Пользовательская тележка для гольфа на 6 мест поднятая электрическая система с четырьмя дисковыми тормозами независимая

 This is our ES-L4+2 Electric Golf Carts product.

Model	LSV(High chassis)
Item	ES-L4+2
Power	48V5KW(Lead acid)	72V5KW(Lithium battery)
Photo	Below
Quotation (Including battery)	USD5250	USD6600
Chassis frame	High strength sheet metal rectangular frame (electrophoresis + highlight)
Outline dimension	3695*1340*2000mm
Front / rear tread	Front 1020mm/Rear1070mm
Wheel base	2108mm
Ground clearance	185mm
Minimum turning radius	3.45m
Net weight	650kg
Electrophoretic rated passenger (person)	6pcs
Maximum driving speed	40km/h(Can be adjusted according to customer needs)
Climbing capacity	45%
Standing slope performance	45%
Endurance	80-100km (flat road)
Braking distance	<6m
Motor voltage(Alternating current)	48V5KW	72V5KW
Motor brand	KDS Motor
Electric control brand	Borcart 48V350A	Borcart 72V350A
Battery	Shengyang lead acid without maintenance 6*8V150AH	Guosheng 72v120ah lithium iron phosphate
DC converter	High power non isolated DC-DC  48V/12V-300W	High power non isolated DC-DC  72V/12V-300W
Battery charger	Preston intelligent vehicle charger 48V/25A,charging time < 8 hours (discharge rate 80%)	Standard lithium iron phosphate charger
Steering system	Bidirectional rack and pinion steering system with automatic clearance compensation function
Braking system	Zero crossing rear axle: four wheel hydraulic pressure brake, four wheel disc brake + electronic brake parking
Front suspension	Double swing arm and independent front suspension + coil spring + barrel hydraulic pressure shock absorber.
Rear suspension	Integral rear axle, speed ratio 16:1, coil spring damping + barrel hydraulic pressure damping + rear stabilizer bar
Tire specification	DOT certification;All terrain 23*10.5-12 12 inch aluminum wheel hub,wheel diameter 580mm.
Ceiling	Frosted black square pipe frame + PP injection molding ceiling
Floor	Aluminum alloy profile anti-skid floor,high strength structure,corrosion resistance and aging resistance
Body of car	The front cover,seat barrel,body and rear tail cover are injection molded for automobiles;Frosted black square pipe ceiling column;
Seat	Integral foam forming cushion;High grade imported leather (optional) color separation;Reverse row seat can be turned over,including storage box
Instrument panel	Injection molding instrument panel, electric lock switch, double arm combination switch, gear switch, electronic hand brake switch, water cup holder; Dual USB data interface, 12V power supply, USB + type-C fast charging. The LCD electric vehicle combination instrument (including fault diagnosis information display) platform is an embedded multimedia touch LCD screen. Optional reverse image.
Rearview mirror	One manually adjustable and foldable exterior rearview mirror on the left and right
Lights and warning signals	Led front combination lamp (low beam lamp,high beam lamp,turn signal lamp,daytime running lamp, position lamp) LED rear tail lamp (brake lamp, position lamp,turn signal lamp);Snail horn, reversing buzzer
Front windshield and wiper	DOT certified acrylic plexiglass;Optional tempered glass + wiper

These are our Latest mordern Golf Carts for 2 seats,4 seats and 6 seats below:
