the
platform that best to your requirements (type of work, type of building, maximum loads, number of persons).
End stirrup:
Fitted at the ends of the platform.
Advantages:
The most economical and lightweight version, although showing extraordinary performances. Max length 12m
"Frame" stirrup:
Slipped over the platform like a "frame".
Advantages:
The ends of the platform and therefore the building corners are clear and can be easily accessed, exchangeable with the upper part
of the end stirrup. Max length 16m
"L" stirrup:
Placed at the rear of the platform behind the workers.
Advantages:
The working surface is completely clear and the whole facade can be easily accessed. Max length 16m.
The different variants are to be distinguished by their suspension principles. Three different stirrups allow choosing the
platform that best to your requirements (type of work, type of building, maximum loads, number of persons).
End stirrup:
Fitted at the ends of the platform.
Advantages:
The most economical and lightweight version, although showing extraordinary performances. Max length 12m
"Frame" stirrup:
Slipped over the platform like a "frame".
Advantages:
The ends of the platform and therefore the building corners are clear and can be easily accessed, exchangeable with the upper part
of the end stirrup. Max length 16m
"L" stirrup:
Placed at the rear of the platform behind the workers.
Advantages:
The working surface is completely clear and the whole facade can be easily accessed. Max length 16m.
