Low-Noise, Very Low Drift, Precision Voltage Reference
• Temperature range: –40°C to 125°C 2 Applications • Precision data acquisition systems • Semiconductor test equipment •
Industrial process controls • Medical instrumentation • Pressure and temperature transmitters • Lab and field instrumentation 3
Description The REF50xx is a family of low-noise, low-drift, very high precision voltage references. These references are capable
of both sinking and sourcing current, and have excellent line and load regulation. Excellent temperature drift (3 ppm/°C) and high
accuracy (0.05%) are achieved using proprietary design techniques. These features, combined with very low noise, make the REF50xx
family ideal for use in high-precision data acquisition systems. Each reference voltage is available in both high grade
(REF50xxIDGK and REF50xxID) and standard grade (REF50xxAIDGK and REF50xxAID). The reference voltages are offered in 8-pin VSSOP
and SOIC packages, and are specified from –40°C to 125°C.
